Component Identification
2-Port Shared Storage Module Components
Table 4-4: 2-Port Shared Storage Module Components
Item
1
2
4-4
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:00 AM
Connector Description
SCSI port connector
SCSI port connector
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
1
2
Bus
A
B
