Input VSWR (Preamp ON -
Option 01 Only)
RSA6100A Series Technical Reference
6. Change the Center frequency from 10 MHz to 4 GHz by 400 MHz steps.
7. Check that the VSWR of the RSA6100A is <1.6 for frequencies from 10 MHz
to 4 GHz, making sure that the RSA6100A center frequency and the Network
Analyzer frequency remain within ±200 MHz of each other. Enter the highest
VSWR in the test record. (Limits are shown in the test record.)
8. Set the START/STOP frequency of the Network Analyzer to 4 GHz/6.2 GHz
and change the center frequency of the RSA6100A from 4 GHz to 6.2 GHz
by 400 MHz steps.
9. Check that the VSWR of the RSA6100A is <1.8 for frequencies from 4 GHz
to 6.2 GHz, making sure that the RSA6100A center frequency and the
Network Analyzer frequency remain within ±200 MHz of each other. Enter
the highest VSWR in the test record. (Limits are shown in the test record.)
10. RSA6114A Only: Set the START/STOP frequency of the Network Analyzer
to 6.2 GHz/ 14 GHz and change the center frequency of the RSA6100A from
6.2 GHz to 14 GHz by 400 MHz steps.
11. RSA6120A Only: Set the START/STOP frequency of the Network Analyzer
to 6.2 GHz/ 20 GHz and change the center frequency of the RSA6100A from
6.2 GHz to 20 GHz by 400 MHz steps.
12. Check (RSA6114A only) that the VSWR of the RSA6100A is <1.9 for
frequencies from 6.2 GHz to 14 GHz, making sure that the RSA6100A center
frequency and the Network Analyzer frequency remain within ±200 MHz of
each other. Enter the highest VSWR in the test record. (Limits are shown in
the test record.)
13. Check (RSA6120A only) that the VSWR of the RSA6100A is <1.9 for
frequencies from 6.2 GHz to 20 GHz, making sure that the RSA6100A center
frequency and the Network Analyzer frequency remain within ±200 MHz of
each other. Enter the highest VSWR in the test record. (Limits are shown in
the test record.)
1. Turn the Preamp on.
NOTE.
Preamp control is located on the Amplitude menu.
2. Set the RSA6100A Center frequency to 1.5 GHz.
3. Set the Network Analyzer span to 10 MHz to 3.0 GHz.
4. Check that the VSWR of the RSA6100A is <1.9 across the entire frequency
span. Enter the maximum VSWR in the test record. (Limits are shown in
the test record.)
Performance Verification
67
