Table 1: Frequency
Characteristic
Measurement frequency
Frequency
range, nominal
Frequency
Marker
Residual FM, typical
Span Accuracy
RSA6100A Series Technical Reference
This section lists the RSA6100A Series Real Time-Spectrum Analyzer
specifications. Items listed in the Performance Requirement column are generally
quantitative, and are either tested by the Performance Verification procedure or
are guaranteed by design. Items listed in the Reference Information column are
useful operating parameters that have typical values; information in this column
is not guaranteed.
NOTE.
In these tables, characteristics which are warranted are indicated by a
symbol in the Characteristics column.
The performance limits in these specifications are valid with these conditions:
The spectrum analyzer must have been calibrated and adjusted at an ambient
temperature between +20 °C and +30 °C.
The spectrum analyzer must be in an environment with temperature, altitude,
humidity, and vibration within the operating limits described in these
specifications.
The spectrum analyzer must have had a warm-up period of at least 20 minutes
after starting the RSA6100A application.
RSA6106A
RSA6114A
RSA6120A
Readout Accuracy
Readout Resolution
Description
9 kHz to 6.2 GHz
9 kHz to 14 GHz
9 kHz to 20 GHz
±(RE × MF + 0.001 × Span + 2 ) Hz
RE: Reference Frequency Error
MF: Marker Frequency [Hz]
Reference level dependent
As small as 0.0001 µV
<2 Hz in 1 second at 200 MHz CF, 100 Hz span,
p-p
Freq vs Time mode, Autoscale (95% confidence)
±0.3% of span (Auto mode)
1
