SSU-2000e Synchronization Supply Unit

and the

SDU-2000e Synchronization Distribution Unit

Technical Reference

Revision E.01 – January 2007

Part Number 12713140-003-2

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the SSU-2000e and is the answer not in the manual?

Questions and answers

Summary of Contents for Symmetricom SSU-2000e

Page 1 SSU-2000e Synchronization Supply Unit and the SDU-2000e Synchronization Distribution Unit Technical Reference Revision E.01 – January 2007 Part Number 12713140-003-2...
Page 2 2300 Orchard Parkway San Jose, CA 95131-1017 U.S.A. http://www.symmetricom.com Copyright © 2006-2007 Symmetricom, Inc. All rights reserved. Printed in U.S.A. All product names, service marks, trademarks, and registered trademarks used in this document are the property of their respective owners.
Page 3: Table Of Contents
SSU-2000e Control Languages ........
Page 4 Set CC Output Parameters ........122 SSU-2000e Technical Reference...
Page 5 ICS Commands ........... . 168 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 6 WHO ............234 SSU-2000e Technical Reference...
Page 7 Clock Module Alarms and Events ........265 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 8 User Changes to Factory Defaults ........319 SSU-2000e Technical Reference...
Page 9 SSU-2000e Shelf Specifications ........
Page 10 Table of Contents SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 11 E1/2048 kHz Output Module Alarm Defaults ......293 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 12 SDU-2000 System Specifications........331 SSU-2000e Technical Reference...
Page 13: How To Use This Guide
Structure of This Guide Conventions Used in This Guide Warnings, Cautions, Recommendations, and Notes Related Documents and Information Where to Find Answers to Product and Document Questions What’s New in This Document 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 14: Purpose Of This Guide
Purpose of This Guide The SSU-2000 Technical Reference describes the programming languages that you can use with the Symmetricom SSU-2000 Synchronization Supply Unit, and contains the alarms and events you can use to troubleshoot the SSU-2000. Who Should Read This Guide This Technical Reference guide contains detailed information and instructions which are intended to be performed by qualified personnel only.
Page 15: Conventions Used In This Guide
Warnings, Cautions, Recommendations, and Notes Warnings, Cautions, Recommendations, and Notes attract attention to essential or critical information in this guide. The types of information included in each are explained in the following examples. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 16 Note: All notes use this symbol. Notes contain installation, operation, or maintenance procedures, practices, conditions, or statements, that alert you to important information, which may make your task easier or increase your understanding. SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 17: Related Documents And Information
Where to Find Answers to Product and Document Questions For additional information about the products described in this guide, please contact your Symmetricom representative or your local sales office. You can also contact us on the web at www.symmetricom.com. What’s New in This Document Revision E.01 contains the following changes and new information:...
Page 18 Table 8-11, and Table 8-12. Corrected the Min and Max Tau Limit and Min and Max Lock Tau values in Table 8-14. Added metric equivalent to Altitude specification in Table 9-1. SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 19: Chapter 1 Overview
Chapter 1 Overview This chapter provides an overview of this guide. In This Chapter SSU-2000e Control Languages 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 20: Ssu-2000E Control Languages
SSU-2000e Control Languages Software embedded in the SSU-2000e hardware allows operators to query and manage an SSU-2000e from a local or remote management terminal using one of three control interfaces. These management agents allow operators to change factory default settings, set or restore stored configuration settings, configure and provision the SSU-2000e to meet the requirements of a unique environment, and perform maintenance and troubleshooting.
Page 21: Module And Software Revision Levels
Chapter 1 Overview SSU-2000e Control Languages Table 1-1. Module and Software Revision Levels Software Revision Hardware Module Part Number Module Name Level Revision level 23413013-001-0 DS1 1-Port Input Module 23413013-002-0 DS1 3-Port Input Module 23413014-001-0 E1 1-Port Input Module 23413014-002-0...
Page 22 Chapter 1 Overview SSU-2000e Control Languages SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 23: Chapter 2 Tl1 Reference
Chapter 2 TL1 Reference This chapter provides detailed information about the Transaction Language One (TL1) that is used to communicate with the SSU-2000e. In This Chapter TL1 Command Interface TL1 Retrieve Commands and Responses TL1 Set Commands Other TL1 Commands 12713140-003-2 Revision E.01 –...
Page 24: Tl1 Command Interface
SSU-2000e using an Ethernet telnet session. To set up an SSU-2000e port for TL1 communications: 1. Log on to one of the SSU-2000e EIA-232 serial ports using a Supervisor-level (or higher) user name and password. 2. Set port A, B, or L to TL1 mode. For example, to set the local port (COML) to TL1...
Page 25: Tl1 Command And Response Conventions
Conventions, on page 26. In-Process Acknowledgment – The in-process acknowledgment (IP) response message is sent in response to a command that the SSU-2000e is unable to respond to within two seconds. For a detailed description of in-process acknowledgment response messages and conventions, see...
Page 26 (Target Identifier) represents the name assigned to the SSU-2000e. The assigned name must be either null or match the name assigned to the SSU-2000e. If the tid is not null, it may must begin with a letter and may contain up to 20 alphanumeric characters see Name, on page 140.
Page 27 The ctag can be any combination of six alpha-numeric characters randomly generated by the user. (General Block) is an field that is not used by the SSU-2000e but that you must indicate by a double colon, that is, by preceding any parameters following the ctag field with double colons (::).
Page 28 (Source Identifier) is the returned ID, and is the same as the tid in the input command message to which the IP acknowledgment is responding is the current year, month, and day in the SSU-2000e in the format: date YY-MM-DD...
Page 29: Denied Response Error Codes
(Source Identifier) is the returned ID, and is the same as the tid in the input command message is the current year, month, and day in the SSU-2000e in the format: date YY-MM-DD. is the current hours, minutes, and seconds timestamp information in the...
Page 30 TL1 Command and Response Conventions Autonomous Report Conventions The SSU-2000e sends autonomous reports in response to a detected alarm condition or status change. You can select one of two formats for autonomous messages: GR-831 or GR-833. Use the RTRV-PRMTR-TL1FORMAT command to select which format is generated.
Page 31 Events, is set to Not Alarmed (NA), then is set to SC when the alarm becomes active and CL condeff when the alarm is cleared. Other terms are identified in this section 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 32: System Security
TL1 command RTRV-INV, or the ICS command CONFIG. The SSU-2000e system software allows you to set up a list of users with one of five access levels; each level has an increasing level of access to system functions and commands.
Page 33: Tl1 Retrieve Commands And Responses
This section contains an alphabetical listing of TL1 retrieve commands, a description of the command which provides the valid aid codes to use in the command, and an example and description of the components of message lines. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 34: Retrieve 2048 Khz Clock Output Parameters
= module access identifier = CLK mode = minimum clock level to enable outputs on the module [ACQ | LOCK] level = [ON | OFF] for allowing Clock C selection bypass SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 35 = module access identifier = squelch value [0 | 1 – 16] and # = port number [1 – 20] squelch# Related Commands Set 2048 kHz Output Parameters, on page 116 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 36: Retrieve Alarm Cutoff
Retrieve Alarm Cutoff This command indicates whether the Alarm Cutoff (ACO) function is active in the SSU-2000e. The command creates a momentary change of state (pulse) on the alarm relay, which allows a specially-built alarm panel to squelch the audio alarm.
Page 37: Retrieve Alarm Elevation Time
[aid] SxAy module. Response Format ^^^"aid:elevtime" <cr lf> where: = module access identifier = alarm elevation time for the specified module elevtime Related Commands Set Alarm Level Parameters, on page 120 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 38: Retrieve Module Alarms
= Condition Type (event number) condtype = service affecting flag [SA | NSA]: SA = service affecting, NSA = srveff non-service affecting occurrence date ocrdat = occurrence time ocrtm = condition description string condstr SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 39 Retrieve Module Alarms Example SSU_2000 06-05-30 14:54:54 100 COMPLD "S1A01:CL,1,NSA,06-05-30,13:47:14:\"Input Ref, Ok\"" "S2A07:CL,4,NSA,06-05-30,13:47:13:\"Clk-C, Ok\"" "S3A09:CL,4,NSA,06-05-30,13:47:13:\"Clk-C, Ok\"" "S3A05:CL,4,NSA,06-05-30,13:47:13:\"Clk-C, Ok\"" "S3A03:CL,4,NSA,06-05-30,13:47;13:\"Clk-C, Ok\"" Related Commands Retrieve Events, on page 56 Retrieve Reports, on page 94 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 40: Retrieve Alarm Parameters
= cleared seconds count for clearing of the alarm. Delay numbers cleardelay are reported only if they are settable for the alarm; otherwise they are reported as IMMED (immediate). Related Commands Retrieve All Alarms, on page 42 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 41: Retrieve Alarm Status
= module or port access identifier = alarm number for that aid almnum = current state of each alarm condition [OK | BAD] status Related Commands Retrieve Alarm Status, on page 41 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 42: Retrieve All Alarms
Retrieve All Alarms Retrieve All Alarms This command reports all active alarms from the SSU-2000e or designated modules or ports with an aid indicating which module or port is generating the alarm. The response is the complied message followed by the alarm report message(s).
