Page 1 ® Intel Modular Server System Service Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products Intel Order Number E70616-004...
Page 2 The source code contained or described herein and all documents related to the source code (Material) are owned by Intel Corporation or its suppliers or licensors. Title to the Material remains with Intel Corporation or its suppliers and licensors. The Material may contain trade secrets and proprietary and confidential information of Intel Corporation and its suppliers and licensors, and is protected by worldwide copyright and trade secret laws and treaty provisions.
Page 3: Preface
® Chapter 4 provides information and instructions on how to use the Intel Modular Server Control user interface to configure the modular server system. This includes step-by-step instructions and screenshots for configuring the system components, updating the modular server system firmware, and monitoring system health.
Page 4 ® Intel Modular Server System Service Guide...
Page 5: Safety Information
Server Boards and Server Chassis Safety Information at: http://support.intel.com/support/motherboards/server/sb/cs-010770.htm Wichtige Sicherheitshinweise Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor ® Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Intel Server Boards and Server Chassis Safety Information unter: http://support.intel.com/support/motherboards/server/sb/cs-010770.htm Consignes de sécurité...
Page 6: Warnings
Reinstalling enclosure cover: To protect internal components and for proper cooling and airflow, the compute module should not be inserted into the chassis with the cover removed; operating it without the enclosure cover in place can damage system parts. ® Intel Modular Server System Service Guide...
Page 7: Table Of Contents
Hardware Installations and Upgrades ..............17 Before You Begin .........................17 Tools and Supplies Needed ...................... 17 Chassis References ........................17 ® Installing the Intel Modular Server System MFSYS25/MFSYS35 in a Rack ........................17 Installation Guidelines ....................... 17 Installing Temporary Handles on System ................. 18 Mounting System in Rack ......................
Page 8 Removing a 2.5-inch Hard Drive from the Storage Bay ............43 Installing a 3.5-inch Hard Drive into the Storage Bay ............... 46 Removing a 3.5-inch Hard Drive from the Storage Bay ............49 Installing and Removing an Intel® Compute Module ............52 ® Installing an Intel Compute Module ..................
Page 9 Feature Activation ........................145 Firmware Updates ........................146 Restore System Settings ......................148 Access Online Help ......................150 ® Log Out from the Intel Modular Server Control ..............150 Troubleshooting ..................... 151 First Steps Checklist ......................151 Specific Issues and Corrective Actions ................151 Chassis Fan Module Not Functioning ..................
Page 10 Advertencias y precauciones sobre seguridad ............... 200 Aplicaciones y usos previstos ....................200 Selección de la ubicación ....................... 201 Manipulación del equipo ......................201 Advertencias el acceso al sistema ..................203 Descarga electrostática (ESD) ....................204 ® Intel Modular Server System Service Guide...
Page 11 Figure 37. Removing a 3.5-inch Drive Carrier from the Drive Bay Module ......50 Figure 38. Removing Hard Drive from a Drive Carrier ............. 51 Figure 39. Installing an Intel® Compute Module ..............52 Figure 40. Removing an Intel® Compute Module ..............53 Figure 41.
Page 12 Figure 46. Removing the Midplane ..................62 Figure 47. Installing the Midplane .................... 63 Figure 48. Installing the Rear Module Cage ................64 ® Figure 49. Intel Modular Server Control Login ............... 73 ® Figure 50. Intel Modular Server Control General Layout ............74 ®...
Page 13 Figure 96. Settings - Feature Activation ................. 146 Figure 97. Settings - Firmware Update Screen ..............147 Figure 98. Settings - Restore System Settings ..............148 Figure 99. Online Help ......................150 ® Intel Modular Server System Service Guide xiii...
Page 14 ® Intel Modular Server System Service Guide...
Page 15 List of Tables Table 1. Modular Server System Features................. 3 ® Table 2. Intel Modular Server System MFSYS25 Contents ............. 3 ® Table 3. Intel Modular Server System MFSYS25 Contents ............. 4 Table 4. Modular Server System References ................6 Table 5.
Page 16 ® Intel Modular Server System Service Guide...
Page 17: Modular Server System Features
Intel Modular Server System MFSYS25V2 All references in the document to MFSYS25 are for both MFSYS25 and MFSYS25V2. Exceptions will call out either MFSYS25 or MFSYS25V2. Unless noted otherwise, all information provided refers to both versions. This chapter briefly describes the main ®...
Page 18: Modular Server System Feature Overview
AF002661 ® Figure 2. Intel Modular Server System MFSYS35 Modular Server System Feature Overview Table 1 provides an overview of the modular server system configuration. ® Intel Modular Server System Service Guide...
Page 19: Intel® Modular Server Systems Content And References
Modular Server Control Powerful integrated management GUI for configuration and chassis management • Provides a single interface for system updates Intel® Modular Server Systems Content and References ® The following three versions of the Intel Modular Server System are available: ®...
Page 20: Table 3. Intel ® Modular Server System Mfsys25 Contents
Server Blanks (Compute Module filler panels) Blank filler panels for rear module bays SCM2 and SWM2 Documentation package including: System Quick Start Guide, Safety Flyer and Resource CD Note: The MFSYS25V2 base configuration does not include hard drives, compute modules or power cords. ® Intel...
Page 21 ® Intel Modular Server System MFSYS35 Contents ® Your Intel Modular Server System MFSYS35 ships with the following items: Quantity Description Chassis enclosure ® Intel Management Module ® Intel Gigabit Ethernet Switch Module ® Intel Storage Control Module 3.5" hard disk drive carriers...
Page 22: Additional Information And Software
Provided in the product box or available for download at: assemble your modular http://support.intel.com/p/en_US/support/highlights/server/mfsys25 server system and install components Accessories or other Intel Spares, Parts List, and Configuration Guide server products Available at: http://support.intel.com/p/en_US/support/highlights/server/mfsys25 or by using the Server Configurator Tool Available at: http://serverconfigurator.intel.com/default.aspx...
Page 23: Major Components
Modular Server Control UI: The Intel Management Module ® your Intel server integrated management interface for the modular server system. ® For instructions and information, refer to the Intel Modular Server System User Guide. Available at: http://www.intel.com/p/en_US/support/highlights/server/mfsys25/ Major Components Front View Figure 3 shows the front view of the platform.
Page 24: Figure 3. Front View Of Intel
Hard Disk Drive bay module with hot-swap 2.5-inch SAS hard disk drives (14) [HDD 1 on the upper left and HDD 14 on the lower right] I/O cooling module System Status LED ® Figure 3. Front View of Intel Modular Server System MFSYS25 ® Intel Modular Server System Service Guide...
Page 25: Figure 4. Front View Of Intel ® Modular Server System Mfsys35
Hard Disk Drive bay module with hot-swap 3.5-inch SAS or SATA hard disk drives (6) [HDD 1 on top and HDD 6 on bottom] I/O cooling module System Status LED ® Figure 4. Front View of Intel Modular Server System MFSYS35 Compute Module ® The Intel Modular Server System supports up to six compute modules.
Page 26 Storage configuration and management are supported via the Intel Modular Server Control UI. ® To access the installed physical drives, you must install at least one Intel Storage Control Module in the rear bay labeled SCM1. Because hard disk drives have different cooling, power, and vibration characteristics, Intel ®...
Page 27: Rear View
All four power supply bays must be populated with either a power supply module or a power supply blank. The power supply blank has two fans that ensure proper system cooling. ® Intel Modular Server System Service Guide...
