MANUAL
ENGLISH
V1
Order code: 41307
Highlite International B.V. - Vestastraat 2 - 6468 EX - Kerkrade - the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maniac FX 7 and is the answer not in the manual?

Questions and answers

Summary of Contents for SHOWTEC Maniac FX 7

  • Page 1 MANUAL ENGLISH Maniac FX 7 Order code: 41307 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Installation ................................... 8 Setup and Operation ................................ 9 Control Modes ................................9 One Maniac FX 7 (Auto, Built-in programs, Sound-controlled and Manual) ..........9 Multiple Maniac FX 7 fixtures (Master/Slave control) ..................9 Multiple Maniac FX 7 fixtures (DMX512 Mode) ....................10 Fixture Linking ................................11...
  • Page 3: Warning

    Save the carton and all packing materials. In the event that the fixture must be returned to the factory, it is important that the fixture will be returned in the original factory box and packing. Your shipment includes: ● Showtec Maniac FX 7 ● Pro-power to Schuko power cable (1,5 m) ●...
  • Page 4 ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
  • Page 5: Operating Determinations

    Maniac FX 7 Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 0,8 m.
  • Page 6: Connection With The Mains

    Maniac FX 7 The Maniac FX 7 can be placed also on a flat stage floor. Open the two mounting brackets at 90° to assure that the fixture will be stable, and position it on the floor. Turn the bar at the desired angle and tighten the adjustment screws.
  • Page 7: Return Procedure

    Maniac FX 7 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
  • Page 8: Description Of The Device

    Features The Showtec Maniac FX 7 is a two-in-one lighting fixture, featuring a wash with 7 x 7 W High Power pixel- controlled RGB LEDs with a 40° beam angle and a beam with 7 x 3 W Cold White LEDs with a sharp 2°...
  • Page 9: Back View

    14) Microphone 15) Ground connection Installation Remove all packing materials from the Maniac FX 7. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly.
  • Page 10: Setup And Operation

    04) When the Maniac is not connected with a DMX cable, it functions as a stand-alone device. 05) Turn on the music. If the device is set to sound control, then the Maniac FX 7 will react to the beat of the music.
  • Page 11: Multiple Maniac Fx 7 Fixtures (Dmx512 Mode)

    Maniac FX 7 Multiple Maniac fixtures (DMX512 Mode) 01) Fasten the effect light onto firm trussing or mount it on flat surface. Leave at least 0,8 meter on all sides for air circulation. 02) Always use a safety cable (order code 70140 / 70141).
  • Page 12: Fixture Linking

    Maniac FX 7 Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.
  • Page 13: Control Panel

    Maniac FX 7 The Maniac FX 7 can be operated with controller or without controller in stand-alone mode. Control Panel A) LED display B) ENTER button C) DOWN button D) UP button E) MODE button Fig. 05 DMX Control Mode The fixtures are individually addressed on a data-link and connected to the controller.
  • Page 14: Menu Overview

    Maniac FX 7 Menu Overview Order code: 41307...
  • Page 15: Main Menu Options

    Maniac FX 7 Main Menu Options Upon start-up the display will show the current version of the firmware . After 2 seconds the display will show the current operation mode or the current DMX address, if the device is connected to a DMX controller: ●...
  • Page 16: Sound-Controlled Mode

    Maniac FX 7 2. Sound-controlled Mode In this menu you can activate the sound control. 01) Press the MODE button to navigate through the Main Menu until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to select one of the 4 types of sound-controlled programs:...
  • Page 17: Dmx Settings

    Maniac FX 7 4. DMX Settings In this menu you can set the device’s DMX address and select the DMX channel mode. 01) Press the MODE button to navigate through the Main Menu until the display shows 02) Press the ENTER button to confirm the selection. The display shows the DMX starting address of the device 03) Press the ENTER button open the submenu where you can choose the DMX channel modes.
  • Page 18: Dmx Channels

    Maniac FX 7 DMX Channels 3 Channels Channel 1 Blackout 10-39 Auto mode Beam and Wash 40-69 Auto mode Beam 70-99 Auto mode Wash 100-129 Auto mode Mix 130-159 Sound-controlled mode Beam and Wash 160-189 Sound-controlled mode Beam 190-219 Sound-controlled mode Wash...
  • Page 19: Channels

    Maniac FX 7 Channel 2 – Auto mode Mix if CH1 is set between 100-129 0-255 No function Channel 3 – Speed Auto mode CH1 must be set between 10-129 0-255 Gradual speed adjustment, from slow to fast Channel 3 – Speed built-in programs...
  • Page 20: Channels

    Maniac FX 7 Order of the Beam LEDs in 10-, 12- and 15-channel DMX mode: 10 Channels Channel 1 – Beam 1 0-255 Gradual adjustment of the brightness, from low to high intensity (0-100 %) Channel 2 – Beam 2...
  • Page 21: Channels

    Maniac FX 7 12 Channels Channel 1 – Beam 1 CH8 must be open 0-255 Gradual adjustment of the brightness, from low to high intensity (0-100 %) Channel 2 – Beam 2 CH8 must be open 0-255 Gradual adjustment of the brightness, from low to high intensity (0-100 %) Channel 3 –...
  • Page 22: Channels

    Maniac FX 7 15 Channels Channel 1 – Beam 1 CH8 must be open 0-255 Gradual adjustment of the brightness, from low to high intensity (0-100 %) Channel 2 – Beam 2 CH8 must be open 0-255 Gradual adjustment of the brightness, from low to high intensity (0-100 %) Channel 3 –...
  • Page 23 Maniac FX 7 Channel 14 – Built-in programs Beam and Wash CH13 must be set between 10-39 0-14 Program 1 15-29 Program 2 30-44 Program 3 45-59 Program 4 60-74 Program 5 75-89 Program 6 90-104 Program 7 105-119 Program 8...
  • Page 24: Maintenance

    04) The electric power supply cables must not show any damages or material fatigue. The Showtec Maniac FX 7 requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth.
  • Page 25 Maniac FX 7 Problem Probable cause(s) Solution ● Check if power is switched on and One or more fixtures No power to the fixture cables are plugged in do not function at all Primary fuse blown ● Replace fuse Fixtures reset The controller is not connected ●...
  • Page 26: Product Specifications

    Maniac FX 7 Product Specifications Model: Showtec Maniac FX 7 Input Voltage: 100-240 V AC, 50/60 Hz Power Consumption: 80 W max Fuse: T1,6 A/250 V Dimensions: 1006 x 185 x 50 mm (L x W x H) (including bracket)
  • Page 27: Notes

    Maniac FX 7 Notes Order code: 41307...
  • Page 28 ©2019 Showtec...
