- Page 1 RTSA04NU User´s Manual (Ed1.1) OBJETIVOS Y SERVICIOS DE VALOR AÑADIDO S.L. Made by: Name Arancha Gómez /Maribel Ferrer Charge Product Manager / SW Manager Date 03/12/2015...
- Page 2 RTSA04NU User´s Manual Ed 1.1 Page 2 of 47 REVISION LIST EDITION CHANGES Ed. 1.0 03/09/2015: Initial Edition RTSA04NU User´s Manual. 03/12/2015: Add remark on FCC statement Ed. 1.1...
-
Page 3: Table Of Contents
RTSA04NU User´s Manual Ed 1.1 Page 3 of 47 CONTENT .......................... 5 NTRODUCTION 1.1.- ........................6 ACKING 1.2.- ......................6 AFETY RECAUTIONS 1.3.- ......................6 S AND NTERFACES 1.4.- ....................... 8 YSTEM EQUIREMENTS 1.5.- ..........................8 EATURES ......................9 ARDWARE NSTALLATION ADVANCED WEB ........................ - Page 4 RTSA04NU User´s Manual E d1.1 Page 4 of 47 3.7.3 ATM Loopback ......................39 3.7.4 ADSL Tone ........................39 3.7.5 ADSL Conectivity ......................40 3.8.- ADMINISTRATOR ......................41 3.8.1 Save and Reboot ......................41 3.8.2 Backup and restore ....................... 41 3.8.3...
-
Page 5: Introduction
RTSA04NU User´s Manual Page 5 of 47 1.- Introduction The device supports multiple line modes. With four 10/100 base-T Ethernet interfaces at the user end, the device provides high-speed ADSL broadband connection to the Internet or Intranet for high-end users like net bars and office users. -
Page 6: Packing List
RTSA04NU User´s Manual Page 6 of 47 1.1.- Packing List 1 x ADSL2+Router 11N 4 Ports Eth with USB (RTSA04NU) 1 x PSU 12V-1A 1 x RJ11 telephone cable, 2 meters length 1 x RJ45 Ethernet cable, 2 meters length ... - Page 7 RTSA04NU User´s Manual Page 7 of 47 Color Status Description Ethernet connection is unavailable. Blinking Green Negotiation Solid Green Green/Red Quick Blinking Green Tx/Rx traffic on line Traffic through broadband interface Solid Green WPS active Green Blinking 2Hz Green WPS negotiation open Rear Panel The following table describes the interface of the device (FROM LEFT TO RIGHT).
-
Page 8: System Requirements
RTSA04NU User´s Manual Page 8 of 47 1.4.- System Requirements A 10 baseT/100BaseT Ethernet card is installed on your PC. A hub or switch (attached to several PCs through one of Ethernet interfaces on the device) Operating system: Windows Vista, Windows 7, Windows 8, Windows 98SE, Windows 2000, Windows ME or Windows XP ... -
Page 9: Hardware Installation
RTSA04NU User´s Manual Page 9 of 47 2.- Hardware Installation Step 1 Connect the ADSL port of the device and the Modem port of the splitter with a telephone cable (if Splitter is available). Step 2 Connect the phone to the Phone port of the splitter through a telephone cable. Connect the incoming line to the Line port of the splitter. -
Page 10: Lan
RTSA04NU User´s Manual Page 10 of 47 3.2.- You can configure the LAN IP address according to the actual application. The preset IP address is 192.168.1.1. You can use the default settings and DHCP service to manage the IP settings for the private network. -
Page 11: Wlan
RTSA04NU User´s Manual Page 11 of 47 3.3.- WLAN This section describes the wireless LAN and basic configuration. A wireless LAN can be as simple as two computers with wireless LAN cards communicating in a pear-to-pear network or as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to wired LAN. -
Page 12: Advanced Configuration
RTSA04NU User´s Manual Page 12 of 47 Description Field enter your new wireless network name in this field. Anchura del canal Select the appropriate band of 20M, 40M or 20M/40M (Band Width) from the pull-down menu. Control de banda lateral... - Page 13 RTSA04NU User´s Manual Page 13 of 47 When it is selected WEP, you can choose the Key Length 64 or 128 bits, ASCII or HEX: When the Security Mode is set as WPA2 AES, or WPA/WPA2 Mixed, you can enter an Hexadecimal or...
- Page 14 RTSA04NU User´s Manual Page 14 of 47 The following table describes the parameters of this page. For WEP: Field Description Longitud de la clave Choose the WEP key length. You can Choose 64- (WEP Key Length) bit or 128-bit. Formato de la clave Choose ASCII or Hexadecimal.