Page 28 ® One or two hot-swap Intel Storage Control Modules can be used for up to 14 hot-swap ® SAS hard drives in the Intel Modular Server System MFSYS25 and up to 6 hot-swap ® SAS/SATA hard drives in the Intel Modular Server System MFSYS35.
Page 29: Front Chassis Connectors And Indicators
I/O cooling module power LED – Green I/O cooling module fault LED – Amber Chassis System Fault LED - Amber ® Figure 6. Intel Modular Server System MFSYS25 Front Chassis Connectors and Indicators ® Intel Modular Server System Service Guide...
Page 30: Compute Module Connectors And Indicators
I/O cooling module fault LED – Amber Chassis System Fault LED - Amber ® Figure 7. Intel Modular Server System MFSYS35 Front Chassis Connectors and Indicators Compute Module Connectors and Indicators For detailed information on compute module connectors and indicators, refer to the appropriate compute module Technical Product Specification and User Guide.
Page 31: Back Chassis Connectors And Indicators
Power supply module power LED – Green Power supply fault indicator LED – Amber Main Cooling Module Main cooling module fault LED – Amber Main cooling module power LED – Green Figure 8. Rear Chassis Connectors and Indicators ® Intel Modular Server System Service Guide...
Page 32: Rack Mount Options
All indicator modes are described in “Diagnostic LED Information” on page 153. Rack Mount Options ® Your Intel Modular Server System can be mounted into a 4-post fixed mount rack. ® Intel Modular Server System Service Guide...
Page 33: Hardware Installations And Upgrades
Review the safety and ESD information at the beginning of this manual and in the appendices. ® • Use a mechanical lift to install the Intel Modular Server System MFSYS25/ MFSYS35 in a rack cabinet. • When lifting the system, DO NOT lift by the power supply or fan module handles.
Page 34: Installing Temporary Handles On System
Installing Temporary Handles on System ® Temporary handles are provided with your Intel Modular Server System. These handles are intended to aid in the movement of the system during removal from packaging and during initial configuration and installation.
Page 35: Mounting System In Rack
Compute modules, management modules, switch modules, storage control modules, power modules, and cooling modules should be replaced with a like component or a filler panel within two minutes. ® Intel Modular Server System Service Guide...
Page 36: Replacing The Management Module
Replacing the Management Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with a management module pre-installed in the middle bay of the rear of the chassis. The middle bay is dedicated to the management module and is labeled CMM. For the exact location of the...
Page 37: Installing The Management Module
To install the management module, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. Locate the management module bay and remove the module to be replaced. ® Intel Modular Server System Service Guide...
Page 38: Figure 11. Installing The Management Module
AF002414 Figure 11. Installing the Management Module 5. Rotate the lever handle in toward the module bay until it is latched. 6. Reconnect the Ethernet management port to the management network. ® Intel Modular Server System Service Guide...
Page 39: Installing And Removing An Ethernet Switch Module
Installing and Removing an Ethernet Switch Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with one Ethernet switch module pre-installed. Optionally, a second switch module may be installed in the second switch module bay. An ethernet switch module can only be installed in a module bay that is designed to support that device type.
Page 40: Removing An Ethernet Switch Module
4. Rotate the lever out and away from the module bay (see letter “B” in Figure 13) and pull the module straight out the back of the chassis (see letter “C” in Figure 13). ® Intel Modular Server System Service Guide...
Page 41: Figure 13. Removing An Ethernet Switch Module
AF002413 Figure 13. Removing an Ethernet Switch Module 5. Install a filler panel or another Ethernet switch module in the switch module bay within two minutes. ® Intel Modular Server System Service Guide...
Page 42: Installing And Removing A Storage Control Module
Installing and Removing a Storage Control Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with one storage control module pre-installed. Optionally, a second storage control module may be installed in the open storage control module bay. A Storage Control module can only be installed in a module bay that is designed to support that device type.
Page 43: Removing A Storage Control Module
If only one Intel Storage Control Module is installed in the Intel Modular Server ® System, power off all compute modules prior to removing the Intel Storage Control Module To remove a storage control module, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices.
Page 44: Figure 15. Removing A Storage Control Module
AF002430 Figure 15. Removing a Storage Control Module 4. Install a filler panel or another storage control module in the storage control module bay within two minutes. ® Intel Modular Server System Service Guide...
Page 45: Installing And Removing The Backup Battery
Figure 16. Removing Top Cover from Storage Control Module 5. Slide the cover towards the rear of the storage control module (see letter “B” in Figure 16) and lift upward (see letter “C” in Figure 16). ® Intel Modular Server System Service Guide...
Page 46: Removing A Backup Battery
2. Remove the storage control module from the system. For instructions, see “Removing a Storage Control Module” on page Warning: You must replace the storage control module with a filler panel or another storage control module within two minutes. ® Intel Modular Server System Service Guide...
Page 47: Figure 18. Removing Top Cover From Storage Control Module
Figure 18. Removing Top Cover from Storage Control Module 5. Slide the cover towards rear of the storage control module (see letter “B” in Figure 18) and lift upward (see letter “C” in Figure 18). ® Intel Modular Server System Service Guide...
Page 48: Installing And Removing A Power Supply Module
“Installing a Storage Control Module” on page Installing and Removing a Power Supply Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with two power supply modules pre-installed. A single power supply is suitable to support the power requirement for the chassis, including fan modules, storage control module, switch module, storage bay, and a single compute module.
Page 49: Installing A Power Supply Module
— To remove a filler module, press the retention lever latch (see letter “A” in Figure 20) to release the filler module from the module bay. Slide the filler module out of the bay (see letter “B” in Figure 20). AF002420 Figure 20. Removing Filler Module ® Intel Modular Server System Service Guide...
Page 50: Removing A Power Supply Module
1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. Locate the power supply module to be removed. 3. Remove the power cord from both the power supply module and the power source. ® Intel Modular Server System Service Guide...
Page 51: Replacing A Main Cooling Module
5. Replace the power supply module with a filler panel or another power supply module within two minutes. Replacing a Main Cooling Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with two main cooling modules pre-installed at the back of the chassis. For the exact location of the Main Cooling Modules, see Figure ®...
Page 52: Removing A Main Cooling Module
Warning: Replace the cooling module with another cooling module within two minutes. AF002438 Figure 23. Removing a Main Cooling Module 5. Install another cooling module into the cooling module bay within two minutes. ® Intel Modular Server System Service Guide...
Page 53: Installing A Main Cooling Module
Figure 24. Installing a Main Cooling Module Replacing the I/O Cooling Module ® The Intel Modular Server System MFSYS25/MFSYS35 ships with one I/O cooling module pre-installed at the front of the chassis. For the exact location of the I/O Cooling Module in ®...
Page 54: Removing The I/O Cooling Module
® • Intel Modular Server System MFSYS25, see Figure 3 ® • Intel Modular Server System MFSYS35, see Figure Removing the I/O Cooling Module To remove the I/O cooling module, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices.
Page 55: Installing The I/O Cooling Module
The on-board storage bay supports the installation of up to 14 hot- ® swap 2.5-inch SAS hard drives in the Intel Modular Server System MFSYS25 or 6 hot- ®...
Page 56: Installing A 2.5-Inch Hard Drive Into The Storage Bay
