Commissioning via operating menu
74
11.6

Configuration of the current outputs

11.6.1 Factory setting of the current outputs for interface
measurements
Current Allocated
output measuring vlaue
1 Interface linearized
1)
2 Level linearized
1) for devices with 2 current outputs
11.6.2

Adjustment of the current outputs

The current outputs can be adjusted in the following submenus:
Basic settings
Setup → Advanced setup → Current output 1 to 2
Advanced settings
Expert → Output 1 to 2 → Current output 1 to 2
See "Description of Device Parameters" GP01000F
4mA value
0% or the corresponding linearized
value
0% or the corresponding linearized
value
Levelflex FMP55 HART
20mA value
100% or the corresponding
linearized value
100% or the corresponding
linearized value
Endress+Hauser