-
Page 15: Access Control
RTSA04NU User´s Manual Page 15 of 47 3.3.4 Access Control From this page is possible to accept or deny several devices basing control on MAC Address. Choose one of the modes (Disabled, Allowed customers, Non Authorized customers). Click apply to enable the mode you want. -
Page 16: Wps
RTSA04NU User´s Manual Page 16 of 47 Go to the page to enable WDS functionality and click Apply. You must configure crossed MAC addresses: in Master station you must enter the MAC address of Slave Stationand viceversa: In the case of slave you must configure you a range of different IP to the Master, and disable the DHCP server. -
Page 17: Multiple Ssids
RTSA04NU User´s Manual Page 17 of 47 Field Description Choose to disable WPS function. By default WPS Deshabilitar WPS (Disable WPS) function is enabled, but can be only launched first time from SW page. When Configured state is selected, wireless parameters (for example, the encryption password) are provided by the CPE in WPS negotiation. -
Page 18: Wlan Status
RTSA04NU User´s Manual Page 18 of 47 3.3.8 WLAN STATUS Click WLAN Estado, you will find the page below. 3.4.- In this menu, user can manage parameters related to internet connection. 3.4.1 DSL WAN To configure internet click on WAN DSL WAN, page shown is the one below. - Page 19 RTSA04NU User´s Manual Page 19 of 47 This page contains several configurable paramaters in order to configure an internet connection. Most important ones are listed below. Description Field VPI: The virtual path between two points in an ATM network, and its valid value is from 0 to 255.
-
Page 20: Atm Configuration
RTSA04NU User´s Manual Page 20 of 47 In table below it’s possible to see how PVC’s are configured. In the example below there are two PPPoE PVC’s and one bridge. Both PPP connections are configured like Auto, but only one is up. -
Page 21: Adsl Configuration
RTSA04NU User´s Manual Page 21 of 47 3.4.3 ADSL CONFIGURATION This page allows configure ADSL modulation parameters. 3.4.4 3G configuration If you want to access the Internet through 3G connection, a 3G USB data card is required. Connect the 3G data card to the USB interface of the Router and go to this page. 3G backup is enable by default, which means that if a 3G dongle is plugged and there is a fail in DSL line, 3G will be up and Internet will be served through 3G dongle. -
Page 22: Pin Configuration
RTSA04NU User´s Manual Page 22 of 47 Field Description You may choose to enable or disable 3G Enable 3G Backup backup. It’s possible to select 2G or 3Gby default is in Network type Auto mode. Enter the access point. Enter the dial number. -
Page 23: Eth/Gre
RTSA04NU User´s Manual Page 23 of 47 3.4.7 ETH/GRE Use this section for configuring the settings of transparent Ethernet over GRE Tunnel: 3.4.8 VPN: PPTP/L2TP Use this section for configuring the settings of VPN(PPTP or L2TP) 3.5.- SERVICES 3.5.1 DHCP By default, Enable DHCP Server is selected for the Ethernet LAN interface of the device. -
Page 24: Dns
RTSA04NU User´s Manual Page 24 of 47 3.5.2 By clicking on DNS Servidor DNS we can configure manually or automatically DNS for ipv4 and ipv6. By default DNS are set automatically. - Page 25 RTSA04NU User´s Manual Page 25 of 47 To configurate Dynamic DNS, click on DNS DNS Dinámico The device supports dynamic domain name service (DDNS). The dynamic DNS service allows a dynamic public IP address to be associated with a static host name in any of the many domains, and allows access to a specified host from various locations on the Internet.
-
Page 26: Firewall
RTSA04NU User´s Manual Page 26 of 47 3.5.3 Firewall Block IP or port Click on Servicios FirewallBloquear IP/Puerto to access this page. To enable a rule is necessary to fill if the action is for outgoing/incoming traffic, choose Deny or Accept and click Apply. - Page 27 RTSA04NU User´s Manual Page 27 of 47 DNAT Click on Servicios Firewall DNAT to access to this page. Inputs on this table allows you to redirect those services required to the router from Internet, to those specific devices in your LAN using NAT.
- Page 28 RTSA04NU User´s Manual Page 28 of 47 Block domains Click on Servicios Firewall Bloquear Dominios to access to this page. From this page can configure those domains that are blocked, user can remove or add new domains. Click on Servicios Firewall DMZ to access this page. Since some applications are not compatible with NAT, the device supports the use of a DMZ IP address for a single host on the LAN.
