2.7 Output verification
The following procedure verify that the power supply outputs the correct
voltage and current levels and properly responds to entries from the front
panel.
Voltage Output Check
The following steps verify basic voltage function without load.
1.
2.
3.
4.
5.
----End
Current output Check
The following steps check the basic current functionality by shorting the power
supply's output.
1.
2.
3.
4.
5.
6.
7.
8.
9.
----End
Press Power key to turn on the power supply.
On/Off
Press
key to enable the output.
Set the voltage value.
Adjust the voltage, then press
METER mode), make sure that the set value and output value are same,
and if the current displayed on the VFD is nearly 0A.
Make sure the voltage can be adjusted from zero to the maximum rated
value.
Check the other two channels by the same method.
NOTE
Meter
Meter
when
key is gray, the power supply is in SET mode, then the VFD displays the set
voltage and current; when the key is lit, then the power supply is in METER mode, the actual
voltage and current display on the VFD. When the output is OFF, the "OFF" indicate will display
at the current display area.
Press Power key to turn on the power supply.
On/Off
Press
to disable the output, ensure the output is OFF.
Connect a short across (+) and (-) output terminals with an insulated test
lead, use a wire sufficient to handle the maximum current.
Adjust the voltage value to 1V.
On/Off
Press
to enable the output.
Adjust the current.
Set some different current values, in METER mode, check whether the
voltage value on VFD is near 0v, and the current on it is close to the value
you set.
Make sure that the current can be adjusted from 0 to full rated value.
Disable the output and then remove the short wire.
Check the other two channels by the same method.
Copyright © Itech Electronics Co., Ltd.
Meter
Meter
to lit the key (indicates it is in the
Quick Start
12
