- Page 1 USER MANUAL ENGLISH Solaris 5.5 incl. FB4 Product code: 51363 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Solaris 5.5 incl. FB4 ©2022 Showtec. All rights reserved. No part of this document may be copied, published or otherwise reproduced without the prior written consent of Highlite International. Design and product specifications are subject to change without prior notice.
-
Page 3: Table Of Contents
Solaris 5.5 incl. FB4 Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 Text Conventions ..............................4 Acronyms and Abbreviations .......................... 4 Symbols and Signal Words ..........................5 Laser Hazard Labels ............................5 Symbols on the Information Label ........................ - Page 4 Solaris 5.5 incl. FB4 Instructions for Deinstallation ..........................30 Instructions for Transportation ........................30 Storage ................................30 10. Disposal ................................30 11. Approval ................................30 Product code: 51363...
-
Page 5: Introduction
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec Solaris 5.5 incl. FB4 ● Seetronic power cable ● Remote interlock ●... -
Page 6: Symbols And Signal Words
Solaris 5.5 incl. FB4 International Electrical Committee Dutch Standard (Nederlandse Norm) ILDA International Laser Display Association NOHD Nominal Ocular Hazard Distance Ingress Protection OLED Organic Light-Emitting Diode Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. -
Page 7: Symbols On The Information Label
Solaris 5.5 incl. FB4 Symbols on the Information Label This product is provided with an information label. The information label is located at the top panel of the device. The information label contains the following symbols: This device is designed for indoor use. -
Page 8: Safety
Solaris 5.5 incl. FB4 Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 9 Solaris 5.5 incl. FB4 WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. It emits visible radiation in the wavelength range 400–700 nm. Exposure to the direct or scattered laser beam can result in severe eye damage and serious skin injuries.
-
Page 10: Requirements For The User
Solaris 5.5 incl. FB4 Attention For professional use only This device shall be used only for the purposes it is designed for. This device is designed to be used as a professional laser projector. Any incorrect use may lead to hazardous situations and result in injuries and material damage. -
Page 11: Laser Safety
Solaris 5.5 incl. FB4 Laser Safety CAUTION Use of controls or adjustments, or performance of procedures, other than those specified in the user manual, may result in hazardous radiation exposure. Check all applicable national and international regulations concerning laser safety before using this device. -
Page 12: Description Of The Device
Solaris 5.5 incl. FB4 Description of the Device The Solaris 5.5 incl. FB4 is a 5500-mW RGB laser projector with built-in Pangolin FB4 control module, intended for professional use in large venues. By using linear analogue dimming modulation, the Solaris 5.5 can generate the full spectrum of colors. -
Page 13: Back View
Solaris 5.5 incl. FB4 Back View Fig. 04 ILDA-compatible DB-25 connector OUTPUT Power connector OUT, 100–240 V, 50–60 Hz, ILDA-compatible DB-25 connector INPUT max 10 A Ethernet & interlock RJ45 connector Power connector IN, 100–240 V, 50–60 Hz Status LED indicator... -
Page 14: Product Specifications
Solaris 5.5 incl. FB4 Product Specifications Model: Solaris 5.5 incl. FB4 Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 150 W Fuse: 6,3 A, 250 V Physical: Dimensions: 309 x 298 x 288 mm (L x W x H) (without accessories) -
Page 15: Dimensions
Solaris 5.5 incl. FB4 Dimensions Fig. 06 Fig. 07 Product code: 51363... -
Page 16: Installation
Solaris 5.5 incl. FB4 Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. ● Make sure that the device is rigidly mounted to prevent movement due to vibration or jarring. -
Page 17: Personal Protective Equipment
Solaris 5.5 incl. FB4 Attention Make sure that there is enough space for ventilation around the device. ● Do not block the ventilation openings. Without proper heat dissipation and air circulation, the internal components may overheat. This can result in product damage. -
Page 18: Rigging