MFSYS35 should be installed. You may damage the Intel Modular Server System ® MFSYS25/MFSYS35 if you install a hard drive that is not listed in the Intel Modular Server System MFSYS25/MFSYS35 Tested Hardware and Operating System List. Installing a 2.5-inch Hard Drive into the Storage Bay To install a 2.5-inch hard drive into the storage bay, follow these steps:...
Page 57: Figure 28. Installing Hard Drive Into Drive Carrier
Figure 28) and attach it to the drive carrier using the four screws removed in the previous step (see letter “B” in Figure 28). AF002428 Figure 28. Installing Hard Drive into Drive Carrier ® Intel Modular Server System Service Guide...
Page 58: Figure 29. Attaching Axxtm3Sata To The Drive
5. For 2.5" SSD and SATA hard drives, attach the AXXTM3SATA (SATA to SAS Converter Board) to the drive. See the below figure. Figure 29. Attaching AXXTM3SATA to the Drive ® Intel Modular Server System Service Guide...
Page 59: Removing A 2.5-Inch Hard Drive From The Storage Bay
1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. To avoid data corruption, ensure that the drive you intend to remove is not online and actively providing data storage to any of the installed compute modules. ® Intel Modular Server System Service Guide...
Page 60: Figure 31. Removing A 2.5-Inch Drive Carrier From The Drive Bay Module
(see letter “A” in Figure 31). Remove the drive carrier from the drive bay module (see letter “B” in Figure 31). AF002425 Figure 31. Removing a 2.5-inch Drive Carrier from the Drive Bay Module ® Intel Modular Server System Service Guide...
Page 61: Figure 32. Removing Hard Drive From A Drive Carrier
32). Lift the hard drive from the carrier (see letter “B” in Figure 32) and store the hard drive in an anti-static container or bag. AF002429 Figure 32. Removing Hard Drive from a Drive Carrier ® Intel Modular Server System Service Guide...
Page 62: Installing A 3.5-Inch Hard Drive Into The Storage Bay
Installing a 3.5-inch Hard Drive into the Storage Bay To install a 3.5-inch hard drive into the storage bay, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices. ® Intel Modular Server System Service Guide...
Page 63: Figure 34. Removing A 3.5-Inch Drive Carrier From The Drive Bay Module
(see letter “B” in Figure 34). AF002662 Figure 34. Removing a 3.5-inch Drive Carrier from the Drive Bay Module 3. With a Phillips* screwdriver, remove the four screws securing the filler panel to the drive carrier. ® Intel Modular Server System Service Guide...
Page 64: Figure 35. Installing Hard Drive Into Drive Carrier
Figure 35) and attach it to the drive carrier using the four screws removed in the previous step (see letter “B” in Figure 35). AF00317 Figure 35. Installing Hard Drive into Drive Carrier ® Intel Modular Server System Service Guide...
Page 65: Removing A 3.5-Inch Hard Drive From The Storage Bay
1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. To avoid data corruption, ensure that the drive you intend to remove is not online and actively providing data storage to any of the installed compute modules. ® Intel Modular Server System Service Guide...
Page 66: Figure 37. Removing A 3.5-Inch Drive Carrier From The Drive Bay Module
(see letter “A” in Figure 37). Remove the drive carrier from the drive bay module (see letter “B” in Figure 37). AF002662 Figure 37. Removing a 3.5-inch Drive Carrier from the Drive Bay Module ® Intel Modular Server System Service Guide...
Page 67: Figure 38. Removing Hard Drive From A Drive Carrier
5. Install either another hot-swap hard drive or a filler blank in the drive carrier. 6. Install the drive carrier into the empty drive bay module within two minutes; this step is required to maintain proper airflow throughout the chassis and to ensure proper system cooling. ® Intel Modular Server System Service Guide...
Page 68: Installing And Removing An Intel® Compute Module
Installing and Removing an Intel® Compute Module Installing an Intel® Compute Module ® To install an Intel Compute Module, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. If you have not done so already, install any necessary options, such as processor and memory, in the compute module.
Page 69: Removing An Intel® Compute Module
Removing an Intel® Compute Module ® To remove an Intel Compute Module, follow these steps: 1. Review the safety and ESD information at the beginning of this manual and in the appendices. 2. If the compute module is operating, shut down the operating system and power it down.
Page 70: Removing And Installing The 2.5-Inch Hard Disk Drive Bay Module
3. Power down all installed compute modules. ® 4. Power down the Intel Modular Server System MFSYS25/MFSYS35 by unplugging power cords to all installed power supplies. 5. Remove the I/O Cooling Module.
Page 71: Installing The 2.5-Inch Hard Disk Drive Bay Module
3. Install the HDD Bay Module bezel (see letter “B” in Figure 42) and secure it with eight screws taking care not to fully tighten the screws until all eight screws are in place (see letter “C” in Figure 42). ® Intel Modular Server System Service Guide...
Page 72: Figure 42. Installing The 2.5-Inch Hard Disk Drive Bay Module
5. Install the I/O Cooling module. You must ensure that the I/O Cooling Module being installated is appropriate for the installed HDD Bay Module. ® For information about choosing the appropriate cooling module, refer to the Intel Modular Server Spare/Parts List and Configuration Guide. For instructions on installing the I/O Cooling module, see “Installing the I/O Cooling Module”...
Page 73: Removing And Installing The 3.5-Inch Hard Disk Drive Bay Module
3. Power down all installed compute modules. ® 4. Power down the Intel Modular Server System MFSYS25/MFSYS35 by unplugging power cords to all installed power supplies. 5. Remove the I/O Cooling Module.
Page 74: Installing The 3.5-Inch Hard Disk Drive Bay Module
2. Gently slide the HDD bay module into the chassis ensuring that the bay is straight and level (see letter “A” in Figure 44). There will be some slight resistance before the bay is fully seated as the bay is inserted into the midplane connectors. ® Intel Modular Server System Service Guide...
Page 75: Figure 44. Installing The 3.5-Inch Hard Disk Drive Bay Module
(see letter “C” in Figure 44). Do not over tighten the screws holding the bezel. AF0031 Figure 44. Installing the 3.5-inch Hard Disk Drive Bay Module ® Intel Modular Server System Service Guide...
Page 76: Replacing The Midplane
5. Install the I/O Cooling Module. You must ensure that the I/O Cooling Module being installated is appropriate for the installed HDD Bay Module. ® For information about choosing the appropriate cooling module, refer to the Intel Modular Server Spare/Parts List and Configuration Guide. For instructions on installing the I/O Cooling module, see “Installing the I/O Cooling Module”...
Page 77: Figure 45. Removing The Rear Module Cage
15. Grasp the cage and gently pull it straight out of the chassis (see letter “B” in Figure 45). AF003176 Figure 45. Removing the Rear Module Cage 16. From the rear of the chassis, remove the 12 screws holding the midplane in place (see letter “A” in Figure 46). ® Intel Modular Server System Service Guide...
Page 78: Figure 46. Removing The Midplane
Note: When removing the midplane, slightly tilt the top of the midplane towards the rear of the chassis so that it is at an angle to allow removal from the chassis. Figure 46. Removing the Midplane ® Intel Modular Server System Service Guide...
Page 79: Installing The Midplane
3. Once in place, secure the midplane to the chassis using the 12 screws (see letter “B” in Figure 47). Take care not to tighten the screws until all screws are in place; do not overtighten. AF003179 Figure 47. Installing the Midplane ® Intel Modular Server System Service Guide...
Page 80: Figure 48. Installing The Rear Module Cage
For instructions, see “Installing an Ethernet Switch Module” on page 9. Install the Storage Control Module(s) and/or filler panels. For instructions, see “Installing a Storage Control Module” on page 10. Install the Main Cooling Modules. ® Intel Modular Server System Service Guide...
Page 81 For instructions, see “Installing the I/O Cooling Module” on page 14. Install the Compute Module(s) and/or filler panels. For instructions, see “Installing an Intel® Compute Module” on page ® 15. Power up the Intel Modular Server System MFSYS25/MFSYS35 by connecting power cords to all installed power supplies and connecting to an appropriate power source.
Page 82 ® Intel Modular Server System Service Guide...
Page 83: Using The Modular Server System
Using the Modular Server System Minimum Hardware Requirements ® To successfully power up the Intel Modular Server System MFSYS25/MFSYS35 and to avoid integration difficulties and possible system damage, your modular server system must meet the minimum hardware requirements listed in the following table.