Page 43: Retrieve Cc Input Parameters
= priority 1 (highest) through 10 (lowest) or MON for monitor = provisioned priority quality level [1 – 16] = CC, indicating Composite Clock mode = zero suppression [NA] Related Commands 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 44: Retrieve Cc Output Parameters
= module access identifier = CC mode = minimum clock level to enable outputs on the module [WARM | ACQ | level LOCK] = allow Clock C selection: [ON | OFF] bypass SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 45 Line 4 contains: = module access identifier = phase compensation [1 – 7] and # = port number 1 through 20 pcomp# Related Commands Set CC Output Parameters, on page 122 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 46: Retrieve Clock Parameters
= {PRI|PQL} for priority or sync message (PQL) selection of inputs inpsel = minimum tau limit mintaulimit = maximum tau limit maxtaulimit Related Commands Set Clock Parameters, on page 123 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 47: Retrieve Clock Status
= current time constant in seconds for the clock control loop = Stratum Level of the clock = clock frequency offset offset = clock frequency sigma value sigma Example SSU_2000 06-06-13 10:45:11 100 COMPLD "S1A01:SEL,LOCK,9000,2,(3.27E-10),(6.75E-10)" "S1A12:OK,LOCK,1200,2,(1.01E-08),(3.98E-10)" 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 48: Retrieve Communication Parameters
^^^"aid:,,,,tout"<cr lf> where: = communication port [TELNET | TL1] = inactivity timeout period before the session is logged out [value | NEVER] tout Related Commands Set Communication Parameters, on page 126 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 49: Retrieve Configuration
Chapter 2 TL1 Reference Retrieve Configuration Retrieve Configuration This command is replaced with the Retrieve Inventory command. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 50: Retrieve Configuration Date
Response Format "LSTCFGC:ocrdat,ocrtm"<cr><lf> where: is the date of the last configuration change ocrdat is the time of the last configuration change ocrtm Example SSU_2000 06-05-30 14:19:22 100 COMPLD "LSTCFGC:06-05-30,14:14:47" Related Commands SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 51: Retrieve Ds1/E1 Input Parameters
= Cesium fault [HI | LO | OFF | NA] csflt = bit number 4 through 8 of the Time Slot 0 word used for the E1 sync status message Related Commands Set DS1/E1 Input Parameters, on page 128 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 52: Retrieve Ds1/E1 Output Parameters
Line 1 contains: = module access identifier = outputs signal mode: [ESF | D4 | CCS | CAS] mode = minimum clock level to enable outputs on the module [ACQ | LOCK] level SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 53 = line length setting in feet [133 | 266 | 399 | 533 | 655] for all 20 DS1 output len# ports, and is the port number [1 – 20] Related Commands Set DS1/E1 Output Parameters, on page 129 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 54: Retrieve E1/2048 Khz Output Parameters
= bit number [4 – 8] of the Time Slot 0 word used for the E1 sync status message When the aid specfies a module, then the response is four lines as follows: ^^^"aid: mode,bypass,zs,crc,ssm,bit"<cr lf> ^^^"aid:signal1,signal2,signal3,…signal20"<cr lf> ^^^"aid:pstate1,pstate2,pstate3,…pstate20"<cr lf> ^^^"aid:squelch1,squelch2,squelch3,…squelch20"<cr lf> SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 55 = threshold value [0 | 1 – 16] (where 0 = disabled). If the reference squelch# clock PQL exceeds this value, then the output is turned off. # = port number [1 – Related Commands Set E1/2048 kHz Output Parameters, on page 130 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 56: Retrieve Events
= condition type (event number) condtype = service affecting flag [SA | NSA]: SA = service affecting, NSA = srveff non-service affecting = occurrence date ocrdat = occurrence time ocrtm = condition description string condstr SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 57 Example SSU_2000 06-05-30 14:53:56 100 COMPLD "S1A01:NA,147,NSA,06-05-30,14:14:57:\"Output Pql, 2\"" "S1A01:NA,146,NSA,06-05-30,14:14:49:\"Inp Select, 1A05-01\"" "S1A05:NA,193,NSA,06-05-30,14:14:46:\"Priority, 1, TELA\"" "S1A02:NA,158,NSA,06-05-30,14:11:15:\"NTP Mode, CLIENT\"" Related Commands Retrieve Module Alarms, on page 38 Retrieve Reports, on page 94 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 58: Retrieve Frequency Data
= frequency of the port versus clock A freqa = frequency of the port versus clock B freqb Example SSU_2000 06-06-26 13:38:57 100 COMPLD "S1A03-01:(0),(0)" "S1A03-02:(0),(0)" "S1A03-03:(0),(0)" "S1A04-01:(-3),(-31)" "S1A05-01:(5),(-23)" "S1A06-01:(0),(0)" "S1A06-02:(0),(0)" "S1A06-03:(0),(0)" Related Commands SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 59: Retrieve Frequency Parameters
= frequency error for A fatau = frequency error for B fbtau Related Commands Retrieve MTIE Data, on page 76 Retrieve MTIE History, on page 78 Set MTIE Parameters, on page 139 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 60: Retrieve Gps Available Data
= calculated orientation of the satellite azimuth elevation Example SSU_2000 06-05-30 14:40:40 100 COMPLD "S1A05:1,1,H,272,41" "S1A05:2,5,H,76,13" "S1A05:3,14,H,344,62" "S1A05:4,15,H,164,33" "S1A05:5,18,H,98,29" "S1A05:6,19,H,268,11" "S1A05:7,22,H,56,62" "S1A05:8,30,H,110,16" Related Commands Retrieve GPS Data, on page 61 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 61: Retrieve Gps Data
SRC = searching, COD = code locking, FRQ = frequency locking, TIM = setting time, EPH = retrieving Ephemeris data, OK = satellite being used in the timing solution = current 1PPS sigma value pps_sigma = the current 3-sigma threshold t3sigma_threshold 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 62 "S1A03: 2,07,083,OK" "S1A03: 3,13,104,OK" "S1A03: 4,27,066,OK" "S1A03: 5,16,104,OK" "S1A03: 6,23,066,OK" "S1A03: 7,01,104,OK" "S1A03: 8,31,052,OK" "S1A03: 9,19,066,OK" "S1A03:10,25,083,OK" "S1A03:11,,,EMPTY" "S1A03:12,,,EMPTY" "S1A03:PPSSIGMA: 3.60E-17" "S1A03:T3SIGMA: 2.03E-15" Related Commands Retrieve GPS Available Data, on page 60 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 63: Retrieve Gps Input Parameters
= minimum satellite elevation for positioning purposes posel = minimum satellite elevation for timing purposes timel = current pdop mask pdop Related Commands Set GPS Input Parameters, on page 132 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 64: Retrieve Gps Position
If there is no such error, the unit uses the stored position. The SSU-2000e generates an event when the GPS module calculates a new position, and stores the new position in NVRAM as the current position and changes the engine mode to fixed position.
Page 65: Retrieve Header
This command allows you to verify that the SSU-2000e is connected to the computer or network. It may also be used to retrieve the unit name (sid) and date and time. The only action taken by the SSU-2000e is to respond with the complied message.
Page 66: Retrieve Input Data
???clr Related Commands Retrieve Signal Fault Alarm Parameters, on page 102 Set Signal Fault Alarm Parameters, on page 150 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 67: Retrieve Input Reference
If the input port is not a valid reference, the DENY response is returned. Example SSU_2000 06-05-30 14:42:54 100 COMPLD "S1A05-01,AR,PRI" Related Commands Set Input Reference, on page 134 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 68: Retrieve Input Status
= current pql level (read or provisioned) being reported by the port, if available. If pql = 0 , then the pql is not applicable for that port. Example SSU_2000 06-03-08 20:28:19 100 COMPLD "S1A03-01:OK,OK,(-29),(-8),2" "S1A04-01:OK,OK,(-20),(-72),4" "S1A05-01:OK,DIS,NA,NA,4" SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 69: Retrieve Inventory
Chapter 2 TL1 Reference Retrieve Inventory Retrieve Inventory This command returns the inventory management information for the SSU-2000e Syntax RTRV-INV:[tid]::ctag; RTRV-INVENTORY:[tid]::ctag; Response Format The response is the complied message followed by the response message(s). A summary for each module and shelf are returned in the following format: ^^^"aid:desc,hwpart,hwrev,hwserial,swpart,swrev,adapterpart"...
Page 70 "S2A13:Output 2048 kHz,23413159-000-0,C.0,1234567890,14313159-000-5,C.00" "S2A15:Buffer Card,23413122-000-0,B.,990705398000737838,,A.0 " "S2A16:Buffer Card,23413122-000-0,B.,990705398000737708,,A.0 " "3:SDU-2000,25413023-000-0" "S3A05:Output 2048 kHz,23413159-000-0,C.00,1234567890,14313159-000-5,C.00" "S3A06:Output 2048 kHz,23413159-000-0,1,1234567890,14313159-000-5,C.00" "S3A08:Output 2048 kHz,23413159-000-0,1,1234567890,14313159-000-5,C.00" "S3A10:Composite Clock,23413158-000-0,2,123456789000,14313158-000-5,B.01" "S3A11:Output E1,23413018-000-0,D,990705398000650816,14313017-000-5,B.01" "S3A12:Output E1,23413018-000-0,A,1234567890,14313017-000-5,B.b02.5" "S3A15:Buffer Card,23413122-000-0,B.,990705398000737821,,A.0 " "S3A16:Buffer Card,23413122-000-0,B.,990705398000737845,,A.0 " SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 71: Retrieve Ip Parameters
^^^"aaa.aaa.aaa.aaa,mmm.mmm.mmm.mmm,ggg.ggg.ggg.ggg"<cr lf> where: = IP address of the unit aaa.aaa.aaa.aaa = IP mask of the unit mmm.mmm.mmm.mmm = IP gateway of the unit ggg.ggg.ggg.ggg Related Commands Set IP Parameters, on page 135 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 72: Retrieve Keep-Alive Parameters
= TL1 session timer in minutes tl1time = SNMP session timer in minutes. snmptime Times set to zero indicate keep-alive is disabled Related Commands Set Keep-alive Parameter, on page 136 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 73: Retrieve Led
Retrieves all LED data from the shelf. [aid] Retrieves LED data from the specified module. SxAy Refer to the SSU-2000e User’s Guide for a detailed description of each module’s LED indicators. Response Format If the module does not support this command, the DENY response is returned.
Page 74: Retrieve Local Time Offset
Response Format "OFFSET:(+/-hh.mm)"<cr><lf> where: is the date of the last configuration change ocrdat is the time of the last configuration change ocrtm Example SSU_2000 06-0-28 13:31:37 M 100 COMPLD "OFFSET:(-6:00)" Related Commands SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 75: Retrieve Login Events
Login and logout events always appear in the system console. Syntax RTRV-PRMTR-EVTLOGIN:[tid]::ctag; Response Format ^^^"aid:evtlogin"<cr lf> where: = shelf access identifier evtlogin = [ENABLE | DISABLE]. Related Commands Set Login Events 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 76: Retrieve Mtie Data
= time period for the measurement data, given in seconds. The maximum tmper tmper values for MTIE are 0.05, 0.1, 1, 10, 100, 1000, 10000, and 100000 = data value for the time period, in nanoseconds monval SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 77 Retrieve MTIE Data Example SSU_2000 06-05-30 14:49:34 100 COMPLD "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,0.05,30" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,0.10,30" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,1.00,30" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,10.00,30" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,100.00,31" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,1000.00,39" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,10000.00,51" "S1A04-01:06-05-29,14:59:58,MTIE,CLK-A,100000.00,51" Related Commands Retrieve MTIE History, on page 78 Set MTIE Parameters, on page 139 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 78: Retrieve Mtie History
0.05, 0.1, 1, 10, 100, 1000, 10000, and 100000 Example SSU_2000 06-06-26 12:51:44 100 COMPLD "S1A05-01:06-06-21,00:01:00,MTIE,CLK-A,21,21,21,49,57,61,73,79" "S1A05-01:06-06-22,00:01:00,MTIE,CLK-A,11,11,11,20,24,33,40,79" "S1A05-01:06-06-23,00:01:00,MTIE,CLK-A,11,11,11,19,27,30,39,54" "S1A05-01:06-06-24,00:01:00,MTIE,CLK-A,12,12,12,20,26,29,41,54" "S1A05-01:06-06-25,00:01:00,MTIE,CLK-A,9,9,9,19,24,30,40,53" Related Commands Retrieve MTIE Data, on page 76 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 79: Retrieve Mtie Parameters
The third line contains the module or port aidand the clear threshold settings for CL1. The fourth line contains the module or port aid and the clear threshold settings for CL2. Example SSU_2000 06-06-26 15:06:38 100 COMPLD "S1A05-01:MTIE,EL1,260,440,810,880,1600" "S1A05-01:MTIE,EL2,325,550,1010,1100,2000" "S1A05-01:MTIE,CL1,230,400,730,790,1440" "S1A05-01:MTIE,CL2,290,490,910,990,1800" 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 80: Retrieve Name
If no name is assigned to a port, then a null field is returned. ^^^"aid:name" <cr lf> Related Commands Retrieve Header, on page 65 Name, on page 140 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 81: Retrieve Network Element Type
This command serves the same purpose as RTRV-HDR with an element type message added. Syntax RTRV-NETYPE:[tid]::ctag; Response Format ^^^"SSU2000" <cr lf> Related Commands Retrieve Header, on page 65 Retrieve Name, on page 80 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 82: Retrieve Ntp Parameters
NTP ips may be listed. todSource = the preferred TOD source [GPS | CLIENT] Example SSU_2000 06-06-26 15:08:18 100 COMPLD "172.16.21.19,CLIENT" "172.16.21.42,CLIENT" "PREFER:CLIENT" Related Commands Set NTP Parameters, on page 141 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 83: Retrieve Ntp Status
= the system peer’s IP address sysIp = system peer offset sysOffset Example SSU_2000 06-05-30 14:16:58 100 COMPLD "172.16.21.19,(0.002249),(0.004485),(0.125549),1,SERVER" "172.16.21.42,(0.001745),(0.006743),(0.125640),1,SERVER" "SYS:CLIENT,172.16.21.19,(0.001997)" Related Commands Retrieve NTP Parameters, on page 82 Set NTP Parameters, on page 141 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 84: Retrieve Operating Mode
The SUBTENDING mode means that SSU is in ANSI subtending mode. In this mode, the unit chooses an available Composite Clock Input as an input reference. All other inputs shall not be selected as input reference. Related Commands SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 85: Retrieve Output Pql
= module access identifier pql = the Priority Quality Level [0, 1-16]. If the value is 0, the PQL override function is disabled and the output SSM is provided by the SSU-2000e’s PQL. Note: the PQL Override function is not persistent.
Page 86: Retrieve Output Status
DIS or FLT = all outputs are turned off = [NA | SxAy], where: NA = non-redundant, and SxAy = redundant module access identifier = clock generating the output [CLK-A | CLK-B | CLK-C | CLK-D] clksrc SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 87 = port status [1 | 0 | F | S], where 1 = enabled, 0 = disabled, F = faulted or pstate S = squelched for all 20 outputs Related Commands 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 88: Retrieve Password Status
If it returns EXPIRED, the application software shall issue the following two TL1 commands back-to-back to change the password. If the application software fails to do so, the TL1 shall stay in this loop until the completion of password change. SET-USER:[tid]::ctag::PWD,username,password; SET-PWD-CONFIRM:[tid]::ctag::password; SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 89: Retrieve Phase Build-Out Parameters
Chapter 2 TL1 Reference Retrieve Phase Build-Out Parameters Retrieve Phase Build-Out Parameters This command returns the Phase Build-Out (PBO) settings for the SSU-2000e. All Input modules use this setting. Syntax RTRV-PRMTR-PBO:[tid]::ctag; Response Format ^^^"aid:mode" <cr lf> where: aid = ALL...
