Component Identification
4-Port Shared Storage Module Components
Table 4-6: 4-Port Shared Storage Module Components
Item
1
2
3
4
4-6
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:00 AM
1
3
Connector Description
SCSI port connector A1
SCSI port connector A2
SCSI port connector B1
SCSI port connector B2
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
2
4
Bus
A
B
