Levelflex FMP55 HART
Endress+Hauser
6.1.3

Notes on the mechanical load of the probe

Tensile load limit of rope probes
Sensor Feature 060
FMP55 NA, ND
Bending strength of rod probes
Sensor Feature 060
FMP55 CA, CB
Bending strength of coax probes
Sensor Feature 060 Process connection
FMP55 UA, UB Flange
Probe
Rope 4mm (1/6") PFA>316
Probe
Rod 16mm (0.63") PFA>316L
Probe
Coax 316L, Ø 42,4 mm
Mounting
Tensile load limit [kN]
2
Bending strength [Nm]
30
Bending strength [Nm]
300
23
