If the latest operation state of the power supply was lost, then the VFD will display (about
2S):
Syst Lost
During channel scan, the VFD will display:
Scan Chan
When checkout for one channel is failed, then the VFD will display (about 2S):
Scan Chan
Chan Lost
When the calibration data of one or more channel is lost, then the VFD will display (about
2S):
Scan Chan
Cal Lost
When the factory calibration data of one or more channel is lost, then the VFD will display
(about 2S):
Scan Chan
Fact Lost

1.2.4 Output verification

The following procedures verify that the power supply outputs the correct voltage and
current levels and properly responds to entries from the front panel.
Voltage Output Check
The following steps verify basic voltage function without load.
1) Press Power key to turn on the power supply
On/Off
2) Press key to enable the output
Note: when
displays the set voltage and current; when the key is lit, then the power supply is
in METER mode, the actual voltage and current display on the VFD. When the
output is OFF, the ---- will display at the current display area.
3) Set the voltage value
Adjust the voltage, then press
make sure that the set value and output value are same, and if the current displayed on
the VFD is nearly 0A.
4) Make sure the voltage can be adjusted from zero to the maximum rated value.
5) Check the other two channels by the same method.
USER MANUAL
Picture 6
Picture 7
Picture 8
Picture 9
Picture 10
key is gray, the power supply is in SET mode, then the VFD
to lit the key (indicates it is in the METER mode),
