ITech IT6322A User Manual page 27

Reset
If you enter this menu and select "YES", all parameters will be set to their
default values.
Exit
Escape the menu.
System
This item set the max voltage and out timer of each channel. Choose one
channel and set the parameters.
Max Volt
The max voltage you set should be within the range of 0V to the maximum
rated voltage. You can edit this value using the
key pad followed by
voltage for each channel.
Out Timer
This item sets the output timer for each channel. The range is 0.1~99999.9S.If
you enable this function, and the output state of all channels is on, the timer
will start counting down immediately. Once the timer expires(count down from
set value to zero) the output of the assigned channel will turn off. To disable
the timer, set the output time to zero. Default setting is 0 seconds.
Comb
This item configures the instrument connection mode.



Enter
Off
"Off" means that each channel operates independently. When set
successfully, front panel will display "Remove success!"
Series (Series mode)
This function configures the instrument for series operation of CH1 and
Enter
CH2.Press button to confirm your set. And press
the operation.
When enable series connection mode, the front panel will indicate
"Series success!" and escape this screen after 2S.
Front display as follows in condition of output off and meter state.
Parallel (Parallel mode)
This function configures the instrument for parallel operations of three
channels. Possible combination mode are CH1+CH2,CH2+CH3,ALL.
Enter
Press button to confirm your set.And press
operation.
Copyright © Itech Electronics Co., Ltd.
,
.The default setting is the maximum rated
Function and Features
keys or via numerical
Esc
to quit
Esc
to quit the
18