Page 84: Monitoring The Server System
One possible way to install an operating system is as follows: ® 1. Connect a remote client machine to the management module in the Intel Modular Server System MFSYS25/MFSYS35 via a cross-over cable. 2. Connect a USB hub to one of the USB ports to allow more than two USB devices to be used.
Page 85: Using The Intel Modular Server Control User Interface
® The Intel Management Module provides a simple and intuitive browser-based graphical ® user interface that IT administrators can use to monitor and configure the Intel Modular ® Server System MFSYS25/MFSYS35. This GUI is referred to as the Intel Modular Server Control UI.
Page 86: System Configuration Requirements
Virtual drives can be assigned to a compute module slot/bay in the chassis regardless of whether or not a compute module is present. However, in order to install ® an operating system, you must first insert a compute module into the Intel Modular Server System MFSYS25/MFSYS35.
Page 87: Setting Up A Remote Connection
It is recommended that the Intel Management Module not be connected to a publicly accessible network. ® The two recommended options for connecting a client system to the Intel Management ® Module in order to launch the Intel Modular Server Control UI are illustrated below.
Page 88: Remote Client System Requirements
Adobe* Flash Player: http://www.adobe.com/products/flashplayer/ • Java* SE Runtime Environment 6, Update 1: http://www.java.sun.com/javase/ downloads/index.jsp ® Log in to the Intel Modular Server Control ® To launch the Intel Modular Server Control, open a browser session on the remote client system. ®...
Page 89: Figure 49. Intel ® Modular Server Control Login
AF002066 Enter Management Module IP Address, 192.168.150.150 Enter Default Username (admin) Enter Default Password (admin) ® Figure 49. Intel Modular Server Control Login ® Intel Modular Server System Service Guide...
Page 90: Layout And Key Navigation Features
Top Menu Left Navigation Main Body AF002459 ® Figure 50. Intel Modular Server Control General Layout ® Intel Modular Server System Service Guide...
Page 91: Figure 51. Intel ® Modular Server Control Configuration Screen Layout
Figure 7 illustrates the layout and types of information presented on the system configuration screens. AF002067 ® Figure 51. Intel Modular Server Control Configuration Screen Layout ® Intel Modular Server System Service Guide...
Page 92: Table 7. Intel ® Modular Server Control Configuration Screen Layout
• ® Dashboard: This tab is displayed by default after logging into the Intel Modular Server Control UI. It provides a snapshot view of the overall system and component health, and also lists all the required actions and critical events.This screen can also be accessed from the left navigation panel by clicking Reports >...
Page 93 Global Hot Spare Icon – indicates hard drives that have been designated as global hot spares. Hover over icon to view component summary information. Server is powered off. Ready for Transport ® Intel Modular Server System Service Guide...
Page 94: Chassis Front
To access the Chassis Front view, click the Chassis Front tab in the top menu. By default, no components are selected on the chassis in this view. Figure 52. Chassis Front View ® Intel Modular Server System Service Guide...
Page 95: System
Compute Module View ® ® The Intel Modular Server System MFSYS25/MFSYS35 supports up to six Intel Compute Modules. To maintain the proper cooling within the modular server system, all empty bays must be populated with the appropriate filler panels. ®...
Page 96: Table 8. Health Icons
Powered Off Firmware update or other background activity ® Intel Compute Module Actions The actions available for a selected server are displayed to the right of the system graphic. For a description of these actions, refer to the following table.
Page 97 Select the type of action first (power on, power off, reset). Then select the servers to apply the action. CAUTION: To avoid potential data loss when selecting power off the Graceful Shutdown option is recommended to shut down applications and the operating system. ® Intel Modular Server System Service Guide...
Page 98: Table 10. Server Tabs
® Intel Compute Module Help ® To quickly access additional help regarding the Intel Compute Module screen, actions, and tabs, click the Get Help button in the Server help box located under Actions. Remote KVM & CD The Remote KVM & CD feature can be used to connect a remote text-based or graphical console to any of the compute modules.
Page 99: Figure 54. Server Action - Remote Kvm & Cd
If the option is grayed out, then the session has been automatically started. 8. To install an application from a CD, insert the CD into the remote console’s CD-ROM drive and select CD from the Devices menu. ® Intel Modular Server System Service Guide...
Page 100: Storage Configuration
This section provides information on creating an initial storage pool, creating an initial ® virtual drive and mapping the virtual drive to a compute module using the Intel Modular Server Control UI. Once a virtual drive is mapped to a compute module, an operating system can be installed.
Page 101: Figure 55. Initial Storage Configuration Screen
Figure 56. Create Storage Pool Dialog Box 3. Enter a name or label for the storage pool. 4. Select the physical hard drives that are to be grouped together to create a single storage pool. ® Intel Modular Server System Service Guide...
Page 102 RAID level is not assigned to a storage pool. Instead, it is assigned to the virtual drives within a storage pool. This enables a single storage pool to support many virtual drives with different RAID levels. ® Intel Modular Server System Service Guide...
Page 103: Figure 57. Create Storage Pool Dialog Box Example
Current health and product summary is quickly available by moving the mouse over the Health/Information icon located on the selected storage pool. ® Intel Modular Server System Service Guide...
Page 104: Figure 58. Storage Pool Screen
Critical (For details, see the Event Log. For information about accessing the Event Log, see “Events” on page 122.) Warning (For details, see the Event Log. For information about accessing the Event Log, see “Events” on page 122.) Information ® Intel Modular Server System Service Guide...
Page 105: Table 12. Storage Pool Actions Menu
Create Virtual Drive A virtual drive is assigned a name, RAID level, size and server. Once a virtual drive is created, an operating system can be installed. ® Intel Modular Server System Service Guide...
Page 106 Storage Pool Details The tabs displayed below the system graphic provide detailed information on the selected storage pool. For a description of these tabs, refer to the following table. ® Intel Modular Server System Service Guide...
Page 107: Table 13. Storage Pool Tabs
Modules. The following are the key benefits of virtual drives: • Virtual drives can be quickly reassigned to different servers with a couple of mouse ® clicks in the Intel Modular Server Control UI without powering down the server or storage pool. •...
Page 108: Figure 59. Create Virtual Drive Dialog Box
By default, this option is set to “auto (recommended)” but can be changed to either ® ® Intel Storage Control Module 1 (SCM1) or Intel Storage Control Module 2 (SCM2). By selecting “auto (recommended)”, the system assigns a storage control module for the virtual drive.
Page 109: Figure 60. Virtual Drive Screen
Shared LUN feature is activated, the “Assign to multiple servers” check ® box is displayed. When the check box is selected, the Intel Shared LUN feature allows a virtual drive to be assigned to two or more servers. This feature requires operating system support for sharing LUNs.
Page 110: Table 14. Health Icons
• Degraded: The virtual drive RAID array is available but has lost one or more disks. The virtual drive will be rebuilt automatically if a global or dedicated spare is available. ® Intel Modular Server System Service Guide...
Page 111: Table 15. Virtual Drive Action Menu
Virtual Drive Details The tabs displayed below the system graphic provide detailed information on the selected virtual drive. For a description of these tabs, refer to the following table. ® Intel Modular Server System Service Guide...
Page 112: Table 16. Virtual Drive Tabs
To assign a virtual drive to a server, follow these steps: 1. From the Storage view, select a virtual drive. 2. Choose Assign from the action menu. The following dialog box appears. ® Intel Modular Server System Service Guide...
