2.4 Introduction of indicators on the screen

c
v
↑
T

2.5 Introduction to the rear panel

The rear panel of IT6322B/IT6332B/IT6333B is shown in the next figure.
The rear panel of IT6322A/IT6332A/IT6333A is shown in the next figure.
1.
2.
3.
4.
5.
6.
In constant current mode.
In constant voltage mode.
Keyboard operation for the lock mode.
Open the remote sense function.
Indicates the shift button is pressed.
Indicates the channel currently selected.
Enable tracking mode.
Cooling window
RS232 communication interface
USB communication interface
GPIB communication interface
Remote measurement terminal
110V/220V AC power selection switch and Fuse
