- Page 1 USER MANUAL ENGLISH ACT Flood 100 RGBW Product code: 34041 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 ACT Flood 100 RGBW Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
ACT Flood 100 RGBW Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 LEDs Lifespan ............................... 4 Text Conventions ..............................5 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................5 Safety .................................. - Page 4 ACT Flood 100 RGBW Fixture Information ............................27 Special Functions ............................28 Manual Operation ............................28 DMX Channels ..............................29 Troubleshooting ..............................31 Maintenance ..............................32 Safety Instructions for Maintenance ......................32 Preventive Maintenance ..........................32 Basic Cleaning Instructions ........................32 Corrective Maintenance ..........................33 Replacing the Fuse .............................33 Deinstallation, Transportation and Storage ....................
-
Page 5: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec ACT Flood 100 RGBW ● Schuko to pro-power cable (1,5 m) ● Barndoor ●... -
Page 6: Text Conventions
ACT Flood 100 RGBW Text Conventions Throughout the user manual the following text conventions are used: ● Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons” ● References: References to chapters and parts of the device are in bold lettering, for example: “Refer to 2. -
Page 7: Safety
ACT Flood 100 RGBW Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children For adult use only. - Page 8 ACT Flood 100 RGBW WARNING Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device.
-
Page 9: Requirements For The User
ACT Flood 100 RGBW Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ● The safety devices are not damaged. ●... -
Page 10: Description Of The Device
ACT Flood 100 RGBW Description of the Device The Showtec ACT Flood 100 RGBW is a compact, yet powerful floodlight for indoor installation in theatres with an asymmetric high-grade reflector with a beam angle of 90° by 105°. The device is delivered with an 8-leaf barndoor. -
Page 11: Barndoor
ACT Flood 100 RGBW Barndoor 15) Safety eye (barndoor) Fig. 04 Product code: 34041... -
Page 12: Product Specifications
ACT Flood 100 RGBW Product Specifications Model: ACT Flood 100 RGBW Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 100 W Fuse: T2 A, 250 V Physical: Dimensions: 280 x 255 x 315 mm (L x W x H) (without the barndoor) Weight: 6,87 kg (with the barndoor) Optics:... -
Page 13: Dimensions
ACT Flood 100 RGBW Dimensions Fig. 05 Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. Personal Protective Equipment During installation and rigging wear personal protective equipment in compliance with the national and site-specific regulations. -
Page 14: Rigging
ACT Flood 100 RGBW Rigging The device can be mounted to a truss or other rigging structure in any orientation. Make sure that all loads are within the pre-determined limits of the supporting structure. CAUTION Restrict the access under the work area during rigging and/or derigging. To mount the device, follow the steps below: 01) Use a clamp to attach the device to the supporting structure, as shown in Fig. -
Page 15: Barndoor Installation
ACT Flood 100 RGBW Fig. 07 Barndoor Installation The ACT Flood 100 RGBW is delivered with a barndoor. To install the barndoor, follow the steps below: 01) Lift the color frame clip (05) and flip it backwards (see Fig. 08). 02) Insert the barndoor into the color frame holders (04) (see Fig. -
Page 16: Connecting To Power Supply
ACT Flood 100 RGBW Connecting to Power Supply DANGER Electric shock caused by short-circuit The device accepts AC mains power at 100–240 V and 50/60 Hz. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. Make sure that the device is always electrically connected to the ground (earth). -
Page 17: Setup
ACT Flood 100 RGBW Setup Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. Stand-alone Setup When the ACT Flood 100 RGBW is not connected to a controller or to other devices, it functions as a stand-alone device. -
Page 18: Dmx Cables
ACT Flood 100 RGBW DMX Cables Shielded twisted-pair cables with 3-pin XLR connectors must be used for reliable DMX connection. You can purchase DMX cables directly from your Highlite International dealer or make your own cables. If you use XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable operation of the DMX network. -
Page 19: Dmx Linking
ACT Flood 100 RGBW DMX Linking To connect multiple devices on one DMX data link, follow the steps below: Use a 3-pin DMX cable to connect the DMX OUT connector of the lighting controller to the DMX IN connector of the first device. 02) Connect the first device’s DMX OUT connector to the second device’s DMX IN connector with a 3-pin DMX cable. -
Page 20: Operation
ACT Flood 100 RGBW Operation Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for. This device is intended for professional use as a theater wash effect. It is suitable only for indoor installation. -
Page 21: Control Panel
ACT Flood 100 RGBW Control Panel A) OLED display ENTER button C) DOWN button D) UP button MENU button Fig. 13 ● Use the MENU button to exit the current submenu, to return to the Main Menu and to return to the start screen. -
Page 22: Menu Overview
ACT Flood 100 RGBW Menu Overview Product code: 34041... - Page 23 ACT Flood 100 RGBW Product code: 34041...
