Take "CH2+CH3" as an example, press
" Comb"
------Select
" CH2+CH3" item and press
indicate "Parallel Success!" and escape this screen after 2S.
Front display as follows in condition of output off and meter state.

Track (sync output setting)
This function configures the instrument for tracking operations of three
channels. Possible combination mode are CH1+CH2,CH2+CH3,ALL.
Enter
Press button to confirm your set.And press
operation.
In tracking mode,once the parameters of any one channel are
changed,other channels will change proportionally.
For example, set voltage and current of CH1 and CH2 as follows, CH1:
4V, 1A；CH2: 8V, 2A. Press
press to select Comb, VFD will display as follows:
CH1+CH2 CH2+CH3
Select "CH1+CH2" and press
"Track Set Success!" and escape this screen after 2S..
Front display as follows in condition of output off and meter state.
For example: In setting status, if voltage of CH1 is set as 2V, voltage of
CH2 will automatically change to 4V
NOTE
Tacking function is disabled to the channel with 0V or 0A setting. In the former example,if CH2
setting is 0V or 0A, then when CH1 voltage is adjusted to 2V,CH2 will remain unchanged.
Parameters in Serial, Parallel or Tracking mode
Maximum voltage
Operate "CH1+CH2" in series, the max voltage is 62V the sum of the max
voltage of CH1 and CH2.
Operate "CH1+CH2" in parallel, the max voltage is the smallest max voltage
of the two channels. It is 31V.
Operate "CH2+CH3" in parallel, the max voltage is the smallest max voltage
of the two channels, it is 6V.
Copyright © Itech Electronics Co., Ltd.
(Shift) +
Enter
and press
Enter
to confirm.The front panel will
I-set I-set
(Shift) +
ALL
Enter
to confirm. The VFD will display
proportionally.
Function and Features
I-set I-set
（Menu）
to confirm.-------select
Esc
to quit the
（Menu）into Menu, and
19
