Chapter 1 Product Overview; Technical Specifications - Ruijie RG-AP630 Directional Hardware Installation And Reference Manual

RG-AP630 is a wireless access point (AP) designed by Ruijie for next-generation high-speed wireless LAN. Adhering to
the latest 802.11ac standard, the AP delivers an access rate of up to 1.75Gbps. It features security, radio frequency (RF)
control, mobile access, Quality of Service (QoS), and seamless roaming, and can be managed by RG-WS series wireless
access controllers (ACs) to implement wireless data forwarding, security, and access control.
The IP67 design adapts Ruijie to inclement outdoor environment, for instance, chillness in northern China and humidity in
southern China. This extremely simplifies installation and maintenance. And the built-in directional and omni-directional
Ruijie patent X-sense smart antennas offer flexible antenna switch and full coverage for various outdoor circumstances.
Moreover, the multi-hop and point-to-multi-points bridging enhances the deployment. The AP fed by IEEE
802.3at-compliant PoE accommodates various monitors and receives real-time monitoring information. It is greatly ideal
for campuses, branch offices, ports, transportation, public security, city blocks, complexes, storage and logistics, tourist
attractions, and other sites.

Technical Specifications

Table 1-1 Technical Specifications of RG-AP630
Model
Dimensions
(L×W×H)
Maximum Transmit
Rate
Operating
Frequency
Maximum Transmit
Power
Antenna Type
Antenna Gain
Lobe Width
Interfaces
Fat/Fit Mode
Switching
LED
PoE
Power Consumption <25w

Chapter 1 Product Overview

RG-AP630 (Directional)
276 mm × 246 mm × 90 mm
1.75Gbps
802.11b/g/n: 2.4 to 2.483GHz
802.11ac/a/n: 5.15 to 5.85GHz
27dBm
Integrated directional antenna
2.4GHz: 10dBi
5GHz: 10dBi
2.4G: E:45°: H:60°
5G: E:25°: H:60°
One 10/100/1000 Base-T uplink Ethernet port
One SFP uplink port (combo)
One 10/100/1000 Base-T downlink PoE port
Supported
System status LED
WDS RSSI LED
IEEE 802.3af/at compatible PoE
PSE-capable
RG-AP630 (Omni-directional)
Integrated omni-directional antenna
2.4GHz: 4dBi
5GHz: 4dBi
N/A