Page 113: Figure 61. Assign Virtual Drive
4. Select the desired drive number if you selected a server in step 3. (Drive #0 is the boot device.) 5. Click Assign to apply the changes. ® To assign a virtual drive to multiple servers (available only when the Intel Shared LUN ® feature has been activated - for instructions to activate the Intel Shared LUN feature, see “Feature Activation”...
Page 114: Figure 62. Deleted Virtual Drive
The following figure displays the Storage screen after a virtual drive has been deleted from a storage pool that contained more than three virtual drives. Figure 62. Deleted Virtual Drive ® Intel Modular Server System Service Guide...
Page 115: Figure 63. Physical Drives
Information icon located on the selected hard drive. Note: For drives that are included in a storage pool, limited drive details are also displayed on the physical drive tab for the assigned storage pool. Figure 63. Physical Drives ® Intel Modular Server System Service Guide...
Page 116: Table 17. Health Icons
Stale: The drive was at one time part of a storage pool, but was taken offline by an error or was transported without being installed, and is no longer required by the storage pool. You may keep the drive in the stale state to preserve the data (for ® Intel Modular Server System Service Guide...
Page 117: Table 18. Physical Drive Action Menu
Cancel Hot Spare is present if a drive hot-spare drive) role is assigned as either a global or dedicated hot spare. ® Intel Modular Server System Service Guide...
Page 118: Table 19. Physical Drive Tabs
Physical Drive Help To quickly access additional help regarding physical drive actions and tabs, click on the Get Help button in the Shared Drive help box located under the action box. ® Intel Modular Server System Service Guide...
Page 119 (assigned to a specific storage pool) and click Apply. Once the hot spare has been created, a successful action dialog will be displayed and the information icon will change to the hot spare icon, ® Intel Modular Server System Service Guide...
Page 120: Intel ® Gigabit Ethernet Switch Module 1 And 2
Intel Gigabit Ethernet Switch modules. Each switch module has 12 ® internal ports and ten external ports. By default, the Intel Gigabit Ethernet Switch Module assigns all internal and external ports to a default virtual LAN (VLAN).
Page 121: Figure 65. Intel ® Gigabit Ethernet Switch Module View
® Figure 65. Intel Gigabit Ethernet Switch Module View Health Icons The health icons are displayed on the graphical representation of the component when the component is selected. ® Intel Modular Server System Service Guide...
Page 122: Table 20. Health Icons
Launches a third-party Advanced Switch Configuration interface in a new window to view all ® switch configuration options. Refer to the Intel Gigabit Ethernet Switch AXXSW1GB User Guide for more information on how to use the Advanced Configuration Switch interface.
Page 123: Table 22. Switch Module Tabs
Gigabit Ethernet Switches come pre-configured with all available ports enabled in ® a single default VLAN. No additional configuration is required to connect the Intel Modular Server System MFSYS25/MFSYS35 to a network. Two options are available to modify the default switch configuration: •...
Page 124 Configure Ports Dialog The Configure Ports dialog enables an IT administrator to modify the following ® parameters for each Intel Ethernet Switch Module: • Enable or disable external ports • Assign any port (internal or external) to a VLAN •...
Page 125: Figure 66. Configure Ports Dialog Box
Figure 66. Configure Ports Dialog Box Advanced Configuration ® The Advanced Configuration action launches the embedded switch UI for the Intel Gigabit Ethernet Switch Module in a new window. This interface exposes all configuration settings for the switch. Configuration settings modified in either the ®...
Page 126: Chassis Back
The icons present on each of the components indicate the current health. By hovering over the component icon, a brief summary of the current health, state and component description is displayed in a pop-up box. ® Intel Modular Server System Service Guide...
Page 127: Intel ® Storage Control Module 1 And 2
To view the current status, available actions, and product details ® for an installed Intel Storage Control Module, click the Chassis Back tab in the top menu to display the back of the system and select the specific storage control module from the system graphic.
Page 128: Figure 69. Intel ® Storage Control Module View
Health/Information icon located on the selected storage control module. ® Figure 69. Intel Storage Control Module View Health Icons The health icons are displayed on the graphical representation of the component when the component is selected.
Page 129: Table 23. Health Icons
In a single SCM configuration, this SCM is the primary controller by default. OK (Secondary) The SCM is operational and this SCM is the secondary controller in a dual SCM configuration. The SCMs have redundancy. ® Intel Modular Server System Service Guide...
Page 130: Table 25. Storage Control Module Action Menu
For a description of these actions, refer to the following table. Table 25. Storage Control Module Action Menu Action Menu Item Description ® Reset Enables remote reset of the selected Intel Storage Control Module. Expansion Port Enable/Disable server access to the external expansion port on the selected storage control module.
Page 131: Intel Management Module
Management Module is replaced. ® ® The Intel Modular Server Control UI enables an IT Administrator to reset the Intel Management Module, view health information, and view product details. To view current ® status, available actions, and product details for the installed Intel...
Page 132: Figure 70. Intel ® Management Module View
® Figure 70. Intel Management Module View Health Icons The health icons are displayed on the graphical representation of the component when the component is selected. ® Intel Modular Server System Service Guide...
Page 133: Table 27. Health Icons
“Events” on page 122.) Information ® Intel Management Module Actions The actions available for a selected management module are displayed to the right of the system graphic. For a description of these actions, refer to the following table. Table 28. Management Module Action Menu...
Page 134: Intel Modular Server Fans And Power Supplies
® Intel Management Module Help ® To quickly access additional help regarding the Intel Management Module screen, actions, and tabs, click on the Get Help button in the Management Module help box located under the actions box. ®...
Page 135: Reports
Displays current sensor information, including fan speed, input/output power, temperature, etc. Reports ® The Intel Modular Server Control generates several standard reports. These reports are used by IT administrators to view overall system health, system configuration information, event logs, diagnostic information, storage resource allocation map, switch performance, and hardware and firmware inventory.
Page 136: Storage Layout
25-GB RAID 0 drive. The second virtual drive is named “Marketing” and is configured as a 30-GB RAID 0 drive. • The virtual drive “Finance” is assigned to Server 1 as Drive 0. The virtual drive “Marketing” is assigned to Server 2 as Drive 0. ® Intel Modular Server System Service Guide...
Page 137: Figure 71. Storage Layout Graphical View
Figure 71. Storage Layout Graphical View ® Intel Modular Server System Service Guide...
Page 138: Events
• Close events: Close individual events by selecting the checkbox next to the event and clicking the Close Selected button. Once an event is closed, it is no longer displayed on this screen. ® Intel Modular Server System Service Guide...
Page 139: Figure 73. System Event Log Screen
Navigate events: If more than 20 events are present, links to additional pages is displayed at the top of the screen next to the Rows drop-down list. Click on the page number to view additional events. Figure 73. System Event Log Screen ® Intel Modular Server System Service Guide...
Page 140: Dashboard
To access the Dashboard view, click the Dashboard tab in the top menu or click Reports > Dashboard in the left navigation panel. This view is displayed by default after successfully ® logging into the Intel Modular Server Control UI. The Dashboard consists of the following five main areas: •...
Page 141: Diagnostics
To access the Diagnostics screen, click Reports > Diagnostics in the left navigation panel. ® Intel Modular Server System Service Guide...
Page 142: Figure 76. Diagnostics
