To service the MSA500 system, you may need the following tools:
•
Flat-blade screwdriver
•
From the SmartStart CD:
— Advanced Diagnostics Utility (ADU)
— ROM Update Utility

Safety Considerations

Before performing service procedures, rev

Preventing Electrostatic Discharge

To prevent damaging the system, be aware of the precautions you need to follow when
setting up the system or handling parts. A discharge of static electricity from a finger or other
conductor may damage system boards or other static-sensitive devices. This type of damage
may reduce the life expectancy of the device.
To prevent electrostatic damage:
•
Avoid hand contact by transporting and storing products in static-safe containers.
•
Keep electrostatic-sensitive parts in their containers until they arrive at static-free
workstations.
•
Place parts on a grounded surface before removing them from their containers.
•
Avoid touching pins, leads, or circuitry.
•
Always be properly grounded when touching a static-sensitive component or assembly.
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 10:57 AM

Removal and Replacement Procedures

iew all the safety information.
2
2-1