-
Page 24: Main Menu Options
ACT Flood 100 RGBW Main Menu Options The main menu has the following options: Press the UP/DOWN buttons to navigate through the main menu. Press the ENTER button to open the submenus. DMX Functions In this menu you can configure the DMX settings of the device. 01) Press the UP/DOWN buttons to scroll through the following options: ●... -
Page 25: Dmx Fail
ACT Flood 100 RGBW DMX Fail In this pop-up submenu you can determine the behavior of the device in case there is no DMX signal. 01) Press the UP/DOWN buttons to select one of the following 3 options: ● Manually Defined: The device will use the manually selected values for color and color temperature. -
Page 26: Mode
ACT Flood 100 RGBW ● Show Chase: Select the built-in chase. See 6.6.2.2. Show Chase for more information. Press the ENTER button to confirm your choice. Mode In this pop-up submenu menu you can select how to operate the device manually. 01) Press the UP/DOWN buttons to select one of the following 3 options: ●... -
Page 27: Fixture Settings
ACT Flood 100 RGBW Fixture Settings In this menu you can adjust the fixture settings. 01) Press the UP/DOWN buttons to select one of the following 3 options: ● Dimmer Curve: There are 4 options available: Linear, Square Law, Inverse Square Law and S-Curve ●... -
Page 28: Fixture Test
ACT Flood 100 RGBW 03) Press the UP/DOWN buttons to select the desired setting. 04) Press the ENTER button to confirm the selection. Fixture Test In this menu you can perform a test of the device’s parameters and adjust manually the color and the dimmer and strobe values. -
Page 29: Special Functions
ACT Flood 100 RGBW Special Functions In this menu you can reset the device’s settings to the default factory settings. 01) Press the ENTER button to open the pop-up submenu for the factory settings: 02) Press the UP/DOWN buttons to choose between NO and YES. If you choose YES, the device’s settings will be reset to the default factory settings. -
Page 30: Dmx Channels
ACT Flood 100 RGBW DMX Channels 4 CH 7 CH 11 CH Function Value Setting 000–255 From low to high intensity (0–100 %) Green 000–255 From low to high intensity (0–100 %) Blue 000–255 From low to high intensity (0–100 %) White 000–255 From low to high intensity (0–100 %) - Page 31 ACT Flood 100 RGBW 4 CH 7 CH 11 CH Function Value Setting 189–192 Color 48 193–196 Color 49 197–200 Color 50 201–204 Color 51 205–208 Color 52 209–212 Color 53 213–216 Color 54 217–220 Color 55 221–224 Color 56 225–228 Color 57 229–232...
-
Page 32: Troubleshooting
ACT Flood 100 RGBW Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 33: Maintenance
ACT Flood 100 RGBW Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ●... -
Page 34: Corrective Maintenance
ACT Flood 100 RGBW Corrective Maintenance The device does not contain user-serviceable parts. Do not open the device and do not modify the device. Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for more information. Replacing the Fuse DANGER Electric shock caused by short-circuit... -
Page 35: Deinstallation, Transportation And Storage
ACT Flood 100 RGBW Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. - Page 36 ©2022 Showtec...
