Dimm Slot Locations - HPE ProLiant MicroServer Gen10 Series Troubleshooting Manual

Item Component
1 Fan connector
2 DIMM slots
3 CMOS header
4 TPM connector
5 LFF/SFF drive SATA port
6 Optical drive or SSD SATA
port
7 System board power
connector
8 System battery
9 Internal USB 2.0 port
10 Expansion slot 2, PCIe3
×4 (1)
11 Expansion slot 1, PCIe3
×8 (8, 4, 1)
1
These are SATA 6Gb/s ports.
2
This expansion slot is open-ended, which enables down-plugging. Down-plugging means a larger-width expansion board
can be installed in a smaller-width connector. For this server, the expansion slot supports low-profile expansion boards
with a physical connector link widths of up to ×16. The board operates at the highest common negotiable link width
specified for the slot.

DIMM slot locations

The DIMM slots are numbered 1 and 2. The arrow in the following illustration points to the front of the server.
14 DIMM slot locations
Description
Connects the fan cable.
These slots support standard UDIMMs with ECC only.
Use the jumper on this header to clear the CMOS.
This connector supports the TPM 2.0 option for data security solution.
Connects the LFF/SFF drive SATA cable.
Connects the optical drive or SSD SATA cable.
Connects the power supply cable.
This battery provides power to the server real-time clock and BIOS
settings.
Connect internal USB devices to this port.
For additional hardware capabilities, install a compatible low-profile
PCIe expansion board here. This expansion slot supports expansion
boards with a physical connector link widths of up to ×16.
For additional hardware capabilities, install a compatible low-profile
PCIe expansion board here. This expansion slot supports expansion
boards with a physical connector link widths of up to ×16.
