Page 2: Table Of Contents
Contents 1 Robin Compact parts 2 Function 3 Facilities 4 Systems 5 Installation and programming 6 Fitting 7 Installation dimensions 8 Connection diagram... -
Page 3: Robin Compact Parts
Robin Compact flush-mounting 1 Robin Compact parts The Robin Compact packaging contains the following parts: • Robin Compact external door entry phone with interface • Anti-theft socket screw key • 4 anti-theft screws • 4 plugs • Drilling template •... -
Page 4: Facilities
Robin Compact flush-mounting 3 Facilities The external door entry phone has the following facilities: • The external door entry phone can operate on a hot-line basis, whereby the company switchboard establishes the desired connection when the button on the unit is pressed. -
Page 5: Installation And Programming
Robin Compact flush-mounting Installation and programming The external door entry phone is connected by means of a two-core cable to a device connection point on a company switchboard. This is shown diagrammatically in the connection diagram. The unit can be programmed to operate in 'hotline' or 'auto-dialling' mode. -
Page 6: Fitting
Secure the cable to the plastic box with a tie wrap (see drawing). • Position the Robin in the hole in such a way that the cable fits behind the unit in a loop. • Screw the unit tight with the anti-theft screws provided. -
Page 7: Installation Dimensions
Robin Compact flush-mounting 7 Installation dimensions 31 mm 42 mm Rear view Side view Detail of connection... -
Page 8: Connection Diagram
Robin Compact flush-mounting 8 Connection diagram Connection to an analog port of a PABX. - Page 9 Flemingstraat 50, 1704 SL Heerhugowaard, The Netherlands Tel.: +31 72 534 64 26, Fax: +31 72-534 64 03, www.robin.nl, info@robin.nl...
