Interconnect Blank
To remove the component:
To replace the component, reverse the removal procedure.
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 10:57 AM
CAUTION: Always populate interconnect bays with a blank. Proper airflow can only be
maintained when the bays are populated. Operating the system with unpopulated bays can
lead to improper cooling and thermal damage.
Removal and Replacement Procedures
1
2
2-15