Page 90: Retrieve Phase Data
= time period of the measurement data, given as xSEC where x = time in s tmper = +/- phase values versus clock for the specified input given in monval nanoseconds enclosed in parentheses SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 91 Only the number of values currently available are returned. Example: SSU_2000 06-05-30 14:50:52 100 COMPLD "S1A04-01:06-05-30,14-48-20,PHA,CLK-A,100,(-23)" Related Commands Set Phase Zero, on page 144 Set Phase Build-Out Parameter, on page 147 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 92: Retrieve Ping
Chapter 2 TL1 Reference Retrieve Ping Retrieve Ping This command allows you to ping a remote host via TCP/IP. Use this command to verify that the SSU-2000e is communicating over a network. Syntax RTRV-PING:::ctag::ip; Parameter Value Description Specifies the host address, given in the ###.###.###.### format, where ### is a number between 0 and 255.
Page 93: Retrieve Reference Parameters
= input reference port designated by the aid port = selected clock source [CLK-A | CLK-B | NA] for outputs clksrc = an input port designated as the bypass Clock C source clockCsrc Related Commands 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 94: Retrieve Reports
= Condition Type (event number) condtype = service affecting flag [SA | NSA]: SA = service affecting, NSA = srveff non-service affecting occurrence date ocrdat = occurrence time ocrtm = condition description string condstr SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 95 Example SSU_2000 06-05-30 14:55:48 100 COMPLD "S1A01:NA,147,NSA,06-05-30,14:14:57:\"Output Pql, 2\"" "S1A01:NA,146,NSA,06-05-30,14:14:49:\"Inp Select, 1A05-01\"" "S1A05:NA,193,NSA,06-05-30,14:14:46:\"Priority, 1, TELA\"" "S1A02:NA,158,NSA,06-05-30,14:11:15:\"NTP Mode, CLIENT\"" Related Commands Retrieve Events, on page 56 Retrieve Module Alarms, on page 38 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 96: Retrieve Rs-422 Output Parameters
= [ON|OFF] for allowing Clock C selection bypass = [ON | OFF | AUTO] if output is set to Fault if signal levels fall below the fltmode threshold output level SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 97 = is the output frequency [0 | 1 |...| 512] where 0 (Reserved) = 4 kHz, 1 = freq# 8 kHz, 2 = 16 kHz...512 = 4096 kHz, and is the port number 1 through 20 Related Commands Set RS-422 Output Parameters, on page 145 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 98: Retrieve Security Log
= the Security Log identification number condType = occurrence date ocrdat = occurrence time ocrtm = condition description string condstr Example SSU_2000 05-10-05 15:49:08 1 COMPLD "1,05-10-04,18-00-47:\"LOGIN,COML,ICS,ADMIN\"" "2,05-10-04,18:01:40:\"LOGIN_FAIL,COML,ICS,ADMIIN\"" "1,05-10-04,18:01:56:\"LOGIN,COML,ICS,ADMIN\"" "4,05-10-04,18:12:11:\"AUTO_LOGOUT,COML,ICS,ADMIN\"" "1,05-10-05,15:41:29:\"LOGIN,ENET,TL1,ADMIN\"" "1,05-10-05,15:48:55:\"LOGIN,COML,ICS,ADMIN\"" SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 99: Retrieve Security Parameters
= the failed login attempt threshold. If zero, user lockout function is faillogin disabled = the user lockout recovery timer in seconds lockout = the password aging setting in days. If zero, the aging function is disabled aging Related Commands 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference...
Page 100: Retrieve Setup Parameters
{value | NEVER}. Some data fields shall be left blank for Telnet parameters is the TL1 or SNMP session timer in minutes. If timer is set to keepalive zero indicate keep alive function is disabled for that session 100 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 101 DS1/E1 Retrieve Output Status Retrieve 2048 kHz Clock Output Parameters 2048 kHz Composite Clock Retrieve CC Output Parameters RS-422 Retrieve RS-422 Output Parameters E1/2048 kHz Retrieve E1/2048 kHz Output Parameters 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 101...
Page 102: Retrieve Signal Fault Alarm Parameters
= setting (in s) for the clear threshold. This value is the number of seconds clcnt that the port must be free of the error condition before the alarm is cleared. Related Commands Set Signal Fault Alarm Parameters, on page 150 102 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 103: Retrieve Snmp Engine Id Parameter
= actual length (in bytes) of the engineid that follows length = the engine ID in hex string format (an example of the hex string: 80 engineid 00 02 59 03 00 A0 6E 0E BD EE) Related Commands 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 103...
Page 104: Retrieve Snmp Mode Parameter
Only alarms cause Traps to be transmitted ALM = All events and alarms cause Traps to be transmitted ALL = Related Commands Set SNMP Mode Parameter, on page 151 104 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 105: Retrieve Snmpv2 Manager List
This command returns the SNMPv2 Manager list. Syntax RTRV-PRMTR-SNMP-MANAGER:[tid]::ctag; Response Format ^^^"ip" <cr lf> where: = the IP address of the assigned SNMP Manager Related Commands Set SNMPv2 Manager Parameters, on page 152 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 105...
Page 106: Retrieve Snmpv2 User List
^^^"readcommunity,level" <cr lf> where: = the assigned Read Community String used by SNMP readcommunity = the access level assigned to that user level Related Commands Set SNMPv2 User Parameter, on page 153 106 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 107: Retrieve Snmpv3 Manager List
RTRV-PRMTR-SNMPV3-MANAGER:[tid]::ctag; Response Format ^^^"ip,username" <cr lf> where: = the assigned SNMPv3 Manager IP address = the assigned SNMPv3 Manager username username Related Commands Set SNMPv3 Manager Parameter, on page 154 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 107...
Page 108: Retrieve Snmpv3 Notification Type
Response Format ^^^"notification" <cr lf> where: = {V2 |V3 | ALL} SNMPv2, SNMPv3, or both types when an event notification occurs Related Commands Set SNMPv3 Notification Parameter, on page 155 108 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 109: Retrieve Snmpv3 User List
Response Format ^^^"username" <cr lf> where: = user identification string used by SNMPv3. No authentication or username privacy key is displayed. Related Commands Set SNMPv3 User Parameters, on page 156 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 109...
Page 110: Retrieve Tdev Data
TDEV are 0.1, 0.3, 0.6, 1.0, 3.0, 6.0, 10.0, 30.0, 60.0, 100.0, 300.0, 600.0, 1000.0, 3000.0, 6000.0, and 10000.0 Only the values available in the interval between the start and stop times are output. 110 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 111 Retrieve TDEV Data Example SSU_2000 06-05-30 14:51:49 100 COMPLD "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,0.10,1.72" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,0.30,0.77" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,0.60,0.52" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,1.00,0.37" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,3.00,0.21" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,6.00,0.16" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,10.00,0.13" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,30.00,0.09" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,60.00,0.10" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,100.00,0.13" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,300.00,0.24" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,600.00,0.90" "S1A04-01:06-05-30,14:00:01,TDEV,CLK-A,1000.00,2.09" Related Commands Retrieve TDEV History Data, on page 112 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 111...
Page 112: Retrieve Tdev History Data
0.1, 0.3, 0.6, 1.0, 3.0, 6.0, 10.0, 30.0, 60.0, 100.0, 300.0, 600.0, 1000.0, 3000.0, 6000.0, and 10000.0 Related Commands Retrieve TDEV Data, on page 110 112 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 113: Retrieve Tl1 Format
^^^"format" <cr lf> where: = format of the autonomous report [GR831 | GR833] format Example SSU_2000 06-03-08 20:34:25 100 COMPLD "GR831" Related Commands Set TL1 Format Parameter, on page 157 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 113...
Page 114: Retrieve User List
= [ALIVE | EXPIRED] passwordState = the number of days before the passwordState changes to passwordDaysleft EXPIRED = whether the username is locked from access to the system [YES | lockout 114 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 115: Tl1 Set Commands
The TL1 set commands allow you to set data and time or parameters for the SSU-2000e. The unit responds to set commands with a complied message or a deny message that indicates the cause for the failure. There is no response message line for the set commands.
Page 116: Set 2048 Khz Output Parameters
0 | 1-16 exceeds the squelch threshold specified in this field. 0 disables the function. Empty fields leave parameters unchanged. Related Commands Retrieve 2048 kHz Clock Output Parameters, on page 34 116 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 117: Set Active Clock
A/R is on, the DENY response is returned. Syntax SET-CLK:[tid]:[aid]:ctag; Parameter Value Description Sets the specified Clock module as the active clock. [aid] S1A1 S1A12 Related Commands Retrieve Clock Status, on page 47 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 117...
Page 118: Set Alarm Cutoff
This command activates the Alarm Cutoff (ACO) function. The ACO remains active until a new alarm is reported, or an existing alarm is elevated. Syntax SET-ACO:[tid]::ctag; Related Commands Retrieve Alarm Cutoff, on page 36 118 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 119: Set Alarm Elevation Time Parameters
SxAy Sets the time after which an alarm is elevated to the next elevtime 0 | 60 - severity level. 500000 Related Commands Retrieve Alarm Elevation Time, on page 37 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 119...
Page 120: Set Alarm Level Parameters
Specifies the clear delay time, which is the number of clrcnt error-free seconds after the alarm condition is cleared before the alarm indication is cleared. Related Commands Retrieve All Alarms, on page 42 120 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 121: Set Cc Input Parameters
Sets the priority quality level of the specified module [or 1 - 16 port]. Turns zero suppression on or off for the specified module ON | OFF [or port]. Related Commands Retrieve CC Input Parameters, on page 43 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 121...
Page 122: Set Cc Output Parameters
[or port], where 0 = No compensation and 8 = 2200 ft. The resolution of pcomp values is 275 ft. Empty fields leave parameters unchanged. Related Commands Retrieve CC Output Parameters, on page 44 122 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 123: Set Clock Parameters
ST2E tau range = [300–10 000] ST3E tau range = [150–1200] TYPEI tau range = [150–1200] Empty fields leave parameters unchanged. Related Commands Retrieve Clock Parameters, on page 46 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 123...
Page 124: Set Clock Autoreturn
The command sets the clock mode of returning or not returning after faults are cleared. The parameter changes the active Clock module selection mode to [ON | OFF] for revertive or non-revertive operation. See the SSU-2000e User’s Guide for more information on revertive and non-revertive operation. Syntax SET-CLK-AR:[tid]::ctag::ar;...
Page 125: Set Clock Mode
Sets the specified Clock module to the Holdover mode. HOLD If you do not specify an aid, then the mode of both Clock modules changes. Related Commands Retrieve Clock Status, on page 47 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 125...
Page 126: Set Communication Parameters
Sets the mode of communication. mode ASCII | Sets the inactivity timeout period in seconds. tout 5 – 43200 | NEVER Empty fields leave parameters unchanged. Related Commands Retrieve Communication Parameters, on page 48 126 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 127: Set Date And Time
UTC, then use a negative number. The valid range is +/– 13 hours. Response The SSU-2000e clock is set to the received date and time and a complied message is returned, with the new date/time in the header. Related Commands...
Page 128: Set Ds1/E1 Input Parameters
Sets the bit number of the Time Slot 0 word used for the 4 - 8 E1 SSM. For DS1 input, the bit value is ignored. Empty fields leave parameters unchanged. Related Commands Retrieve DS1/E1 Input Parameters, on page 51 128 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 129: Set Ds1/E1 Output Parameters
Sets the bit number of the Time Slot 0 word used for the 4 - 8 E1 SSM. Empty fields leave parameters unchanged. Related Commands Retrieve DS1/E1 Output Parameters, on page 52 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 129...