Solaris 5.5 incl. FB4 Rigging The device is only for overhead mounting. The device can be positioned on a flat surface or mounted to a truss or other rigging structure. Make sure that all loads are within the pre-determined limits of the supporting structure. -
Page 19: Angle Adjustment
Solaris 5.5 incl. FB4 Angle Adjustment You can adjust the angle of the device with the adjustment screws (04). 03) Turn the adjustment screws (04) counterclockwise to release them. Tilt the device at the desired angle (see Fig. 11). Turn the adjustment screws (04) clockwise to tighten them. Make sure that the device cannot move freely after the adjustment screws (04) are tightened. -
Page 20: Power Linking Of Multiple Devices
Do not link more devices on one power link than the maximum recommended number. Maximum recommended number of devices: ● at 100–120 V: 5 devices Solaris 5.5 incl. FB4 ● at 200–240 V: 10 devices Solaris 5.5 incl. FB4 Product code: 51363... -
Page 21: Setup
Solaris 5.5 incl. FB4 Setup Warnings and Precautions WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. Attention Use laser protective eyewear during alignment and setup. During alignment and setup the access of unauthorized persons to the area, where the laser radiation exceeds the spectator MPE, must be restricted. -
Page 22: Setup Example With One Device
Solaris 5.5 incl. FB4 Setup Example with One Device Fig. 13 shows a typical setup with one device. Follow the steps below to connect the device to a computer/lighting controller and the remote interlock: Connect the RJ45 connector of the computer/lighting controller to the Ethernet only RJ45 connector (24) of the device with a CAT-5/CAT-5E/CAT-6 cable. -
Page 23: Setup Example With Multiple Devices
Solaris 5.5 incl. FB4 Setup Example with Multiple Devices Fig. 14 shows a typical setup with multiple device. Follow the steps below to connect the device to a computer/lighting controller, to the remote interlock, and to other devices: Connect the RJ45 connector of the computer/lighting controller to the Ethernet only RJ45 connector (24) of the first device with a CAT-5/CAT-5E/CAT-6 cable. -
Page 24: Using The Safety Devices
Solaris 5.5 incl. FB4 Using the Safety Devices The device is equipped with a key switch, a scan fail function and is supplied with a remote interlock with a key switch. Key Switch The key switch prevents that unauthorized and untrained persons can operate the device. If the key is removed, you cannot operate the device. -
Page 25: Beam Alignment
Solaris 5.5 incl. FB4 Beam Alignment WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. Attention Use laser protective eyewear during alignment and setup. During alignment and setup the access of unauthorized persons to the area, where the laser radiation exceeds the spectator MPE, must be restricted. - Page 26 Solaris 5.5 incl. FB4 Fig. 17 Fig. 18 Turn the beam alignment screws (A) and (B) to adjust the horizontal and vertical positions of the red and blue beams (see Fig. 18): ● beam alignment screws (A) – red color ●...
-
Page 27: Operation
Solaris 5.5 incl. FB4 Operation Safety Instructions for Operation WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. It emits visible radiation in the wavelength range 400–700 nm. Exposure to the direct or scattered laser beam can result in severe eye damage and serious skin injuries. -
Page 28: Control Modes
Solaris 5.5 incl. FB4 Control Modes The device is equipped with a built-in Pangolin FB4 control module. You can control the device: ● manually from the control panel, ● from a laptop/computer with the QuickShow software by Pangolin, ● from a laptop/computer with ILDA software, or ●... -
Page 29: Maintenance
Solaris 5.5 incl. FB4 Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. WARNING Laser radiation Avoid exposure to beam. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. -
Page 30: Corrective Maintenance
Solaris 5.5 incl. FB4 Corrective Maintenance The device does not contain user-serviceable parts. Do not open the device and do not modify the device. Refer repairs and servicing to skilled persons. Contact your Highlite International dealer for more information. Replacing the Fuse... -
Page 31: Deinstallation, Transportation And Storage
Solaris 5.5 incl. FB4 Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. - Page 32 ©2022 Showtec...