The System Information Report generates a complete report about your system and the system settings (this does not include user account information). Clicking the System Information Report will download the service information, which can be saved or opened as shown in Figure 78 Figure ® Intel Modular Server System Service Guide...
Page 143: Figure 77. Diagnostic Tests
Figure 77. Diagnostic Tests Figure 78. System Information Report Download ® Intel Modular Server System Service Guide...
Page 144: Figure 79. System Information Report
Figure 79. System Information Report ® Intel Modular Server System Service Guide...
Page 145: Settings
I/O performance of a drive by acting as a fast data buffer during large read and write operations. This is a chassis-wide setting, that is, all drive write-back caches are either enabled or all are disabled. ® Intel Modular Server System Service Guide...
Page 146: Storage Redundancy Check Options
Redundancy check does provide the user with an indication that drive information may be suspect. The customer can Enable or Disable Redundancy Check schedule by themselves. ® Intel Modular Server System Service Guide...
Page 147: Ip Configuration
The factory default IP address is 192.168.150.150. The default netmask is 255.255.255.0. ® The IP Configuration screen enables an IT Administrator to change the Intel Management Module host name and external network access, as well as view the internal configuration. The following is a description of the settings and information found in the IP Configuration tab: •...
Page 148: Figure 83. Settings - Ip Configuration
To access the IP Configuration screen, click Settings > IP Configuration in the left ® navigation panel. The Intel Modular Server Control IP Configuration screen similar to the following image is displayed. Figure 83. Settings - IP Configuration ®...
Page 149: Date And Time
The new date and time will be displayed once the management module is reset. Figure 84. Settings - System Date and Time Configuration ® Intel Modular Server System Service Guide...
Page 150: Figure 85. Calendar
The button toggles between the two options. 5. Click Save Changes. In the Update dialogue box Update and Reboot. This action will reset the management module to enable the changes to take effect. ® Intel Modular Server System Service Guide...
Page 151: Simple Network Management Protocol (Snmp)
Intel Modular Server via SNMP. Full hardware ® management and configuration is supported via the Intel Modular Server Control interface. For more information regarding SNMP v2 and SNMP v3 support for the installed Unified Firmware Update (UFU) release, refer to the Unified Firmware Update (UFU) Release Notes.
Page 152: Figure 86. Snmp Options
The first option on the screen in the Agent section is to enable or disable SNMP v2. By ® default, this setting is set to enabled. The Intel Modular Server System supports read- only access to system information via SNMP v2. To use SNMP v3, SNMP v2 does not need to be enabled;...
Page 153: Figure 87. Snmp V3
User Access to either read-only or read-write. With read-only access, an SNMP v3 user account can view system settings remotely. With read-write access, an SNMP v3 user ® account can view system settings remotely and change the Intel Compute Module’s ®...
Page 154: Figure 88. Reset Snmp V3
SNMP v3 user account to remotely configure the Intel Modular Server System. Full ® hardware management and configuration is only supported via the Intel Modular Server Control interface. Note: For more information regarding SNMP v3 support for the installed Unified Firmware Update (UFU), refer to the Unified Firmware Update (UFU) Release Notes .
Page 155: User Accounts
Module Server Control UI for initial configuration. It is ® recommended that the default administrator password is changed before adding the Intel Modular Server System to the production network. The administrator password supports a maximum of 10 characters. Supported characters are limited to letters, numbers and the following special characters ! @ # $ ^ &...
Page 156: Event Policies
To configure an event policy, click Edit for a specific event. The Edit dialog box appears. Use the dialog box to change the severity of a specific event, as well as to select who to notify when the event occurs. ® Intel Modular Server System Service Guide...
Page 157: Figure 91. Settings - Event Policies Configuration Screen
Figure 91. Settings - Event Policies Configuration Screen ® Intel Modular Server System Service Guide...
Page 158: Notification
Notification ® The Notification screen enables an IT administrator to configure the Intel Management Module to send alert messages to users by going through a Simple Mail Transport Protocol (SMTP) email server and to send system events to an external syslog server.
Page 159: Figure 93. Syslog Notification Setting
® Steps to configure the Intel Management Module to forward system events to an external syslog server 1. Click Settings > Notifications in the left navigation panel. 2. Enter the Syslog Server Address. 3. Enter the SysLog server port number.
Page 160: Import/Export
Storage from one chassis and import to a chassis with a similar configuration. Figure 94. Configuration Import /Export Language Option Setting ® The Intel Modular Server Control UI provides the capability to change the language for the on-line help content. Available languages are: •...
Page 161: Feature Activation
This feature requires operating system support for sharing LUNs. ® ® • Intel Modular Server Storage Management Pack Features: With the Intel Modular ® Server Storage Management Pack (Formerly Intel LUN Copier), you will be able to perform many advanced storage operations as below: —...
Page 162: Firmware Updates
— Exporting and importing chassis settings including the storage and switch configuration Steps to activate a feature 1. Obtain a feature activation code or key. Contact your Intel Sales representative for information on how to obtain a key. 2. Click Settings > Feature Activation in the left navigation panel.
Page 163: Figure 97. Settings - Firmware Update Screen
3. Select the file from the console system. File must be accessible from the console system. Refer to the Unified Firmware Update Release Notes for detailed instructions on how to update the system firmware. ® Intel Modular Server System Service Guide...
Page 164: Restore System Settings
This option is only available to the administrative user and only when system settings are actually corrupt. After selecting this option and clicking Apply, the management module will reset. As the management module boots, the settings will be repaired. If this operation is ® Intel Modular Server System Service Guide...
Page 165 “Restore factory defaults” is selected. If restoring from factory defaults, check the user manual for the factory default password (this password is not affected by any prior firmware updates). ® Intel Modular Server System Service Guide...
Page 166: Access Online Help
Access Online Help ® The Help link located at the top right of the banner opens the Intel Modular Server Control Help in a new window. Use the table of contents to quickly access help and tips for specific screens and functions.
Page 167: Troubleshooting
First Steps Checklist ® • Is the power LED lit on all modules installed in the Intel Modular Server System MFSYS25/MFSYS35? • Is the chassis properly connected to an AC power source? • Are the various chassis modules fully seated? —...
Page 168: Chassis Fan Module Not Functioning
• Is the power LED on? If not, re-seat the fan module. If so, check the fault LED. ® • Is the fault LED on? Check the status of the system using the Intel Modular Server Control. • Are both fan modules in error? If so, verify that the power supply modules are properly installed and connected to grounded AC outlets.
Page 169: Cannot Connect A Compute Module To A Storage Control Module
— If so, check the fault LED on the switch module • Is the power fault LED lit on the Ethernet switch module? ® — If so, check the status of the system using the Intel Modular Server Control. — If not, check the switch port link. •...
Page 170: Table 32. Diagnostic Leds
On = Ethernet switch module Module Power of the Ethernet switch module front panel power on module Ethernet Switch Visible fault warning Ethernet switch Amber On = Ethernet switch module Module Fault module front panel fault ® Intel Modular Server System Service Guide...
Page 171: Table 33. Nic Leds