Page 130: Set E1/2048 Khz Output Parameters
Sets the bit number of the Time Slot 0 word used for the 4 - 8 E1 SSM. Empty fields leave parameters unchanged. Related Commands Retrieve E1/2048 kHz Output Parameters, on page 54 130 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 131: Set Frequency Alarm Threshold Parameters
Sets the frequency error tau, the period (in seconds) for fbtau 10 - 1000 the frequency to be calculated for input versus B clock. Empty fields leave parameters unchanged. Related Commands Retrieve Frequency Parameters, on page 59 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 131...
Page 132: Set Gps Input Parameters
10 - 1000 Related Commands Retrieve GPS Data, on page 61 Retrieve GPS Available Data, on page 60 Retrieve GPS Input Parameters, on page 63 Retrieve GPS Position, on page 64 132 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 133: Set Gps Position
Sets the minimum satellite elevation level in degrees [timel] 0 to 50 for timing. Related Commands Retrieve GPS Data, on page 61 Retrieve GPS Available Data, on page 60 Retrieve GPS Input Parameters, on page 63 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 133...
Page 134: Set Input Reference
This command sets the current input reference to the designated input port. If the input port is not a valid reference, then the DENY response is returned. This command also sets the reference selection mode. For more information on reference switching, see “Setting the Reference Switching Mode” in the SSU-2000e User’s Guide. Syntax SET-INPUT-REF:[tid]::ctag::port[,swtmode][,selmode];...
Page 135: Set Ip Parameters
This command sets the Internet Protocol parameters. Syntax SET-PRMTR-IP:[tid]::ctag::[addr],[mask],[gate]; Parameter Format Description Sets the IP address of the SSU-2000e. addr Sets the IP mask of the SSU-2000e. mask Sets the IP gate of the SSU-2000e. gate All IP address values are in the ###.###.###.### format.
Page 136: Set Keep-Alive Parameter
Set Keep-alive Parameter Set Keep-alive Parameter This command supports a "keep-alive” mode in which, based upon a user settable time, the SSU-2000e generates an event to alert an upstream support system that the SSU-2000e and associated communication path is functional. Syntax SET-PRMTR-KEEPALIVE:[tid]::ctag::[tl1_time],[snmp_time];...
Page 137: Set Login Events
Login and logout events always appear in the system console. Syntax SET-PRMTR-EVTLOGIN:[tid]::ctag::evtlogin; Parameter Value Description Enables login and logout events to be stored in the evtlogin ENABLE | event log. DISABLE Related Commands Retrieve Login Events, on page 75 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 137...
Page 138: Set Mtie Mask
Each option selects a specific predefined MTIE mask mask G811 G823 Related Commands Retrieve MTIE Data, on page 76 Retrieve MTIE History, on page 78 Set MTIE Parameters, on page 139 138 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 139: Set Mtie Parameters
CL1 | CL2 Sets the error limits in ns for the measurement time t10, period. t100, t1k, Range = [0 – 60000] t10k, t100, Related Commands Retrieve MTIE Parameters, on page 79 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 139...
Page 140: Set Name
Sets the specified module [or port] to the name specified SxAy[-z] in [name] Defines the name for the device specified in [aid] name up to 20 characters Related Commands Retrieve Name, on page 80 140 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 141: Set Ntp Parameters
Selects the time-of-day source in the SSU from GPS or prefer GPS | an NTP client. CLIENT Related Commands Retrieve NTP Parameters, on page 82 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 141...
Page 142: Set Operating Mode
SUBTENDING = SSU is in ANSI subtending mode. In this mode, the unit chooses an available Composite Clock Input as an input reference. All other inputs shall not be selected as input reference. Related Commands Retrieve Operating Mode, on page 84 142 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 143: Set Output Pql
Sets the output PQL for the specified module. SxAy Defines the output pql for the specified module. 0 | 1 - 16 Related Commands Retrieve Output PQL, on page 85 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 143...
Page 144: Set Phase Zero
Sets the phase value for the specified Clock module to clksrc CLK-A | zero. If not specified, phase values for both Clock CLK-B modules are set to zero. Related Commands Retrieve Phase Data, on page 90 144 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 145: Set Rs-422 Output Parameters
1 = 8 kHz, 2 = 16 kHz ... 512 = 4096 kHz. The resolution is 8 kHz per step. Empty fields leave parameters unchanged. Related Commands Retrieve RS-422 Output Parameters, on page 96 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 145...
Page 146: Set Password Confirm
Specifes a password, up to 20 characters long. This must password exactly match the password parameter used in the SET-USER command. Related Command Set User Parameters , on page 158 146 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 147: Set Phase Build-Out Parameter
NONE – enables the PBO function. The PBO event is neither displayed nor stored in the COMM module event buffer. Related Command Retrieve Phase Build-Out Parameters, on page 89 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 147...
Page 148: Set Security Parameters
Sets the number of days that the password is valid. After aging 0 | 10 - this time has elapsed, the user must create a new password. 0 disables the feature. Related Commands Set User Parameters, on page 158 148 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 149: Set Setup Parameters
Reloads the previously saved configuration. User Stores the current configuration. Save Related Command Retrieve Configuration Date, on page 50 Backing Up and Restoring the Configuration, on page 160 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 149...
Page 150: Set Signal Fault Alarm Parameters
For CC input modules and ports, only the LOS and BPV commands apply; AIS, CRC, and OOF commands are denied. Related Commands Retrieve Signal Fault Alarm Parameters, on page 102 150 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 151: Set Snmp Mode Parameter
ALM – Only alarms cause Traps to be transmitted. trap ALM | ALL ALL – All events and alarms cause Traps to be transmitted. Related Commands Retrieve SNMP Mode Parameter, on page 104 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 151...
Page 152: Set Snmpv2 Manager Parameters
INIT – Clears all entries in the manager table. Does not require an IP address Specifes an IP address for the ADD and DEL mode values. Related Commands Retrieve SNMPv2 Manager List, on page 105 152 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 153: Set Snmpv2 User Parameter
Specifes a user name. community Specifies a password for the rdcommunity. community Specifies the user level. Defaults to 1 if not specified. level Related Commands Retrieve SNMPv2 User List, on page 106 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 153...
Page 154: Set Snmpv3 Manager Parameter
Does not require any other fields. Specifes an IP address for the ADD and DEL mode values. Specifies a user in the SNMPv3 manager table. username Related Commands Retrieve SNMPv3 Manager List, on page 107 154 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 155: Set Snmpv3 Notification Parameter
V2 – Sets v2 notification type. notifica- V2 | V3 tion V3 – Sets v3 notification type. All – Sets both v2 and v3 notification type. Related Commands Retrieve SNMPv3 Notification Type, on page 108 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 155...
Page 156: Set Snmpv3 User Parameters
The following is an example which adds a user to the v3 table with a Progress Code (assume the cTag is 100). SSU_2000 06-08-28 20:28:21 100 COMPLD IP 100 <; Related Commands Retrieve SNMPv3 User List, on page 109 156 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 157: Set Tl1 Format Parameter
Sets the response format as described by the specified mode GR831 | standard. GR833 Autonomous Report Conventions, on page 30, for more information. Related Commands Retrieve TL1 Format, on page 113 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 157...
Page 158: Set User Parameters
1 - 4 You must issue the SET-PWD-CONFIRM command immediately after issuing this command with the ADD, PWD, or TMP mode parameter. Related Commands Set Password Confirm, on page 146 158 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 159: Other Tl1 Commands
Ethernet session to end TL1 communication. RMV-MODULE:[tid]:aid:ctag; Valid aid code: SxAy This command removes configuration information for the specified module from the database of the SSU-2000e. RST-MODULE:[tid]:aid:ctag; Valid aid code: SxAy This command restarts (reboots) the specified module.
Page 160: Backing Up And Restoring The Configuration
Response: "\"172.16.20.246, SSUCONFIG\"" "\"CONFIGURATION BACKUP, PLEASE WAIT\"" "\"1A01 SIZE= 624\"" "\"1A02 SIZE=5272\"" "\"1A06 SIZE=3072\"" "\"1A08 SIZE=1200\"" "\"1A10 SIZE=1224\"" "\"1A12 SIZE= 624\"" "\"CONFIG IMAGE CREATED, SIZE=13788\"" SSU_2000 05-10-31 20:11:43 100 COMPLD 160 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 161 "\"1A01 DATA IS SAME AS STORED\"" "\"1A02 SIZE=5272, PASS\"" "\"1A06 SIZE=3072, PASS\"" "\"1A08 SIZE=1224, PASS\"" "\"1A10 SIZE=1224, FAIL\"" "\"1A12 DATA IS SAME AS STORED\"" SSU_2000 05-10-31 20:12:26 100 COMPLD Example 4: Restore Failed Input: CPY-MEM:::TP1000::,172.16.20.200; 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 161...
Page 162 Chapter 2 TL1 Reference Backing Up and Restoring the Configuration Response: "\"172.16.20.200, SSUCONFIG\"" "\"CONFIGURATION RESTORE, PLEASE WAIT\"" "\"RESTORE CONFIGURATION FAILED, TFTP CONNECTION ERROR\"" SSU_2000 05-11-01 15:42:19 100 DENY SDNR 162 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 163: Chapter 3 Ics Command Reference
Chapter 3 ICS Command Reference This chapter provides detailed information about the Interactive Command Set (ICS) control language you can use to communicate with the SSU-2000e. In This Chapter Overview General Conventions ICS Commands 12713140-003-2 Revision E.01 – January 2007...
Page 164: Overview
Overview The Interactive Command Set (ICS), also called the ASCII command set, can be used to control the SSU-2000e from a terminal connected to one of the SSU-2000e EIA-232 serial ports. This chapter describes ICS command conventions, the prompts, line editing functions, and command syntax for ICS commands.
Page 165: Ics Prompts
Chapter 3 ICS Command Reference ICS Prompts ICS Prompts ICS uses the SSU-2000e name followed by command prompt. The prompt is either +> -> prompt indicates that the last output string is an event. +> prompt indicates that the last output string is a response to a command or ->...
Page 166: Command Syntax
Shows any commands related to this command. This command may affect other commands or be affected by other commands. Restrictions Special restrictions on the use or operation of this command. 166 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 167 CLK-A = Clock A, 1A1 CLK-B = Clock B, 1A12 2BUF-A = Shelf 2, Buffer A, 2A15 2BUF-B = Shelf 2, Buffer B, 2A16 3BUF-A = Shelf 3, Buffer A, 3A15 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 167...
Page 168: Ics Commands
Remarks and comments about the command operation Related Commands lists other commands that may affect or be affected by the command. Restrictions describes any special restrictions on the use or operation of the command. 168 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 169: Alarm
Sets the MAJOR alarm relay/LED MAJOR Sets the CRITICAL alarm relay/LED CRITICAL Level 3 Same as Level 2 operation, with the following additions: ALARM xAy[-z] # DELAY time ALARM xAy[-z] # {IGNORE|REPORT|MINOR|MAJOR|CRITICAL} ALARM ACO 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 169...
Page 170 (pulse) on the alarm relay, which allows a specially-built alarm panel to squelch the audio alarm. Alarm panels that do not have this capability ignore the pulse. Contact your Symmetricom representative for further details on this alarm panel. Level 4 Same as Level 3 operation.
Page 171: Bye
Same as Level 1 operation Level 4 Same as Level 1 operation Remarks This command implies that you have completed the session and want to return the SSU-2000e to an Idle state. Related LOGIN RestrictionsNone 12713140-003-2 Revision E.01 – January 2007...
Page 172: Clk
Same as Level 1 operation, with the following additions: CLK xAy MODE {ACQUIRE|LOCKED|HOLD} CLK xAy SELECT Options are: MODE {ACQUIRE|LOCKED|HOLD} Sets the current PLL operation parameters. Forces re-acquisition of the software PLL loop. ACQUIRE 172 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 173 CLK [xAy] WARMUP value CLK [xAy] {MINTAU|MAXTAU} value Options are: Enables or disables the clock autoreturn mode (see the AR {ON|OFF} SSU-2000e User’s Guide for information on autoreturn). Sets the clock warm up time in seconds. WARMUP Sets the minimum tau value. MINTAU Sets the maximum tau value.
