Table 20: Spurious response with signal

Span ≤ 40 MHz,
Swept Spans > 40 MHz
Frequency Specification
30 MHz - –73 dBc
6.2 GHz
≥6.2 GHz –70 dBc
- 20 GHz
(RSA6114A
and RSA6120A
only)
1
1 In 110 mode CF > 80 MHz, after alignment.

Table 21: Acquisition

Characteristic
Real-time Capture Bandwidth,
nominal
Demodulation Bandwidth
A/D Converter, nominal
RSA6100A Series Technical Reference
Typical
–78 dBc
–75 dBc
Description
40 MHz (RF, 40 MHz Version)
110 MHz (RF, 110 MHz Version)
40 MHz (RF, 40 MHz Version)
110 MHz (RF, 110 MHz Version)
14 bits, 100 Ms/s (40 MHz Version)
14 bits, 100 Ms/s & 12 bits, 300 Ms/s (110 MHz Version, Serial Numbers B010XXX)
14 bits, 100 Ms/s, 300 Ms/s (110 MHz Version, RSA6106A and RSA6114A Serial Number
B020XXX and above, all RSA6120A)
For Option 110 1
40 MHz < Span ≤ 110 MHz
Specification
–73 dBc
–70 dBc
Specifications
Typical
–75 dBc
–75 dBc
15