No network connection Solid Amber Network connection in place Blinking Amber Transmit/receive activity Right LED 10 Mbps connection (if Left LED is on or blinking) Solid Amber 100 Mbps connection Solid Green 1000 Mbps connection ® Intel Modular Server System Service Guide...
Page 172 ® Intel Modular Server System Service Guide...
Page 173: A Product Regulatory Requirements
(or higher) speed as the microprocessor used on this server board. The final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative. This is an FCC Class A device. Integration of it into a Class B chassis does not result in a Class B device.
Page 174 GB 17625 - (Harmonics) CNCA Certification (China) Product Ecology Compliance Intel has a system in place to restrict the use of banned substances in accordance with world wide regulatory requirements. A Material Declaration Data Sheet is available for Intel products. For more reference on material restrictions and compliance you can view Intel's Environmental Product Content Specification at http://supplier.intel.com/ehs/...
Page 175: Product Regulatory Compliance Markings
Packaging & Product Recycling Marks Product Regulatory Compliance Markings This Intel Server Chassis product is provided with the following regulatory and safety markings. In the event there is no room for a marking(s) on the chassis, the information is provided here in the product guide.
Page 176 Requirement Country Marking GS Mark Germany CE Mark Europe FCC Marking (Class A) EMC Marking Canada (Class A) VCCI Marking Japan (Class A) ® Intel Modular Server System Service Guide...
Page 177 Intel products. KCC Mark Korea Note: The following symbol is the new Korean EMC mark and is seen on newer Intel products. 于符合中国《子信息品染控制管理法》的声明 Management Methods on Control of Pollution from Electronic Information Products (China RoHS declaration) 品中有毒有害物...
Page 178 Note that some of the component types listed above may or may not be a part of the enclosed product. Belarus Safety Belarus Compliance Mark ® Intel Modular Server System Service Guide...
Page 179 This notice is required by California Code of Information Regulations, Title 22, Division 4.5, and Chapter 33: Best Management Practices for Perchlorate Materials. This product may include a battery which contains Perchlorate material. ® Intel Modular Server System Service Guide...
Page 180 Countries Proper Ground "Apparaten skall anslutas till jordat uttag, när den Outlet ansluts till ett nätverk." "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan." "Connect only to a properly earth grounded outlet." Safety Standy-by power ® Intel Modular Server System Service Guide...
Page 181: Regulated Specified Components
Web site at the following URL: http://channel.intel.com/go/serverbuilder If you do not have access to Intel’s Web address, contact your local Intel representative. 1. Server Chassis: Base chassis is provided with power supply and fans—UL listed. 2. Server board: You must use an Intel server board—UL recognized.
Page 182: Electromagnetic Compatibility Notices
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497 Phone: 1-800-628-8686 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Page 183 Perchlorate Material - special handling may apply. See: http://www.dtsc.ca.gov/hazardouswaste/perchlorate This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This product/part includes a battery which contains perchlorate material. ® Intel Modular Server System Service Guide...
Page 184 33: Best Management Practices for Perchlorate Materials. This product/part includes a battery which contains perchlorate material. BSMI (Taiwan) The BSMI Certification Marking and EMC warning is located on the outside rear area of the product. ® Intel Modular Server System Service Guide...
Page 185 Perchlorate Material - special handling may apply. See: http://www.dtsc.ca.gov/hazardouswaste/perchlorate This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This product/part includes a battery which contains perchlorate material. ® Intel Modular Server System Service Guide...
Page 186 ® Intel Modular Server System Service Guide...
Page 187: B Installation/Assembly Safety Instructions
5. Provide some electrostatic discharge (ESD) protection by wearing an antistatic wrist strap attached to chassis ground of the system-any unpainted metal surface-when handling components. 6. Do not operate the system with the chassis covers removed. ® Intel Modular Server System Service Guide...
Page 188 • Provided with a properly grounded wall outlet. • Provided with sufficient space to access the power supply cord(s), because they serve as the product's main power disconnect. ® Intel Modular Server System Service Guide...
Page 189: Deutsch
Anschlußkabel von den I/O Anschlüssen oder Ports ab. 5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD) über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden. 6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein. ® Intel Modular Server System Service Guide...
Page 190 Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend. ® Intel Modular Server System Service Guide...
Page 191 Telekommunikationsleitungen mit dem Modem bestehen; • "mit einer geerdeten Wechselstromsteckdose ausgerüstet sein; • "über ausreichend Platz verfügen, um Zugang zu den Netzkabeln zu gewährleisten, da der Stromanschluß des Produkts hauptsächlich über die Kabel unterbrochen wird ® Intel Modular Server System Service Guide...
Page 192: Français
Procédez comme suit: 1. Si un cadenas a été installé sur à l'arrière du système, déverrouillez-le et retirez-le. 2. Retirez toutes les vis des panneaux et mettez-les dans un endroit sûr. 3. Retirez les panneaux. ® Intel Modular Server System Service Guide...
Page 193 • "Muni d'une prise murale correctement mise à la terre. • "Suffisamment spacieux pour vous permettre d'accéder aux câbles d'alimentation (ceux-ci étant le seul moyen de mettre le système hors tension). ® Intel Modular Server System Service Guide...
Page 194: Español
Para ello: 1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se ha instalado uno. 2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las tapas. ® Intel Modular Server System Service Guide...
Page 195 • "Provisto de una toma de tierra correctamente instalada. • "Provisto de espacio suficiente como para acceder a los cables de alimentación, ya que éstos hacen de medio principal de desconexión del sistema. ® Intel Modular Server System Service Guide...
Page 196: Italiano
1. Aprire e rimuovere il lucchetto dal retro del sistema qualora ve ne fosse uno installato. 2. Togliere e mettere in un posto sicuro tutte le viti delle coperture. 3. Togliere le coperture. ® Intel Modular Server System Service Guide...
Page 197 • "Dotata di una presa a muro correttamente installata. • "Dotata di spazio sufficiente ad accedere ai cavi di alimentazione, i quali rappresentano il mezzo principale di scollegamento del sistema. ® Intel Modular Server System Service Guide...
Page 198 ® Intel Modular Server System Service Guide...
Page 199: C Safety Information
English Server Safety Information ® ® This document applies to Intel server boards, Intel server chassis and installed peripherals. To reduce the risk of bodily injury, electrical shock, fire, and equipment damage, read this document and observe all warnings and precautions in this guide before ®...
Page 200: Intended Application Uses
To remove power from system, you must unplug the AC power cord from the wall outlet. Your system may use more than one AC power cord. Make sure all AC power cords are ® Intel Modular Server System Service Guide...
Page 201: System Access Warnings
Do not attempt to modify or use an AC power cord if it is not the exact type required. A separate AC cord is required for each system power supply. ® Some power supplies in Intel servers use Neutral Pole Fusing. To avoid risk of shock use caution when working with power supplies that use Neutral Pole Fusing.
Page 202: Rack Mount Warnings
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges. After removing a board from its protective wrapper or from the server, place the board component side up on a grounded, static free surface. Use a ® Intel Modular Server System Service Guide...
Page 203: Other Hazards
Caution: To avoid risk of radiation exposure and/or personal injury: • Do not open the enclosure of any laser peripheral or device • Laser peripherals or devices have are not user serviceable • Return to manufacturer for servicing ® Intel Modular Server System Service Guide...
Page 204: Deutsch
Deutsch Sicherheitshinweise für den Server ® ® Das vorliegende Dokument bezieht sich auf Intel Serverplatinen, Intel Servergehäuse (Standfuß und Rack) sowie installierte Peripheriegeräte. Es enthält Warnungen und Vorsichtsmaßnahmen zur Vermeidung von Gefahren durch Verletzung, Stromschlag, Feuer und Beschädigungen von Geräten. Lesen Sie diese Dokument daher sorgfältig, ®...