Page 174: Cls
Level 2 Same as Level 1 operation. Level 3 Same as Level 1 operation. Level 4 Same as Level 1 operation. Remarks This command is for aesthetic purposes only. RestrictionsNone 174 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 175: Comm
Same as Level 2 operation, with the following additions: COMM {L|A|B} MODE {ASCII|TL1} COMM {L|A|B|TELNET|TL1} TIMEOUT {[5-43200]|NEVER} Use this option to change the settings for the specified communications port. The setup changes are stored in non-volatile RAM. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 175...
Page 176 Level 4 Same as Level 3 operation Remarks None Related None RestrictionsBAUD, ECHO, AND EOL are only applicable to EIA-232. To set any parameter, the communications port must be specified . 176 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 177: Config
Chapter 3 ICS Command Reference CONFIG CONFIG Use this command to view the current hardware configuration of the SSU-2000e. Level 0 Not applicable Level 1 CONFIG [xAy] If you do not provide parameters, the current hardware inventory displays with each slot on one line (concise information). If you provide parameters, more detailed hardware and software inventory management information displays in multiple lines (detailed information).
Page 178 Level 4 Same as Level 3 operation, with the following additions: CONFIG {BACKUP|RESTORE} ipAddress filename Options are: Stores the entire SSU-2000e configuration to the specified BACKUP server and filename via TFTP protocol. Restores the entire SSU-2000e configuration from the RESTORE specified server and filename via TFTP protocol.
Page 179 2A03 Output DS1 14113017-000-0 A.06 19APR01 2A04 Output DS1 14113017-000-0 A.06 19APR01 2A05 Output E1 14113017-000-0 A.06 19APR01 2A08 Output Comp Clock 14113158-000-0 A.02 09OCT00 2A09 Output Comp Clock 14113158-000-0 A.02 09OCT00 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 179...
Page 180: Date
Same as Level 2 operation, with the following additions: DATE yyyy-mm-dd Use this option to set the current date. Level 4 Same as Level 3 operation Remarks None Related TIME, RestrictionsNone 180 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 181: Doy
Remarks This command displays the current day of the year and the year in the unit. Related DATE, LOGIN, USERS RestrictionsThis command is always hidden and does not display in the online Help. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 181...
Page 182: Elevtime
1A03 elevation time is 86400 seconds 1A04 elevation time is 86400 seconds 1A05 elevation time is 86400 seconds 1A08 elevation time is 86400 seconds 1A09 elevation time is 86400 seconds 182 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 183: Engine
Antenna latitude. The decimal point determines the input format. For example, the format is dd:mm:ss.ss for entering 30:27:49.8 seconds. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 183...
Page 184 Sets the current Position Dilution of Precision or pdop mask PDOP (1 through 10). Pdop is a measurement that indicates the geometry of the GPS satellites that the SSU-2000e is tracking. Lower values indicate better geometry. Provides tracking information for the engine. Available...
Page 185 Lat: +30:27:15.89, Lon: -097:39:45.88, Ht: 230.81 m (3D) PDOP: 2.7, 300 ave GPS Module: 1A05 GPS MOT Engine: 2.2, APR 24 1998 Lat: +30:27:15.75, Lon: -097:39:45.85, Ht: 233.43 m (3D) PDOP: 2.8, 10 ave 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 185...
Page 186: Events
Start time and stop time default to the current time of day. Stop date defaults to the current date. Start date defaults to the current date, minus 24 hours. 186 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 187 Allows Login and Logout events to be stored in the event LOGIN log. Level 4 Same as Level 3 operation Remarks Events are stored in non-volatile memory. They are retained on startup. Related ALARM RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 187...
Page 188: Frequency
Same as Level 1 operation Remarks None Related INPUT, PHASE RestrictionsNone Example SSU_2000->FREQUENCY 1A04-01 FreqA:2001-06-18T20:54:19, 0 1A04-02 FreqA:2001-06-18T20:54:19, 1 1A04-03 FreqA:2001-06-18T20:54:19, 1 1A09-01 FreqA:2001-06-18T20:54:19, 3 1A09-02 FreqA:2001-06-18T20:54:19, 2 1A09-03 FreqA:2001-06-18T20:54:19, 1 188 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 189: Help
Level 4 commands: ALARM COMM CONFIG DATE ELEVTIME ENGINE EVENTS FREQ HELP INFO INPUT IONAME KEEPALIVE MTIE NAME OUTPUT PHASE PING PQLTABLE RESET RESTART SETUP SNMP STATUS SYSTIME TDEV TIME USERS 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 189...
Page 190 This is different from the NAME command in that the NAME information is settable by the user. The unit ID is also returned on any status type command. Related NAME RestrictionsNone Example SSU_2000->ID Unit ID: SSU2000 190 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 191: Info
Same as Level 0 operation Level 3 Same as Level 0 operation Level 4 Same as Level 0 operation Remarks This command displays all service information available for the unit. Related RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 191...
Page 192: Input
/ / / / 1A08-01 Dis NA / / / / GPS STATUS Loc# Sta PhaseA PhaseB Pql UTC ------- --- -------- -------- --- --- 1A03-01 Ok -143 -145 1A05-01 Ok -149 -149 192 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 193 1 = highest priority, and 10 = lowest priority. For use with all Input modules. Enables the specified input port on a DS1, E1, CC, or Sine ENABLE Input module. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 193...
Page 194 Sets Frequency limits on Clock A or Clock B. For use with the DS1, E1, GPS, or Sine Input module. Sets Frequency Error Count Sets Frequency Clear Count Set frequency tau (default is 400), range is 10 to 1000 194 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 195 Chapter 3 ICS Command Reference INPUT Level 4 Same as Level 3 operation Remarks None Related SETUP, STATUS RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 195...
Page 196: Ioname
Level 4 Same as Level 3 operation Remarks None Related None RestrictionsCLR is an operand, and cannot be used as an I/O port name. 196 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 197 Communications Module in order for the changes to take effect. Related None RestrictionsThe IP address is in the decimal dotted address format (for example, 192.168.70.224). No name server is allowed. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 197...
Page 198: Keepalive
KEEPALIVE Use this command to enable a “keep-alive” mode that generates a recurring event, based on a user settable time, to alert the upstream support system that the SSU-2000e and associated communication path is functional. Level 0: Level 1: KEEPALIVE Displays the “keep-alive”...
Page 199: Login
Remarks Use this command to access various levels of the system. This is the only way to change access levels for a port. If you lose the password, contact Symmetricom Global Services to generate a new one. There is a GUEST entry, with a null password, that is always present to gain access to Level 1.
Page 200: Msg
Level 3 Same as Level 2 operation Level 4 Same as Level 3 operation Remarks The string must be entered Related None RestrictionsNone 200 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 201: Mtie
ISO timestamp format, and must be separated by a space. Starttime and stoptime both default to the current time of day. Stopdate defaults to the current date. Startdate defaults to the current date, minus 24 hours. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 201...
Page 202 The MTIE ( 1000.00 sec) is 13 The MTIE ( 10000.00 sec) is 22 The MTIE (100000.00 sec) is 22 2001-06-25T18:20:49 1A05 Rep Pos Set by Rec, Information Locked, TL1A 202 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 203: Name
Valid names must start with a letter. If TL1 is to be used, care must be taken in the assignment of the unit name as it is the Target Identification (TID) for that mode. RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 203...
Page 204: Ntp
Chapter 3 ICS Command Reference Use this command to provide access to the NTP (Netswork Timing Protocol) parameters in the SSU-2000e. NTP can run as a server application, a client application, and in broadcast mode. The server always runs and the client and broadcast modes are enabled independently by assigning an address and setting a timer.
Page 205 Client dispersion: 0.001953 Server offset: 0.00390625 Server delay: 0.000000 Server dispersion: 0.127929 Valid Timeserver: Passed BROADCAST: 172.16.21.255 NTP Setup 2005-05-19T18:25:33Z ID: SSU2000, Name: SSU_2000 CLIENT: 172.16.21.18 BCLIENT: 172.16.21.19 BROADCAST: 172.16.23.255, Timer 64 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 205...
Page 206: Opermode
The above options are: puts the unit into normal TSG operation NORMAL puts the unit into ANSI subtending mode SUBTENDING This option is not applicable to the SSU-2000e JAPANESE Perform a special operation to sync a reference clock to SYNC Clock C.
Page 207: Output
OUTPUT xAy LEVEL {ACQ|LOCK} OUTPUT xAy BYPASS {ON|OFF} OUTPUT xAy-z[&&z] {133FT|266FT|399FT|533FT|655FT} OUTPUT xAy {CRC|ZS} {ON|OFF} OUTPUT xAy SSM {ON|OFF} OUTPUT xAy SSM {4|5|6|7|8} OUTPUT xAy-z[&&z] DUTYCYCLE {63/37|50/50} OUTPUT xAy-z[&&z] COMPENSATE {275ft|550ft|825ft|1100ft|1375ft| 1650ft|1925ft|2200ft} 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 207...
Page 208 For CC Output module. Allows the user to turn the output on or off when the output FLTMODE level exceeds 2.1v threshold. For 2048 kHz and RS-422 Output modules. 208 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 209 PQL override (1-16). If zero, PQL override is disabled. For E1/2048, E1, and DS1 Output modules. Level 4 Same as Level 3 operation Remarks None Related ALARM, ELEVTIME, SETUP, STATUS RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 209...
Page 210: Pbo
PBO Enabled, the PBO events sent out and displayed, but EVENT not stored in the COMM event buffer PBO Enabled, but no PBO events displayed NONE Level 4: Same as level 3 operation Remarks None Related INPUT, PHASE RestrictionsNone 210 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 211: Phase
Level 3 Same as Level 2 operation Level 4 Same as Level 3 operation Remarks None Related STATUS, INPUT RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 211...
Page 212: Ping
Same as Level 2 operation Level 4 Same as Level 2 operation Remarks No name server is available. The Internet Protocol (IP) address is formatted as a decimal dotted address. Related None RestrictionsNone 212 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 213: Pqltable
Use this option to set or clear this entry as the standard STD {ON|OFF} input type. Only standard entries are matched for input. Level 4 Same as Level 3 operation Remarks None Related None 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 213...
Page 214 Type IV 0x22 0x0B s G.813 Opt1 0x22 s SMC 0x0F G.813 Opt2 0x28 s St4 0x0F 0x40 s Reserved 0x0F 0x30 s DUS 0x0F s DUS 0x7E Unassigned 0x0F Unassigned 214 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 215: Ref
Note: Input reference selection order proceeds from highest (1) to lowest (10) priority valid input port. If the inputs have equal Priority level, the PQL value is used to distinguish between them. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 215...
Page 216 Same as Level 3 operation Remarks None Related INPUT, CLK, STATUS RestrictionsNone Example SSU_2000->ref 2001-06-18T21:29:56Z ID: SSU2000 Name: SSU_2000 Input Reference: 1A03-01 Bypass Clock C Selected: 1A04-01 Clock Selected: 1A01 216 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 217: Reset
RestrictionsThis command uses the COMM module PLD’s CLK A/B reset bit to reset the clock module. The software is required to hold the RESET bit for at least for 4 seconds and then writes a zero for that RESET bit. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 217...
Page 218: Restart
RESTART command support. This command assumes that the target module is working properly. If the target module does not work, this command has no effect. Note: This command does not work on the Buffer module. 218 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 219: Security
Chapter 3 ICS Command Reference SECURITY SECURITY This command provides the security interface to the SSU-2000e. This command works with the USERS command to allow an Administrator-level user to change passwords, to query the security log, set the login failed attempts threshold, set the user lockout timer, and set the password aging timer.
Page 220: Setup
SETUP 1A2 CONNECTION FACTORY Options are: Use this option to restore the current setting from the FACTORY factory settings. If addressed as COMM, connection and user list are not included. 220 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 221 RAM with the current program defaults and transfers those setting into non-volatile RAM as the new factory settings. Related INPUT, CLK, OUTPUT, EVENTS, ALARM RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 221...
Page 222: Snmp
SNMP notification sent out in V2, V3, or both NOTIFICATION Level 4: Same as level 3 operation, with the following additions: SNMP V2USER [{INIT|ADD|MODIFY|DELETE}] SNMP V2MANAGER [INIT|{ADD|DELETE}] [ipAddress] SNMP V3USER [{INIT|ADD|MODIFY|DELETE}] SNMP V3MANAGER [INIT|{ADD|DELETE}] [ipAddress][username] Options are: 222 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 223 Modifies the given user of the authentication algorithm and MODIFY their localized keys. If the user id is not in the system, this 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 223...
