ECC Memory

Table 6-1. ECC Memory Banks
If you fill one bank with
8 MB DIMM, 1M x 72
16 MB DIMM, 2M x 72
32 MB DIMM, 4M x 72
64 MB DIMM, 8M x 72
128 MB DIMM, 16M x 72
Table 6-2. Sample DIMM Size Combinations
0, J1 1, J2 2, J3 3, J4 4, J5 5, J6 6, J7 7, J8 Total Memory
8
8 16
16 32
16 32
32 64
64 16
8 16
64 64
128 128
M440LX Server System Product Guide
Memory size for that bank will be
8 MB
16 MB
32 MB
64 MB
128 MB
Banks Filled
8
8 8
64 128 128
32 32 8
16 32 64
64 64 64
128 128 128
128
64 128 128
64 64 64
128 128 128
8 MB
24 MB
56 MB
64 MB
416 MB
280 MB
456 MB
512 MB
1024 MB
