System Unit Specification

Table 5-1: System Unit Specifications
Specification
Dimensions
Height
Depth
Width
Weight, no drives installed
Input power requirements * (US and international)
Rated input voltage
Rated input frequency
Rated input current
Input power (max)
Power supply specifications
Rated steady-state power
Maximum peak power
Heat dissipation (max) *
Acoustic noise (LWAdc bels and LpAm dBA)
Idle
Fixed disk (random writes)
Temperature range
Operating
Shipping
* Input power and heat dissipation specifications are maximum values and apply to worst-case
conditions at a full-rated power supply load. The power/heat dissipation for your installation varies
depending on the equipment configuration.
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:04 AM
Value
17.5 cm (6.9 in)
52.1 cm (20.5 in)
48.3 cm (19.0 in)
22.7 kg (50 lb)
100 to 240 VAC
50 to 60 Hz
7.35 A Max
641 W *
499 W
681 W
2187 Btu/hr *
<6.9 and 53
<7.3 and 54
10° to 35° C (50° to 95° F)
[derated 1°C per 304.8 m (1.8°F per 1000 ft) of
elevation to 3,048 m (10,000 ft)]
-30° to 50° C (-22° to 122° F)