Page 224 Initializes the SNMPv3 Manager Table to all null IP INIT addresses. Adds an SNMP Managerv3 IP address into the SNMPv3 Manager Table.. Deletes an SNMPv3 Manager IP address from the DELETE SNMPv3 Manager Table Remarks Related USERS RestrictionsNone 224 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 225: Status
If xAy specifies a Buffer module, nothing displays. Level 2 Same as Level 1 operation Level 3 Same as Level 1 operation Level 4 Same as Level 1 operation Remarks None Related CLK, OUTPUT, INPUT, EVENTS RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 225...
Page 226: Systime
2001-06-18T21:31:57Z ID: SSU2000 Name: SSU_2000 1A01 0T09:13:35 1A02 5T03:25:59 1A03 4T04:06:37 1A04 3T06:26:05 1A05 4T04:05:48 1A08 4T03:30:10 1A09 9T01:43:29 1A10 9T01:43:31 1A11 9T01:43:32 1A12 0T09:12:35 2A01 9T01:30:59 2A02 0T05:32:39 2A03 9T01:30:53 226 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 227: Tdev
Level 3 Same as Level 2 operation Level 4 Same as Level 3 operation Remarks Since TDEV is an intensive calculation, you can only specify one port. Related None RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 227...
Page 228 600.00 sec) is 0.19 The TDEV ( 1000.00 sec) is 0.24 The TDEV ( 3000.00 sec) is 0.62 The TDEV ( 6000.00 sec) is 1.22 The TDEV (10000.00 sec) is 1.60 228 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 229: Time
If local time is behind UTC, then offset is negative. Use this command to set the current time within the unit. Level 4 Same as Level 3 operation Remarks None Related DATE RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 229...
Page 230: Tl1Format
Generates GR-831 compliant events on all TL1 sessions GR831 Generates GR-833 compliant events on all TL1 sessions GR833 Level 4 Same as Level 3 operation Remarks None Related None RestrictionsNone 230 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 231: Users
After the user ID is entered, you are prompted for a password. Password entries are echoed as ‘*’. Valid password characters are upper case, alphanumeric characters. After 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 231...
Page 232 Disables, enables, or unlocks the specified user in the DISABLE system. ENABLE UNLOCK Remarks TL1 requires user names and passwords to be limited to 10 characters. Related LOGIN, BYE, SECURITY RestrictionsNone 232 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 233: Ver
Main Code: B.00, 14AUG02 Level 2 Same as Level 1 operation Level 3 Same as Level 1 operation Level 4 Same as Level 1 operation Remarks None Related INFO RestrictionsNone 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 233...
Page 234: Who
You are ADMIN, with access level 4, connected to TELB ADMIN is connected to COML ADMIN is connected to COMA ADMIN is connected to COMB ADMIN is connected to TELA 234 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 235: Chapter 4 Ntp And Snmp
Chapter 4 NTP and SNMP This chapter provides detailed information about the Network Time Protocol (NTP) and Simple Network Management Protocol (SNMP) available with the SSU-2000e. In This Chapter NTP Support SNMP Protocol 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 235...
Page 236: Ntp Support
GPS receiver or local timing source. The SSU-2000e implements the NTP v.3 (RFC 1305) version. It can run as a server application and a client application. In addition, broadcast mode may be implemented as either a server or client.
Page 237: Snmp Protocol
Status, on page 83, and Parameters, on page 141, respectively. SNMP Protocol This section describes the two versions of SNMP that the SSU-2000e supports. The Communications module software determines the version of SNMP used by the SSU-2000e. See Table 4-1 for the part number for the various software loads that are available.
Page 238: Snmp V3 Details
SSU-2000e system, its modules, module features, input ports, output ports, etc. and variables include settings and measurements. The MIB is controlled by the SSU-2000e’s SNMP agent. The SNMP agent is a server program that sends SSU-2000e status (stored in the MIB database) to the network manager when the manager transmits commands.
Page 239: Adding A User
You can add up to four managers in the SNMP manager table. TL1 Command To use the TL1 command to add an SNMP manager IP address for traps with username XYZ, type: SET-PRMTR-SNMPV3-MANAGER:::::ADD,192.100.100.100,XYZ; 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 239...
Page 240: User And Manager Tables
SNMP supports a "keep-alive" mode based on a user-settable time. An event is generated to alert the upstream support system that the SSU-2000e and associated paths are functional. This mode is only supported in TL1 and SNMP sessions, not in ICS, Telnet, or Hyperterminal sessions.
Page 241: Shelf Information
Basic + NTP Support 24113012-002-0 Basic + SNMP v2 Support 24113012-003-0 Basic + NTP and SNMP v2 Support 24113012-004-0 Basic + SNMP v3 Support 24113012-005-0 Basic + NTP and SNMP v3 Support 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 241...
Page 242 Chapter 4 NTP and SNMP SNMP Protocol 242 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 243: Chapter 5 Antennas
This chapter provides information about optional antennas, antenna kits, part numbers and installation procedures for connecting GPS antennas to the SSU-2000e. In This Chapter Antenna Kits and Accessories Installing Antennas Optional Accessories Ordering Information 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 243...
Page 244: Antenna Kits And Accessories
250B-90 Gas Tube transient eliminator in series with the antenna coaxial cable. The cable between the antenna and the SSU-2000e cable should be kept to the shortest reasonable length. With the appropriate antenna (lised in...
Page 245: Gps Antennas With Internal Lna
< 3 lbs (1.4 kg) Environmental Temperature –40°C to +75°C Relative Humidity 100% Non-Immersed Altitude 200 ft. (60 m) below sea level to 13,000 ft. (3962 m) above sea level 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 245...
Page 246: Db L1 Gps Antenna Accessory Kit
Transient Eliminator, 90 Volts, 1.5 GHz, N-Type 12013076-030-0 Cable, LMR-400, 30 ft., Right Angle 551100-6013 Adapter, Right Angle Female to Right Angle Male 12010210-000-0 Bracket Assembly, Antenna Mount Right Angle 246 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 247: Transient Eliminators
Crimper Kit, LMR-400 (crimp tool, 2150 tape, LMR preptool, 10 each crimp N-type connectors) Transient Eliminators Symmetricom offers the FCC-250B-90-1.5NFNF Transient Eliminator for installations that require antenna coaxial lead-in protection. The FCC-250B- 90-1.5NFNF Transient Eliminator passes DC power and frequencies in the 1.5 GHz range with non-downconverter L1 GPS antennas.
Page 248: Gps L1 Inline Amplifier
20 dB ± 2 dB Gain Dimensions, includes connectors Length: 3.77 in (9.6 cm) Electrical Power +4 VDC to +28 VDC Current < 10 mA Noise Factor < 3 dB 248 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 249: Gps L1 Inline Amplifier Assembly
GPS inline amplifier, a 90 V L1 Transient Eliminator, and an adapter for connectivity. Antenna Coaxial Cables Symmetricom provides several low-loss cable types, as well as LMR-400 with N-type connectors on both ends. Table 5-8 lists the optional antenna coaxial cables...
Page 250: Antenna Cable Specifications
Plenum U/L 5.26 mm (Belden 89913) LMR-400 0.051 dB Shield – 0.00165 0.109 inch Solid Center – 0.00139 LMR-400 0.051 dB Shield – 0.00165 0.27686 cm Solid Center – 0.00139 250 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 251: Installing Antennas
254 Antenna Connection Overview The SSU-2000e chassis has two antenna connections located on the rear panel. The antenna connections are made via isolated TNC connectors J6 and J7, labeled ANTENNA-A and ANTENNA-B, respectively. The connectors are DC isolated and AC bypassed to frame ground.
Page 252 Follow local building electrical codes for grounding using the frame ground lugs on the SSU-2000e chassis. The in-line amplifier receives 5 VDC power from the GPS radio receiver, and is supplied on the center conductor of the LMR-400 or equivalent coaxial cable.
Page 253 Chapter 5 Antennas Installing Antennas Recommendation: Symmetricom recommends that you consider the following location and environment influences before installing the GPS antenna: If possible, provide the antenna with an unobstructed 360-degree view of the sky from the horizon. In general, do not allow obstructions that obscure the horizon (as...
Page 254: Antenna Installation Tools And Materials
Connect transient eliminators, if part of the grounding scheme, to earth ground through a conductor. Symmetricom makes no recommendation as to whether to install transient eliminators. Symmetricom can provide suitable transient eliminators as an option. Note: connect the outside transient eliminator ground to the Do not inside equipment rack ground.
Page 255: Cutting Antenna Cables
GPS antenna and the radio receiver. Coiling the excess cable also allows you to use the factory-installed crimped connector. Symmetricom does not recommend cutting the antenna cables provided in the GPS Antenna Kits. If you must cut the cables, please ensure that the following requirements are met.
Page 256: Connecting The Cable To The Antenna
If at all possible, avoid bundling the coaxial cable with other cables (and possible noise sources). Use appropriate cable-pulling devices when pulling the coaxial cable through conduit or a weather head. 256 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 257: Installing The Transient Eliminator
4. Connect the ground wire between the transient eliminator and the proper grounding zone (building ground, master ground bar, or other) for the mounting location. Recommendation: Symmetricom does not recommend soldered connections for grounding purposes. All grounding connections should be secured with mechanical clamp connectors.
Page 258: Installing The Antenna Cable
2. Secure the free end of the antenna cable to the appropriate antenna connector on the rear panel of the SSU-2000e using the right angle adapter provided with the antenna cable. Recommendation: Symmetricom recommends coiling excess cable to avoid gain mismatch between the GPS antenna and the SSU-2000e.
Page 259: Optional Accessories
551026-0038 Cable EIA-232 shielded DB9P to DB9S, 5 ft. (1.5 m) Ordering Information To order any accessory, contact the Symmetricom Sales Department at the following address and phone number, and supply the accessory name and part number: USA and Canada Symmetricom, Inc.
Page 260 Asia and Pacific Rim Symmetricom Hong Kong Ltd P.O. Box No. 71 Texaco Road Post Office Hong Kong Telephone: + 852 2405 5203 Fax: + 852 2405 5713 email: asia_sales@symmetricom.com 260 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 261: Chapter 6 Alarms And Events
Chapter 6 Alarms and Events This chapter describes the alarms and events that the SSU-2000e generates, and provides some troubleshooting information for dealing with these alarms and events. In This Chapter Message Format Clock Module Alarms and Events Communication Module Alarms and Events...
Page 262: Message Format
After the Communications module is installed and functioning properly, it monitors the SSU-2000e and logs events into non-volatile memory, where you can inspect it at a later date. Events are conditions within the unit or at the interfaces of the unit which may indicate abnormal operation or a change in the unit’s operational status.
Page 263: Snmp Trap Message Format
2 = user requested event to be resent tpId Trap Identification (199) tpMCode (1013) Symmetricom's module code number tpTimestamp (0x07:d6:06:14:08:23:1a:00:2b:00:00) Event timestamp tpChassis Shelf ID (1 through 5) tpSlot Module slot number tpPort Module port number 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 263...
Page 264 1 = yes 2 = no tpDescr Trap Message (Port, Enable, TELA) Note: Refer to Module specific Alarm/Event/Trap ID for values. Refer to Module specific Alarm/Event/Trap Response for message content. 264 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 265: Clock Module Alarms And Events
Only available with Stratum 2E Rubidium module. If alarm persists, internal phase lock loop re-seat module. (ST2E clock only) Status of the hardware Call Symmetricom Global Services. Return to factory. configuration A user has installed a Clock module. Module nstalled Module Removed A user has removed a Clock module.
Page 266 Changed Alarm Level Changed A user has changed the Alarm level. Elevation Time Changed A user has changed alarm elevation time. Setup Changed A user has set the module’s configuration. 266 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 267: Clock Module Alarm Defaults
PLL on the output of the NCO is unlocked Hardware Config Major Immed Immed Error, indicates a mismatch between the hardware of the module and the hardware number. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 267...
Page 268: Communication Module Alarms And Events
Unable to communicate with Expansion Shelf 3. Check cables. Shelf #4 Comm, Lost Unable to communicate with Expansion Shelf 4. Check cables. Shelf #5 Comm, Lost Unable to communicate with Expansion Shelf 5. Check cables. 268 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 269 Upgrade NAK, 1A02 Module’s firmware upgrade was not completed. Config, 1A06, Not Support Call Symmetricom Global Services. Return to factory. NTP Mode, GPS The SSU is configured with NTP running in an NTP Client, Broadcast, or Broadcast Client server mode; Local is displayed when NTP server is initialized.