Page 205: Zielbenutzer Der Anwendung
Verwenden Sie mechanische oder andere geeignete Hilfsmittel zum Transportieren oder Anheben von Geräten. • Entfernen Sie alle Komponenten, die sich leicht abnehmen lassen, um das Gewicht zu reduzieren und die Handhabung zu erleichtern. ® Intel Modular Server System Service Guide...
Page 206 Typ entspricht. Jedes Netzteil im System muß über ein eigenes Netzkabel angeschlossen werden. Einige Netzteile von Intel Servern verwenden Nullleitersicherungen. Vorsicht ist geboten im Umgang mit Netzteilen, welche Nullleitersicherungen verwenden, um das Risiko eines elektrischen Schlages zu vermeiden Das Netzteil in diesem Produkt enthält keine Teile, die vom Benutzer gewartet werden...
Page 207: Warnhinweise Für Den Systemzugang
Einbauen von Hot-Plug-Komponenten sorgfältig vor, um nicht mit heißen Komponenten in Berührung zu kommen. Vorsicht: Berühren Sie nicht die rotierenden Lüfterflügel, um Verletzungen zu vermeiden. Falls Ihr System mit eine Lüfterabdeckung besitzt, darf es nicht ohne diese Abdeckung betrieben werden. ® Intel Modular Server System Service Guide...
Page 208: Elektrostatische Entladungen (Esd)
Ausbau aus dem Server mit der Bauelementseite nach oben auf eine geerdete, statisch entladene Unterlage.Verwenden Sie dazu, sofern verfügbar, eine leitfahige Schaumstoffunterlage, aber niche die Schutzhülle der Platine. Ziehen Sie die Platine nicht über eine Fläche. ® Intel Modular Server System Service Guide...
Page 209: Andere Gefahren
• Öffnen Sie keinesfalls das Gehäuse von Laser-Peripheriegeräten oder Laser- Komponenten. • Laser-Peripheriegeräte oder -Komponenten besitzen keine für den Benutzer wartungsbedürftigen Teile. • Schicken Sie das Gerät für Wartungsarbeiten an den Hersteller zurück. ® Intel Modular Server System Service Guide...
Page 210: Français
® d’installer ou de mettre à jour votre produit serveur Intel En cas de conflit entre les informations fournies dans ce document et celles livrées avec le produit ou publiées sur le site Web pour un produit particulier, la documentation du produit prime.
Page 211: Sélection D'un Emplacement
• Utilisez l’assistance mécanique ou toute autre assistance appropriée lorsque vous déplacez et soulevez le matériel. • Pour réduire le poids en vue de faciliter la manipulation, retirez tout composant amovible. ® Intel Modular Server System Service Guide...
Page 212 Vous devez les débrancher avant d’ouvrir le châssis, d’ajouter ou de supprimer un composant non connectable à chaud. Les alimentations de certains serveurs Intel sont munies de doubles fusibles pôle/neutre: veuillez observer les précautions d'usage afin d'éviter tout risque d'eléctrocution.
Page 213 Attention: Pour éviter de vous blesser, ne touchez pas les pales de ventilateur en mouvement. Si votre système est fourni avec une protection sur le ventilateur, ne mettez pas le système en route sans la protection en place. ® Intel Modular Server System Service Guide...
Page 214: Décharges Électrostatiques (Esd)
Utilisez si possible un tapi de mousse conducteru, mais pas l’emballage de la carte. Veillez à ce que la carte ne glisse sur aucune surface. ® Intel Modular Server System Service Guide...
Page 215: Autres Risques
Attention: Pour éviter tout risque d’exposition aux rayonnements et/ou de dommage personnel: • N’ouvrez pas l’enceinte d’un périphérique laser. • Les périphériques laser ne sont pas réparables par l’utilisateur. • Retournez-les au fabricant en cas de problème. ® Intel Modular Server System Service Guide...
Page 216: Español
Español Información de seguridad del servidor ® Este documento se aplica a las tarjetas de servidor de Intel , los gabinetes de servidor de ® Intel (montaje en rack y en pedestal) y los dispositivos periféricos. Para reducir el riesgo de daños corporales, descargas eléctricas, fuego y en el equipo, lea este documento y...
Page 217: Selección De La Ubicación
Utilice medios mecánicos u otros que sean adecuados al trasladar o levantar el equipo. • Para que el peso sea menor para manipularlo con más facilidad, extraiga los componentes que sean de fácil extracción. ® Intel Modular Server System Service Guide...
Page 218 CA estén desenchufado antes de abrir le gabinete, agregar o extraer cualquier componente que no es de conexión en funcionamiento. Algunas fuentes de alimentación de electricidad de los servidores de Intel utilizan el polo neutral del fuselaje. Para evitar riesgos de choques eléctricos use precauciones al trabajar con las fuentes de alimentación que utilizan el polo neutral de fuselaje.
Page 219: Advertencias El Acceso Al Sistema
Precaución: Para evitar posibles daños, no toque las aspas en movimiento de los ventiladores. Si el sistema se le ha suministrado con una protección para el ventilador, asegúrese de que cuando esté funcionando el sistema la protección esté en su sitio. ® Intel Modular Server System Service Guide...
Page 220: Descarga Electrostática (Esd)
Utilice una almohadilla de espuma conductora si dispone de ella, pero nunca el envoltorio de la tarjeta. No deslice la tarjeta sobre ninguna superficie. ® Intel Modular Server System Service Guide...
Page 221 Precaución: Para evitar el riesgo de la exposición a radiaciones o de daños personales: • No abra la caja de ningún periférico o dispositivo láser • Los periféricos o dispositivos láser no pueden ser reparados por el usuario • Haga que el fabricante los repare. ® Intel Modular Server System Service Guide...
Page 222 简体中文服务器安全信息本文档适用于 Intel® 服务器主板、Intel® 服务器机箱（基座和机架固定件）和已安装的外设。为减少人身伤害、电击、火灾以及设备毁坏的危险，请在安装或维护 Intel® 服务器产品之前阅读本文档并遵循本指南中的所有警告和预防措施。如果本文档中的信息与特定产品的随附信息或 Web 站点信息之间存在不一致，请以产品文档为准。服务器须由合格的技术人员进行集成和维护。必须遵守本指南的规定和服务器手册的装配指导，以确保符合现有的产品认证和审批。仅使用本指南中描述和规定的指定组件。使用其他产品 / 组件将使产品的 UL 认证和其他管理审批无效，并可能导致产品不符合销售地的产品法规。安全警告与注意事项为避免人身伤害与财产损失，安装本产品之前，请阅读以下所有安全指导和信息。下面所列的安全符号可能在整个文档中使用并可能标注于产品和 / 或产品包装之上。注意表示如果无视此“? ? ? 项”? ? ? ? ? ? ? 轻微人身伤害或财产损失的危险。警告表示如果无视此“? ? ”? ? ? ? ? ? ? 严重人身伤害的危险。...
Page 223 远离振动源或物理震动。 • • 与电气设备产生的强大电磁场隔离。在易受闪电袭击的地区，我们建议将系统插入电涌抑制器并在闪电期间断开通信 • 线路与调制解调器之间的连接。提供正确接地的墙壁插座。 • • 提供足够的空间，以便拿取电源供应线，因为这是本产品的主要电源断开器。设备操作规范减少人身伤害或设备受损的危险：移举设备时遵守当地的职业健康与安全要求。 • 借助机械手段或其他合适的手段移举设备。 • • 拆除一切易分离组件，以降低重量并方便操作。电源与电气警告注意事项电源按钮（如待机电源标记所示）并不能完全关闭系统的交流电源，只要系统已接通电源，就存在 5V 待机电源。要从系统切断电源，须从墙壁电源插座中拔下交流电线。您的系统可能不止使用一根交流电线。请确保所有的交流电线都已拔下。打开机箱或增加或去除任何热插拔组件之前，确保交流电线已拔下。若非所需的确切类型，请勿尝试修改或使用交流电线。系统的每个电源供应设备都需要一根单独的交流电线。本产品的电源供应设备包含非用户维修部件。请勿打开电源供应设备。电源供应设备包含非常危险的电压级、电流级和能量级。请与生产商联系维修事宜。替换热插拔电源供应设备时，请先拔下需替换的电源供应设备上的电源线，再将其从服务器上移除。 ® Intel Modular Server System Service Guide...
Page 224 ⎯ 电源线须拥有适合插座的安全接地插头或触点。 • 电源线为交流电源的主要断开设备。插座须靠近设备并可随时断开。电源线须插入所提供的拥有合适接地的插座。 • 系统使用警告注意事项为避免人身伤害或财产损失，无论何时检查产品内部，以下安全指导都适用：关闭所有与本产品相连的外设。 • 按下电源按钮至关闭状态，关闭系统。 • 从系统或墙壁插座上拔下所有交流电线，断开交流电源。 • • 断开与系统相连的所有线缆和通信线路。卸除舱口盖时，保留所有螺钉及其他紧固件。完成产品内部检查之后，请 • 用螺钉或紧固件重新固定舱口盖。请勿打开电源供应设备。电源供应设备内没有可维修部件。请与生产商联系 • 维修事宜. 增加或替换任何非热插拔组件之前，请关闭服务器电源并断开所有电源线 • 。替换热插拔电源供应设备时，请先拔下需替换的电源供应设备上的电源线 • ，然后再从服务器上移除电源供应设备。注意事项如果服务器一直在运行，任何已安装的处理器和吸热设备都可能很热。除非要增加或移除热插拔组件，否则请待系统冷却后再开盖。为避免在热插拔组件安装过程中接触灼热组件，移除或安装热插拔组件时务须小心。 ® Intel Modular Server System Service Guide...
Page 225 注意事项为避免受伤，请勿触摸运转的风机叶片。如果系统的风机上配有防护装置，请勿卸下风机防护装置运行系统。机架固定件警告设备的机架须固定在稳固的支座上，以防从中安装服务器或设备时倒塌。须按照机架生产商提供的安装说明进行安装。从下往上将设备安装在机架上，最重的设备安装在机架的最底层。一次只从机架上安装一件设备。您须负责安装整个机架装置的主要电源断开设备。此主要断开设备须随时可用，且须标明为控制整个装置（而不仅限于服务器）的电源。为避免潜在的电击危险，须对机架及其上所安装的每一件设备实行正确的安全接地。静电放电 (ESD) 注意事项 ESD 会损坏磁盘驱动器、主板及其他部件。我们建议您执行 ESD 工作站的所有步骤。如果没有 ESD 工作站，则采取一些静电放电保护措施，操作部件时，戴上与服务器上的机箱接地或任何未喷漆金属表面连接的防静电腕带。操作主板时始终保持小心。它们可能对 ESD 非常敏感。拿持主板时只接触边缘。从保护包装中或从服务器上取出主板后，请将主板组件侧面朝上放置在无静电的接地表面上。请使用导电泡沫垫（若有），不要使用主板包装。请勿将主板在任何表面上滑动。 ® Intel Modular Server System Service Guide...
Page 226 其他危险替换电池注意事项不正确替换电池可能导致爆炸危险。替换电池时，请只使用设备生产商推荐使用的电池。请按当地法规处置电池。请勿对电池充电。请勿拆卸、刺穿或以其他方式损坏电池。冷却和气流注意事项按照说明小心布置线缆，尽量减少气流阻塞和冷却问题。为保证适当的冷却和气流，运行系统时请确保机箱盖已安装。未安装机箱盖即运行系统可能导致系统部件受损。安装机箱盖的步骤如下：首先检查并确保系统内没有遗留的未固定工具或部件。 • 检查线缆、内插板和其他组件已正确安装。 • 按产品说明安装机箱盖。 • 激光外设或激光设备注意事项为避免幅射暴露和 / 或人身伤害：请勿打开任何激光外设或激光设备的外壳 • 激光外设或激光设备为非用户维修设备 • 请与生产商联系维修事宜 ® Intel Modular Server System Service Guide...

This manual is also suitable for:

Mfsys35

Intel MFSYS25V2 Service Manual

Preface

Safety Information

Modular Server System Features

Hardware Installations and Upgrades

Using the Modular Server System

Using the Intel Modular Server Control User Interface

Troubleshooting

A Product Regulatory Requirements

B Installation/Assembly Safety Instructions

C Safety Information

Quick Links

Need help?

Questions and answers

Related Manuals for Intel MFSYS25V2

Summary of Contents for Intel MFSYS25V2
