Robin SmartView SIP User Manual page 38

C
Settings:
The 'Sensor mode' menu allows you to choose between two optimization profiles. You can choose
between Performance or Quality.
 Performance - The Robin settings will be optimized to achieve the highest possible frame
rate. The video quality will loose some detailing.
 Quality - The Robin settings will be optimized for the best video quality possible. The frame
rate will be limited to approximately 15 frames per second.
The 'Resolution' menu allows you to select the video image resolution. Choose between 'VGA', 'SD'
or 'HD'.
 VGA - The video image will be presented with a vertical resolution of 480 pixels
 SD - The video image will be presented with a vertical resolution of 576 pixels
 HD - The video image will be presented with a vertical resolution of 720 pixels
The 'Sensor aspect' menu allows you to choose the preferred aspect ratio of the video image.
 4x3 - The default aspect ratio
 16x9 - Widescreen
Image:
 Brightness
 Contrast
 Saturation
 Auto gain control
(AGC)
 Fluorescent light
 Auto white balance
(AWB)
gf37
Changes the brightness of the video image
Changes the contrast of the video image
Changes the colour saturation of the video image
'Automatic Gain Control' automatically matches video
image exposure to the light circumstances
Activate this function if artificial light sources in a
room cause interference, e.g. TL strip lighting
'Auto White Balance' automatically matches the
colour temperature of the video image to the circum-
stances
