Component Identification

Hot-Plug SCSI Hard Drive LEDs

Table 4-11: Hot-Plug SCSI Hard Drive LEDs
Item
1
2
3

Hot-Plug SCSI Hard Drive LED Combinations

Table 4-12: Hot-Plug SCSI Hard Drive LED Combinations
Activity LED Online LED
On Flashing
Off Off
Off, on, or On
flashing
Off, on, or On or Off
flashing
4-12
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:00 AM
3
2
1
LED Description
Activity
Online
Fault
Fault LED Status
Off
Do not remove the drive. Removing a drive during this process
can cause data loss in non-fault-tolerant configurations
•
•
On OK to replace the drive online.
The drive has failed and has been placed offline.
Off Do not remove the drive. Removing a drive during this process
can cause data loss in non-fault-tolerant configurations.
The drive is online and configured as part of an array.
Flashing A predictive failure alert has been received for this drive. Replace the
drive as soon as possible.
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
The drive is a replacement drive and is being rebuilt or
If all online LEDs in a drive array are flashing, an expansion is
occurring.
