Specifications of Red and Black Test Lines
ITECH provides you with optional red and black test lines, which individual
sales and you can select for test. For specifications of ITECH test lines and
maximum current values, refer to the table below.
Model
IT-E301/10A
IT-E301/30A
IT-E301/30A
IT-E301/60A
IT-E301/120A
IT-E301/240A
IT-E301/240A
IT-E301/360A
For maximum current of AWG copper wire, refer to table blow.
AWG
The
Maximum
current
value(A)
Note: AWG (American Wire Gage), it means X wire (marked on the wire).
The table above lists current capacity of single wire at working
temperature of 30° C. For reference only.
Specification
10A
30A
30A
60A
120A
240A
240A
360A
10 12 14 16
40 25 20 13
