Universal Hot-Plug Tape Drive
To remove the component:
To replace the Universal Hot-Plug Tape drive:
1. Install a new tape drive height converter on the replacement tape drive.
2. Slide the tape drive into the bay until it locks into place.
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 10:57 AM
CAUTION: To prevent improper cooling and thermal damage, do not operate the system
unless all bays are populated with either a component or a blank.
CAUTION: Installation of the tape drive height converter is permanent. Attempting to
remove the converter after installation voids the tape drive warranty.
2
CAUTION: Data loss can occur if the drive is not firmly seated.
Removal and Replacement Procedures
1
2-7
