Video Modes

The 54M40 provides all standard VGA modes. With 512 KB of video
memory, the standard server goes beyond standard VGA support. If
necessary, you can install an additional 512 KB of video memory on the
system board. The following tables show all supported video modes that
use 512 KB and 1 MB of video memory.
Bits
Hexadecimal Per
Mode Number Pixel
0, 1 4
2, 3 4
4, 5 4
6 4
7 4
D 4
E 4
F 4
10 4
11 4
12 4
12+ 4
13 8
32
Table 1-1. Standard VGA Modes
Colors
(number/palette
size) Resolution
16/256K 360 X 400
16/256K 720 X 400
4/256K 320 X 200
2/256K 640 X 200
Mono 720 X 400
16/256K 320 X 200
16/256K 640 X 200
Mono 640 X 350
16/256K 640 X 350
2/256K 640 X 480
16/256K 640 X 480
16/256K 640 X 480
256/256K 320 X 200
Pixel Horizontal
Frequency Frequency
(MHz) (kHz)
14 31.5
28 31.5
12.5 31.5
25 31.5
28 31.5
12.5 31.5
25 31.5
25 31.5
25 31.5
25 31.5
25 31.5
31.5 37.5
12.5 31.5
Chapter 1 Server Description
Vertical
Frequency
(Hz)
70
70
70
70
70
70
70
70
70
60
60
75
70
