Installing Security Lock (Optional)

The security lock is customer-supplied.
The lock loop on the AP is for your security needs. You can fasten the AP to a fixture as follows:
1) Fasten the cable of a securit
2) Secure the lock plate into th
Figure 3-10 Lock Loop
Connecting Cables

Connecting the grounding cable

The ground ing cable is made on site. Connect the supplied grounding wire (yellow-green) to the AP grounding hole on
one end and ground the wire on the oth
demands.
Figure 3-11 Grounding the AP
y lock to a fixture;
e lock loop.
er end through OT terminals. To avoid waste, adjust the cable length on actual