Page 270 An SNMP Manager has been initialized at the IP address shown. INIT<192.5.41.39, COML Err Delay, (1), 300 sec, A user has changed the alarm delay time. COML Alm Level, (2), Rep, COML A user has changed the alarm level. 270 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 271: Basic + Snmpv2 And Basic + Ntp + Snmpv2
This table includes the typical response for each alarm or event, it’s event number, and a description or a suggested corrective action. The SNMP MIB trap is listed in the Alarm/Event/Trap Description column. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 271...
Page 272: Basic +Snmpv2 And Basic +Ntp + Snmpv2 Communications Module Alarm And
System automatically logging out a user. Msg, <HELLO BILL>, COML Message sent from a user. Not Acknowledged, 1A01 Module configuration could not be obtained. Module Status, Fault, 1A04 Module did not boot properly. 272 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 273 Upgrade NAK, 1A02 Module’s firmware upgrade was not completed. Config, 1A06, Not Support Call Symmetricom Global Services. Return to factory. NTP Mode, GPS The SSU is configured with NTP running in an NTP Client, Broadcast, or Broadcast Client server mode; Local is displayed when NTP server is initialized.
Page 274: Basic + Snmpv3 And Basic + Ntp + Snmpv3
This table includes the typical response for each alarm or event, it’s event number, and a description or a suggested corrective action. The SNMP MIB trap is listed in the Alarm/Event/Trap Description column. 274 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 275: Basic +Snmpv3 And Basic +Ntp + Snmpv3 Communications Module Alarm And
System automatically logging out a user. Msg, <HELLO BILL>, COML Message sent from a user. Not Acknowledged, 1A01 Module configuration could not be obtained. Module Status, Fault, 1A04 Module did not boot properly. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 275...
Page 276 Upgrade NAK, 1A02 Module’s firmware upgrade was not completed. Config, 1A06, Not Support Call Symmetricom Global Services. Return to factory. NTP Mode, GPS The SSU is configured with NTP running in an NTP Client, Broadcast, or Broadcast Client server mode; Local is displayed when NTP server is initialized.
Page 277 An alarm level change. Elevate Time, 3600 sec, A user has changed the alarm elevation time. COML Setup, Save, COML A user has saved the setup to the user default. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 277...
Page 278: Cc Input Module Alarms And Events
A user has changed input priority level. Prov PQL, 5, COML A user has changed input provisioned PQL. Err Cnt, BPV, 16, COML Signal Alarm Error Count (LOS, AIS, OOF, BPV, or CRC). 278 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 279: Composite Clock Input Module Alarm Defaults
User defaults have been set and saved. Table 6-9. Composite Clock Input Module Alarm Defaults Description Alarm Level Major Major Hdw Config Major Clock PLL Major Phase Hdw Major Phase 3Sigma Minor Phase Polarity Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 279...
Page 280: Ds1/E1 Input Module Alarms And Events
The Input module has been removed. Module Enable, Input Module, COML The Input module has been enabled. Disable, Input Module, COML The Input module has been disabled. Restart, in 5 seconds, COML Module re-boot. 280 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 281 The MTIE clear limit settings have been changed. Setting PBO, Report, COML Phase Build-out system response has been changed to the indicated setting. Freq Tau, Clk-A, 400, COML The frequency TAU limits have been set. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 281...
Page 282: Ds1/E1 Input Module Alarm Defaults
Alarm Level Major Major Minor Minor Minor MTIE/L1 Minor MTIE/L2 Major Minor Major Ref Qualifier Minor Clk PLL Major Inp PLL Major Phase Hdw Major FREQ Minor Hdw Config Major 282 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 283: Gps Input Module Alarms And Events
Item Number, Unknown Call SGS. Return to factory. GPS Qualifier, Fault Reseat module. If problem persists, call SGS. Phase Hdw, Fault Reseat module. If problem persists, call Symmetricom Global Services. MTIE/L1, Fault Check inputs. If inputs are OK, call SGS. MTIE/L2, Fault Check inputs.
Page 284: Gps Input Module Alarm Defaults
Setup, Save, COML User defaults have been set and saved. Table 6-13. GPS Input Module Alarm Defaults Description Alarm Level Hdw Config Major Tracking Major Antna Conntd Major Antna Shorted Major 284 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 285 Table 6-13. GPS Input Module Alarm Defaults (Continued) Description Alarm Level Engine Hdw Major Engine System Minor Position Minor Clk PLL Major Item Number Major GPS Qualifier Report Phase Hdw Major MTIE/L1 Minor MTIE/L2 Major Freq Minor 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 285...
Page 286: 2048 Khz Output Module Alarms And Events
Hdw Config, Fault If module is installed in slot previously used by a different module type, use the CONF xAy REMOVE command. If problem persists, call Symmetricom Global Services. Squelch, Below Prov Input signal PQL is below user-defined threshold. Install, 2048 Output Module...
Page 287 Major Module Match Major Clk-A Major Clk-B Major Clk-C Major Clk-D Major Clk Level Major Clk Selected Major VCXO Major Major Configuration Major IntPortFlt Major Hdw Config Major Squelch Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 287...
Page 288: Cc Output Module Alarms And Events
Indication of external port fault on ports 2 and 4 (A000 Hex). Hdw Config, Fault If module is installed in slot previously used by a different module type, use the CONF xAy REMOVE command. If problem persists, call Symmetricom Global Services. Install, CC Output Module Module Installed. Remove, CC Output Module Module Removed.
Page 289: Cc Output Module Alarm Defaults
Major Module Match Major Clk-A Major Clk-B Major Clk-C Major Clk-D Major Clk Level Major Clk Selected Major VCXO Major Major Configuration Major IntPortFlt Major Hdw Config Major Squelch Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 289...
Page 290: Ds1 Output Module Alarms And Events
Hdw Config, Fault If module is installed in slot previously used by a different module type, use the CONF xAy REMOVE command. If problem persists, call Symmetricom Global Services. Clk-D, Lost Only in SDU. Loss of backup clock. Check cable.
Page 291: Ds1 Output Module Alarm Defaults
Alarm Level Redundant Major Module Match Major Clk-A Major Clk-B Major Clk-C Major Clk Level Major Clk Selected Major PortFlt Major VCXO Major Major Configuration Major Hdw Config Major Clk-D Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 291...
Page 292: E1/2048 Khz Output Module Alarms And Events
Hdw Config, Fault If module is installed in slot previously used by a different module type, use the CONF xAy REMOVE command. If problem persists, call Symmetricom Global Services. Configuration, Fault Redundant configuration mismatch. Re-seat or replace module. Clk-A, Lost Clock module in slot A1 is in warm-up mode or has other problems.
Page 293: E1/2048 Khz Output Module Alarm Defaults
Table 6-21. E1/2048 kHz Output Module Alarm Defaults Description Alarm Level Hdw Config Major Configuration Major Clk-A Major Clk-B Major Clk-C Major Clk-D Major Clk Selected, Major VCXO Major Major Sync Major Squelch Major PortFlt Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 293...
Page 294: Rs-422 Output Module Alarms And Events
Hdw Config, Fault If module is installed in slot previously used by a different module type, use the CONF xAy REMOVE command. If problem persists, call Symmetricom Global Services. Configuration, Fault Redundant configuration mismatch. Re-seat or replace module. Clk-A, Lost Clock module in slot A1 is in warm-up mode or has other problems.
Page 295: Output Module Alarm Defaults
Table 6-23. RS-422 Output Module Alarm Defaults Description Alarm Level Hdw Config Major Configuration Major Clk-A Major Clk-B Major Clk-C Major Clk-D Major Clk Selected Major VCXO Major Major PortFlt Major 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 295...
Page 296: Buffer Module Alarms And Events
User has changed the error delay time. COML Alm Level, (0), Maj, COML User has changed the level of specified alarm. Elevate Time, 86400 sec, User has changed the alarm elevation time. COML 296 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 297: Chapter 7 Connector Pinouts
Chapter 7 Connector Pinouts This chapter describes the pinouts for each of the connectors on the SSU-2000e chassis. In This Chapter Signal Names and Definitions Shelf Module Slot Addressing and Size Assignments I/O Connector Grounding 12713140-003-2 Revision E.01 – January 2007...
Page 298: Signal Names And Definitions
SSU-2000e, as shown in Figure 7-1. Figure 7-1. SSU-2000e Connection Panel Power and Ground Figure 7-2 shows the power and ground connections for the SSU-2000e chassis. Figure 7-2. Power and Ground Connection Pinouts 298 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 299: Communication Interfaces
J5-3 CTS-B Serial Port B, Clear to Send Control Line J5-8 DTR-B Serial Port B, Data Terminal Ready Control Line J5-4 RI-B Serial Port B, Ring Indicator Control Line J5-9 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 299...
Page 300: Local Osc And Antennas
Alarm Contact Closures Figure 7-5 illustrates the alarm closure connectors on the rear panel of the SSU-2000e chassis. Table 7-3 outlines signal names, definitions, and locations of alarm contact closures. 300 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 301: Signal Names And Locations Of Alarms
Local Minor Alarm, Normally Open Contact TB1-7 LMIN-COM Local Minor Alarm, Common Contact TB1-8 LMIN-NC Local Minor Alarm, Normally Closed Contact TB1-9 RCRT-NO Remote Critical Alarm, Normally Open Contact TB2-1 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 301...
Page 302 Remote Major Alarm, Normally Closed Contact TB2-6 RMIN-NO Remote Minor Alarm, Normally Open Contact TB2-7 RMIN-COM Remote Minor Alarm, Common Contact TB2-8 RMIN-NC Remote Minor Alarm, Normally Open Contact TB2-9 302 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 303: Sdu-2000 Expansion Interface
Signal Names and Definitions SDU-2000 Expansion Interface Figure 7-6 illustrates the SDU Interface and the Backup Clock Connector, located on the rear panel of the SSU-2000e. Table 7-4 outlines signal names, definitions, and locations of the SDU Expansion interface and backup clock connectors.
Page 304: Shelf Module Slot Addressing And Size Assignments
Body/Shield: Connected to Frame Ground Plane Ethernet RJ45 Body/Shield: Connected to Frame Ground Plane 10-Base-T Serial Port A DE9S Body/Shield: Connected to Frame Ground Plane Serial Port B DE9S Body/Shield: Connected to Frame Ground Plane 304 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 305 Micro D50S Body/Shield: Connected to Frame Ground Plane RESET TBNC/BNO Shield: 0.01μF Bypass to Frame Ground Plane LG (Logic Stake-On TB3 & TB4 Terminal: 1.0μF Bypass to Frame Ground Plane Ground) 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 305...
Page 306 Chapter 7 Connector Pinouts I/O Connector Grounding 306 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 307: Chapter 8 Default Settings
Chapter 8 Default Settings This chapter contains tables that list the factory default settings for the SSU-2000e. If you make any changes to the factory default settings, record them in Table 8-14 for future reference. Use the “SETUP” command to verify settings.
Page 308: Communications Module Default Settings
Chapter 8 Default Settings Communications Module Default Settings Communications Module Default Settings Table 8-1 lists settings and factory defaults for the SSU-2000e Communications Module. Table 8-1. Communications Module Factory Default Settings Setting Factory Default Unit Name SSU_2000 Module Information Current Configuration = the configuration that is currently in use.
Page 309: Ds1 And E1 Input Module Default Settings
2,3,4,5,6, or 8 Note: PQL 4=STU 4 for E1 Input Module Priority 0 to 10 (0 = Monitor) E1 SSM Bit Position 8 (Not applicable for DS1 Input 4 to 8 Module) 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 309...
Page 310: Mtie Limits For The Ds1 Input Module
MTIE limits for the DS1 Input Module configuration and factory defaults and settings. Table 8-4. DS1 Input Module – MTIE Limits Set Limit L1 Set Limit L2 Clear Limit L1 Clear Limit L2 Time (s) (ns) (ns) (ns) (ns) 310 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 311: Mtie Limits For The E1 Input Module
Longitude (+ = East, – = West) ±180 degrees Height –60 to 4,000 meters Averages 10 to 3600 PDOP 1 to 10 Pos Mode Calc User | Calc Min Elevation for position 0 to 50 degrees 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 311...
