Data Flash Strobe

8. Info

01) Press the MODE button and then the UP/DOWN buttons, until the display shows
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose between the 2 options,
04) Press the SETUP button to open one of the 2 options.
05) In the menu
06) In the menu

DMX Channels

2 channels

Channel 1 – Dimmer intensity
0-255 Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Strobe (
0-4 Closed
5-127 Linear strobe, from low to high frequency (0-20Hz) ALL LEDs
128-189 Random strobe, from low to high frequency ALL LEDs
190-255 Random strobe RANDOM LED RINGS
3 channels
Channel 1 – Dimmer intensity
0-255 Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Strobe (
0-4 Closed
5-255 Strobe flash frequency, from low to high frequency (0-20 Hz)
Channel 3 – Strobe mode (
0-127 Linear strobe, from low to high frequency (0-20Hz) ALL LEDs
128-149 Random strobe, from low to high frequency ALL LEDs
150-172 Random strobe RANDOM LED RINGS
173-199 Blinder mode (25Hz) ALL LEDs
200-231 Sound sensitivity, from OFF to high sensitivity
232-255 Single flash mode
Ordercode: 40296
, the device will display if the temperature from the device is too high or not.
you can view the current software version.
Dimmer must be open
Dimmer and CH3 must be open
Dimmer and CH2 must be open
)
)
)
18
.
and .
