- Page 1 MANUAL ENGLISH FX Ice Jet Ordercode: 61000 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Declaration of Conformity .............................15 Maintenance ..................................16 Troubleshooting ................................16 The FX Ice Jet is leaking .............................16 Only a small smoke plume is visible when the CO gas exits the FX Ice Jet ...........16 No white smoke plume visible when the CO gas exits the FX Ice Jet.............16... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec FX Ice Jet with IEC power cable (1,5 m) ● User manual Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ●... - Page 4 The shooting direction is the direction in which the output pipe on the FX Ice Jet is pointed. The output distance depends on the humidity in the air! The higher the humidity, the longer the output distance.
-
Page 5: Operating Determinations
Always let the installation be carried out by an authorized dealer ! Procedure: ● If the FX Ice Jet is lowered from the ceiling or high joists, professional trussing systems have to be used. ● Use a clamp to mount the FX Ice Jet, with the mounting-bracket, to the trussing system. -
Page 6: Connection With The Mains
Showtec excludes liability for unsafe situations, accidents and damage that are the result of: ● Disregard for the warnings or regulations as set out on the FX Ice Jet or in this manual. ● Use for other purposes or under other circumstances than those set out in this documentation. -
Page 7: Return Procedure
FX Ice Jet Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 8: Description Of The Device
FX Ice Jet Description of the device The Showtec FX Ice Jet is designed to blow white CO smoke streams. As soon as the CO2 leaves the cylinder through the secured high-pressure hoses, it converts into gas. This formation of gas is accompanied by a strong hissing sound, as well as a solid stream of smoke will be visible. -
Page 9: Optional Accessories
FX Ice Jet Optional accessories 61010 - CO2 High Pressure Hose 5 m 61011 - CO2 High Pressure Hose 10 m 61012 - CO2 High Pressure Hose 15 m 70332 - Twenty Clamp SWL 20 kg, TÜV 28 mm 61001 – Ice Gun... -
Page 10: Installation
FX Ice Jet Installation Remove all packing materials from the FX Ice Jet. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. - Page 11 Step 4 01) The FX Ice Jet is activated as soon as it is powered by a 230V electricity source, preferably via a dimming pack. 02) Use a 230V plug and make sure that the electricity is switched OFF! 03) Plug the FX Ice Jet into the electricity socket of a Showtec Relay Pack, Multidim or a Single MKII.
- Page 12 FX Ice Jet. Step 6 01) Connect the hose to the FX Ice Jet and secure it with an open-ended spanner (size 22). Step 7 01) Connect the other end of the hose to the CO bottle (with a dip pipe).
- Page 13 03) If the gas hose is not properly connected, gas can escape. 04) If this is the case, turn the couplings tighter until gas is no longer escaping. 05) The FX Ice Jet is now ready for use. Ordercode: 61000...
-
Page 14: Set Up And Operation
01) Plug the FX Ice Jet’s power connector into the mains power supply. 02) The magnetic valve will immediately open and a white smoke plume will exit from the FX Ice Jet. 03) Unplug the device - the valve will immediately close. - Page 15 03) Disconnect the plug of the FX Ice Jet from the power supply, preferably via a dimming pack. 04) The hose can be disconnected from the gas bottle and the FX Ice Jet only when there is no gas in it.
-
Page 16: Declaration Of Conformity
FX Ice Jet Declaration of Conformity Ordercode: 61000... -
Page 17: Maintenance
The FX Ice Jet is leaking 01) Check if the coupling of the gas hose is connected properly to the coupling of the FX Ice Jet. 02) Press it firmly if it is not entirely secured. This is only possible when there is no pressure on the hose. -
Page 18: Product Specification
FX Ice Jet Product Specification Model: Showtec FX Ice Jet Input Voltage: 230 VAC, 50 Hz Continuous Power: Fuse: F1AL/250V Dimensions: 195 x 125 x 244 mm (LxWxH) Weight: 2,9 kg Operation Input: IEC power connector Input: Liquid CO Output:... -
Page 19: Dimensions
FX Ice Jet Dimensions Ordercode: 61000... - Page 20 ©2019 Showtec...
