Summary of Contents for SHOWTEC FX Station
- Page 1 FX Station ORDERCODE 50402...
- Page 2 Congratulations! You have bought a great, innovative product from Showtec. The Showtec FX Station brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated DMX show, this product provides the effect you need. You can rely on Showtec, for more excellent lighting products.
- Page 3 Showtec Showtec FX Station Product Guide ™ Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Description..…................……….………………………………… Features and Overview ………………………………...….……………….………….………………….…. Backside…………………………………………………...…...….……………….…………………...….…. Installation................…...…………………………………….….. Set Up and Operation..............……..……………………………….… Channel Output and State Control........………………………………………….. 8 CH / 16 CH output console …………………………………………………………………….…. EFFECT / LATCH / FLASH Function ………………………………..………………………….….
-
Page 4: Safety Instructions
WARNING CAUTION! Keep this device away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this device has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely • (preferably in the original packing material), and return it to your Showtec dealer for service. - Page 6 Description of the device Features The Showtec FX Station is a multi control system from Showtec. • Dimming Channels • Switch Channels • Strobe Function • Fog Button Overview Fig. 1 1) Power On/Off: Press to turn On/Off the power.
-
Page 7: Installation
Channel Buttons (X16): These buttons can lock (LATCH) or trigger (FLASH) the relevant channel output. 17) Channel LED: Indicates the working state of the relevant channel output. 18) STANDBY LED: Indicates whether the device is STANDBY. LED On indicates the output is disabled, OFF means output is enabled. - Page 8 • Set the FLASH SPEED switch to OFF, then the strobes will be disabled. Signal Output • The FX Station can control any standard DMX dimmer as well as the strobes. Usage of USB light • When you want to use a USB light, just connect the USB light to the USB socket on the front of the controller, and then turn on the power switch of the USB light.
-
Page 9: Maintenance
Maintenance The Showtec FX Station requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. -
Page 10: Product Specification
Product Specification Model: Showtec FX Station Voltage: 240V-50Hz (CE) USB Output: DC 5V 100mA Strobe Output” Pulse 10Vp-p (frequency adjustable) Audio Line Input: 0.1V~1Vp-p Internal Fuse: 0,5A / 250V Dimensions: 480x83x43mm (LxWxH) Weight: 1,2 kg Design and product specifications are subject to change without prior notice.