Page 312: Gps Input Module Default Settings
0 to 60 000 MTIE T1K Clear Limit 1 0 to 60 000 MTIE T1K Clear Limit 2 0 to 60 000 MTIE T10K Clear Limit 1 0 to 60 000 312 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 313: Ds1 And E1 Line Re-Timing Module Default Settings
1 to 255 (in any 24 hour period) Clear <4 Fault Strategy SQUELCH Port Enable Enabled Enabled Disabled Circuit ID None (blank) String from 0-43 characters (only valid TL1 characters are supported) 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 313...
Page 314: Ds1 And E1 Output Module Default Settings
Chapter 8 Default Settings DS1 and E1 Output Module Default Settings DS1 and E1 Output Module Default Settings Table 8-8 lists settings and factory defaults for the SSU-2000e DS1 and E1 Output modules. Table 8-8. DS1 and E1 Output Module Default Settings Factory...
Page 315: 2048 Khz Output Module Default Settings
On | Off On | Off SSM Bit Position 4 | 5 | 6 | 7 | 8 Port Output (per port) Enabled Enable | Disable Bypass Enable Enable | Disable 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 315...
Page 316: E1/2048 Khz Output Module Default Settings
60 to 500 000, 0 is disabled Port Delay 3 (1375 feet) in 0 to 7 Normal mode, 7 (2200, 1925, 1650, 1375, 1100, (275 feet) in 825, 550, and 275 feet) Subtending mode 316 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 317: Composite Clock Output Module Default Settings
G.811 0x08 0x00 0x0C 0x04 Type II 0x0C Type I 0x04 Type I 0x78 Type V 0x04 G.812 Transit 0x7C ST3E 0x08 Type III 0x10 Type VI 0x08 G.812 Local 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 317...
Page 318: Priority Quality Level (Pql) Table Default Settings
Factory Configuration = the factory default configuration User List Maximum of 25 users including four built-in configurations users 318 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 319: User Changes To Factory Defaults
86400 seconds PQL Setting 2E: 5 TYPE I: 6 3E: 8 Clock Module 2 Warmup Time 1200 s Min Tau Limit 2E: 300 s TYPE I: 150 s 3E: 150 s 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 319...
Page 320 3E: 1200 s Clk Switch AR Input Switch AutoReturn (AR) Input Selection Mode Priority Local Oscillator (LO) Elevation Time 86400 seconds PQL Setting 2E: 5 TYPE I: 6 3E: 8 320 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 321: Chapter 9 Specifications
Chapter 9 Specifications This chapter provides specifications for the SSU-2000e and for its functional components, such as operating conditions, power inputs, clock inputs and outputs, indicators, EMC and safety standards, and chassis dimensions. In This Chapter SSU-2000e Shelf Specifications SDU-2000 Shelf Specifications 12713140-003-2 Revision E.01 –...
Page 322: Ssu-2000E Shelf Specifications
Alarm Levels Commands can set alarm level to IGNORE, REPORT, MINOR, MAJOR, and CRITICAL. MINOR and MAJOR alarms can be elevated to the next higher level after a user-defined time period. 322 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 323 Exceeds latest ANSI, ITU-T and Telcordia Technologies standards Clock Type (Holdover) Stratum 2E Rubidium (2 weeks) Stratum 3E Quartz TYPE I Quartz Control DDS (Direct Digital Synthesis) technology Integrated CPU 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 323...
Page 324 –48 VDC return, isolated from frame and logic grounds Chassis Mechanical Width 17 inches (43.2 cm) Depth 11.5 inches (29.2 cm) Height 10.5 inches (26.7 cm) Weight (provisioned) ~ 27 lbs (12.3 kg) Chassis Environmental 324 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 325 ETS 300 019-2-2 Class 2.1, 2.2, 2.3, and 2.3 special Packaged Equipment Shock GR-63-CORE Sec. 4.3.1.2 Unpackaged Equipment Shock GR-63-CORE Sec. 4.3.2 Electrical Safety GR-1089-CORE Sec. 7 Material/Component Fire GR-1089-CORE Sec. 4.2.3.1 Resistance 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 325...
Page 326 GPS PRS Performance and Antenna Environmental GPS Performance Compliant with Stratum 1 PRS (Primary Reference Source) per (ANSI) T1.101-1999, ITU-T G.811, and Telcordia Technologies (Bellcore) GR-2830-CORE. Temperature –40°C to +72.5°C 326 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 327: Operating Conditions Specifications
–5 °C Relative Humidity 1. The unit is not damaged if the polarity on the power leads is reversed. ° 2. At 30 C max/hour rate of change. 3. Non-condensing. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 327...
Page 328: Power Input And Grounding Specifications
G.703 Sec. 9 Framed E1 Bit Rate 2048 kbit/s Format CAS or CCS (per ITU-TG.703 Sec. 2 & (ANSI) T1.102 DS1A CRC4 enabled/disabled AMI or HDB3) Amplitude Range +3 to –27 dBTLO 328 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 329: Output Signal Specifications
Rise Time < 100 ns Pulse Width < 324 ns, nominal Pulse Interval 648 ns, nominal Duty Cycle Number of Outputs 20 per module 100 Ω ± 5% Termination Impedance 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 329...
Page 330 1.0 to 1.9 V peak into 120 Ω Amplitude 0.75 to 1.5 V peak into 75 Ω Jitter < 0.03 UI Number of Outputs 20 per module 120 Ω ± 5% or 75Ω ± 5% Termination Impedance 330 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 331: Sdu-2000 Shelf Specifications
2 Buffer modules and 10 mixed Output modules Expansion drive for up to three additional Expansion shelves Maximum of four Expansion Shelves per system Maximum of 61 m (200 ft) between the SSU-2000e main shelf and the farthest expansion shelf Output Section...
Page 332 Return DC isolated from frame and logic grounds. Integrated frame and logic ground. Power Connections A-BUS and B-BUS input power connectors (#6 terminal block) on opposite sides of the rear panel. 332 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 333: Chapter 10 Reference Materials
This chapter lists the standards and other reference materials that apply to the SSU-2000e. In This Chapter (ANSI) T1.101–1999, Synchronization Interface Standards for Digital Networks. Generic Requirements Technical Advisories and Framework Technical Advisories Technical References EIA/TIA Documents Other Reference Documents 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 333...
Page 334: American National Standards Institute (Ansi) Documents
10.FR–476, OTGR Section 6: Network Maintenance: Access and Testing (Bellcore, 1997 Edition) (A subset of OTGR, FR–439). 11.FR–480, OTGR Section 10: User System Interface (Bellcore, 1997 Edition). (A subset of OTGR, FR–439). 334 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 335: Generic Requirements
5. TA–NWT–000983, Reliability Assurance Practices for Optoelectronic Devices in Loop Applications, Issue 2 (Bellcore, December 1993). 6. TA–TSV–001294, Generic Requirements for Element Management Layer (EML) Functionality and Architecture, Issue 1 (Bellcore, December 1992). 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 335...
Page 336 (EM) Applications for SONET Subnetworks, Issue 1 (Bellcore, September 1992). 22.TA–NWT–001385, Generic Requirements for Optoelectronic Devices in Fiber Optic Systems, Issue 1 (Bellcore, April 1993) plus Bulletin 1, January 1994. 336 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 337: Technical References
13.TR–TSY–000458, Digital Signal Zero, “A” (DS-0A 64 kb/s) Systems Interconnection, Issue 1 (Bellcore, December 1989). 14.TR–TSY–000782, SONET Digital Switch Trunk Interface Criteria, Issue 2 (Bellcore, September 1989). (A module of LSSGR, FR–64, and TSGR, FR–440.) 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 337...
Page 338: Eia/Tia Documents
7. OFSTP–10, Measurement of Dispersion Power Penalty in Single-Mode Systems. 8. OFSTP–11, Measurement of Single Reflection Power Penalty for Fiber Optic Terminal Equipment.These publications are available from: EIA/TIA Standards Sales Office 2001 Pennsylvania, NW Washington, DC 20006 (202) 457-4963 338 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 339: Other Reference Documents
18.ETS 300 019 series, ETSI environmental conditions and tests. 19.ETS 300 119-2, ETSI requirements for racks and cabinets. 20.IEC 950/EN60950, European Safety Requirements, August 1993. 21.ITU-T Rec G.703. 22.ITU-T Rec G.704. 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 339...
Page 340 35.EN 61000-4-5 (1995), Electromagnetic Compatibility (EMC); Part 4: Testing and Measurement Techniques; Section 5: Surge Immunity Test. 36.EN 61000-4-6 (1996), Electromagnetic Compatibility (EMC); Part 4: Testing and Measurement Techniques; Section 6: Conducted Disturbances Induced by Radio Frequency Fields. 340 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 341: Index
ICS minor, setting, TL1 report-level, setting, ICS activating a user. See logging in report-level, setting, TL1 address, IP response message codes retrieving, ICS retrieving settings, TL1 retrieving, TL1 retrieving, ICS 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 341...
Page 342 TL1 setting, TL1 output, setting mode, ICS status, retrieving current, ICS output, setting mode, TL1 status, retrieving current, TL1 Cesium fault input, enabling, ICS input, enabling, TL1 342 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 343 ICS crimper kit setting port parameters, ICS GPS antenna setting port parameters, TL1 optional signals crimp-style connectors, requirements Communications module critical alarm alarms setting, ICS default settings setting, TL1 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 343...
Page 344 ICS input frequency, setting, ICS parameters, retrieving, TL1 input signal specifications retrieving parameters, ICS MTIE limits setting parameters, ICS parameters, retrieving, TL1 setting parameters, TL1 DS1 Line Re-timing module 344 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 345 TL1 E1/2048 kHz Output module retrieving satellite availability GPS Input module settings, retrieving, ICS login setting, ICS settings, retrieving, TL1 phase build-out, enabling, ICS GPS antenna phase build-out, enabling,TL1 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 345...
Page 346 PQL, setting, ICS ID, displaying, ICS PQL, setting, TL1 idle-level users priority mode, setting, ICS priority mode, setting, TL1 ignoring alarms, ICS reference port, retrieving, ICS ignoring alarms, TL1 346 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 347 TL1 mechanical specifications testing, ICS chassis line length GPS antenna DS1 outputs, ICS GPS L1 inline amplifier setting, DS1/E1 Output modules, TL1 message, sending, ICS line termination, ICS minor alarm 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 347...
Page 348 ICS threshold, setting, ICS operating conditions threshold, setting, TL1 exceptional mulltiframe mode normal setting, TL1 operating mode multiframe mode retrieving, TL1 setting, ICS setting, TL1 setting/retrieving, ICS ordering 348 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 349 ICS position of GPS receiver shelves, retrieving, TL1 setting, ICS password setting, TL1 aging, ICS power aging, TL1 chassis, specifications changing, ICS GPS antenna specifications lockout, ICS SSU-2000 shelf 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 349...
Page 350 ICS lockout, TL1 GPS antenna non-operating conditions login events setting, TL1 operating conditions login events, ICS relays, testing login events, retrieving, TL1 overview reloading user configuration parameters, retrieving, ICS 350 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 351 TL1 enabling/disabling, ICS manager list, modifying, TL1 enabling/disabling, TL1 manager list, retrieving, ICS translating from PQL, ICS manager list, retrieving, TL1 SSU-2000 mode, retrieving, TL1 mode, setting, TL1 dimensions 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 351...
Page 352 Telcordia Technologies (formerly Bellcore) GPS antenna accessories installing GR-1244-CORE L1 signal loss TR-NWT-000831 specifications temperature translating PQL to SSM values, ICS GPS antenna specifications Type 1 Clock module non-operating conditions operating conditions alarms 352 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
Page 353 TL1 maximum name length zero suppression unlocking, ICS input, enabling/disabling, ICS unlocking, TL1 input, enabling/disabling, TL1 user configuration output, enabling/disabling, ICS reloading, ICS output, enabling/disabling, TL1 reloading, TL1 12713140-003-2 Revision E.01 – January 2007 SSU-2000e Technical Reference 353...
Page 354 Index Z—Z 354 SSU-2000e Technical Reference 12713140-003-2 Revision E.01 – January 2007...