-
Page 29: Upnp
RTSA04NU User´s Manual Page 29 of 47 3.5.4 UPnP Click on Servicios Upnp to access this page. In this page, you can configure universal plug and play (UPnP). The system acts as a daemon after you enable UPnP. UPnP is used for popular audio visual software. It allows automatic discovery of your device in the network. -
Page 30: Advanced
RTSA04NU User´s Manual Page 30 of 47 3.6.- ADVANCED Go to menu “Avanzado” to configure several advanced settings. 3.6.1 ARP Table Table ARP shows the list with MAC addresses known by the router. 3.6.2 Bridging This page is used to configure bridge parameters. In this page, you can change the settings or view some information of the bridge and its attached ports. -
Page 31: Snmp
RTSA04NU User´s Manual Page 31 of 47 Click on button “Mostrar rutas” to see the current Routing Table info as below. 3.6.4 SNMP Click on Avanzado SNMP to access this page. In this page, you can set SNMP parameters... -
Page 32: Ip Qos
RTSA04NU User´s Manual Page 32 of 47 3.6.5 IP QoS Click on Avanzado IP QoS, to get IP QoS configuration menu. There are two pages to configure it: Cola QoS and Clasificación. Política QoS (QoS Policy) In this page it’s possible to see QoS queue list. -
Page 33: Remote Access
RTSA04NU User´s Manual Page 33 of 47 Control de Tráfico (Traffic Control) 3.6.6 Remote access Click on Avanzado Acceso Remoto to see this page. At access remote page you can choose whether services are accessible or not via LAN/WAN. When one... -
Page 34: Other Configuration
RTSA04NU User´s Manual Page 34 of 47 An example of the working is explained here: For instance, if Telnet is accessible via WAN then: Is there any IP range enabled for this service? telnet is accessible just for those IP’s set in the table. -
Page 35: Ipv6
RTSA04NU User´s Manual Page 35 of 47 3.6.8 IPv6 This device supports IPv6, and there is a complete menu where user can configure main parameters for an IPv6 connection. To access to this menu go to Avanzado IPv6. Options available are: IPv6 This page allows you enable/disable Ipv6 support. - Page 36 RTSA04NU User´s Manual Page 36 of 47 DHCPv6 IPv6 hosts that use stateless autoconfiguration may require information other than an IP address. DHCPv6 can be used to acquire this information, even though it is not being used to configure IP addresses.
- Page 37 RTSA04NU User´s Manual Page 37 of 47 IPv6 Routing This page can be used to configure static routing for ipv6. From this page, user can add or remove new routes.
-
Page 38: Diagnostics
RTSA04NU User´s Manual Page 38 of 47 Block IP/Port In this page, it’s possible to block an specific IP and ports. User must choose between outgoing/incoming traffic, protocol and accept or deny that traffic. 3.7.- Diagnostics From these pages, user can use many Diagnostic tools to know which the router state is. -
Page 39: Packet Dump
RTSA04NU User´s Manual Page 39 of 47 3.7.2 Packet Dump Packet Dump is a useful tool to capture traffic. Open wireshark and follow instructions listed in the page. You may enter interface you want to capture, for instance –s 1500 –i wlan0. -
Page 40: Adsl Conectivity
RTSA04NU User´s Manual Page 40 of 47 3.7.5 ADSL Conectivity Click on Diagnóstico Conectividad ADSL to access to this page. Choose ppp interface and click on “Comenzar” button. This page will show you a list of individuals tests and if... -
Page 41: Administrator
RTSA04NU User´s Manual Page 41 of 47 3.8.- ADMINISTRATOR Click on “Administrador” for access to some management features. 3.8.1 Save and Reboot Guardar/Reiniciar: In this page you can reboot the device. CPE will save changes in your configuration and they will be stored and ready even after the reboot. -
Page 42: Close Session
RTSA04NU User´s Manual Page 42 of 47 3.8.3 Close Session This page closes current session. User will be log out and router will ask again for credentials. This way user profile can be changed. 3.8.4 System log This page displays event log data in the chronological manner. You can read the event log from the local host or send it to a system log server. -
Page 43: Password
RTSA04NU User´s Manual Page 43 of 47 3.8.5 Password In the page Administrador Contraseña, user can change the current password for accessing management web. This change can be performed for different profiles. if user does not fill those fields requiring new password, no authentication will be asked. -
Page 44: Acl
RTSA04NU User´s Manual Page 44 of 47 3.8.7 In this page, you can configure the IP address for access control list (ACL). If ACL is enabled, only devices with the specified IP addresses can access the device. Choose Enable (Habilitar) to enable ACL and click on Apply (Aplicar) button to save changes. - Page 45 RTSA04NU User´s Manual Page 45 of 47 3.8.9 TR-069 CPE WAN Management Protocol (CWMP) is a protocol for communication between a CPE and Auto- Configuration Server (ACS). The function supports TR-069 protocol which collects information, diagnoses the devices and configures the devices automatically via ACS (Auto-Configuration Server).
-
Page 46: Statistics
RTSA04NU User´s Manual Page 46 of 47 3.9.- Statistics Go to Statistics menu to see ADSL and Interface statistic. In this menu it’s possible to check network statistics and data transfer. This information helps technicians to identify if the device is functioning properly. -
Page 47: Adsl
RTSA04NU User´s Manual Page 47 of 47 3.9.2 ADSL Choose ADSL to see statistics related to DSL line working.
