Removal and Replacement Procedures
Bezel Blank
To remove the component:
To replace the bezel blank:
1. Slide the bezel blank into the bay until it locks into place.
2. Close the lever.
2-8
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 10:57 AM
CAUTION: Always populate bays with either a component or blank. Proper airflow can only
be maintained when the bays are populated. Operating the system with unpopulated bays can
lead to improper cooling and thermal damage.
1
2
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
3
