Tektronix RSA6100A Technical Reference page 58

Specifications
Table 52: AM/FM/PM and Direct audio measurements (Option 10)
Characteristic
AM modulation analysis
AM carrier power accuracy, typical
AM depth accuracy, typical
AM rate accuracy, typical
AM residual THD, typical
AM residual distortion, typical
AM residual SINAD, typical
PM modulation analysis
PM carrier power accuracy, typical
PM carrier frequency accuracy,
typical
PM deviation accuracy, typical
PM rate accuracy, typical
PM residual THD, typical
PM residual distortion, typical
PM residual SINAD, typical
Direct audio input
Direct input frequency range (for
audio measurements only)
Maximum audio frequency span
Audio frequency accuracy
Signal power accuracy
Direct audio input residual THD
42
Description
±0.85 dB
±0.2% + (0.005 × measured value)
±0.2 Hz
0.16%
0.13%
56 dB
±0.85 dB
±0.02 Hz + (transmitter frequency × reference
frequency error)
±100% × (0.005 + (measured rate / 1 MHz))
±0.2 Hz
0.1%
1%
40 dB
9 kHz to 10 MHz
10 MHz, maximum
±0.2 Hz
±1.5 dB
0.1%
1 (cont.)
Reference information
Carrier frequency: 10 MHz to 2 GHz
Input power: -20 to 0 dBm
Rate: 1 kHz to 1 MHz
Depth: 10% to 90%
Rate: 1 kHz to 1 MHz
Depth: 50%
Rate: 1 to 10 kHz
Depth: 50%
Rate: 1 to 10 kHz
Depth: 50%
Rate: 1 to 10 kHz
Depth: 50%
Carrier frequency: 10 MHz to 2 GHz
Input power: -20 to 0 dBm
Rate: 1 kHz to 20 kHz
Deviation: 0.2 to 6 radians
Rate: 1 kHz to 10 kHz
Deviation: 0.628 radians
Rate: 1 kHz to 10 kHz
Deviation: 0.628 radians
Rate: 1 kHz to 10 kHz
Deviation: 0.628 radians
Rate: 1 kHz to 10 kHz
Deviation: 0.628 radians
RSA6100A Series Technical Reference
