Tektronix RSA6100A Technical Reference page 23

Table 7: Noise and distortion (cont.)
Characteristic
3rd Order Intermodulation Distortion
Specified
Typical
Each signal level –25 dBm at the RF input. 1 MHz tone separation. Attenuator = 0, Ref Level = –20 dBm.
2 Harmonic Distortion, typical. Preamp OFF
nd
10 MHz to 3.1 GHz (–40 dBm at RF
Input, Atten = 0)
3.1 GHz to 7 GHz (RSA6114A Only)
(–25 dBm at RF Input, Atten = 0)
3.1 GHz to 10 GHz (RSA6120A Only)
(–25 dBm at RF Input, Atten = 0,
Preamp OFF, ) RF & IF Optimization set
to "Maximize Dynamic Range".
Displayed Average Noise Level (DANL) Normalized to 1 Hz RBW, with Average of Logs detector (RSA6106A and RSA6114A only)
Preamp OFF (best noise mode)
Preamp ON (option 01 only)
RSA6100A Series Technical Reference
Description
2.130 GHz –80 dBc
Each signal level -25 dBm at the RF input. 1 MHz tone separation. Attenuator = 0, Ref
Level = –20 dBm.
9 kHz to 100 MHz <–77 dBc
<–80 dBc
100 MHz to 3 GHz
3 GHz to 6.2 GHz <–84 dBc
6.2 GHz <–84 dBc
to 14 GHz
(RSA6114A only)
<–80 dBc
<–80 dBc
<–80 dBc
Specification
9 kHz to 10 MHz –99 dBm/Hz
10 MHz to –149 dBm/Hz
100 MHz
100 MHz to
–151 dBm/Hz
2.3 GHz
2.3 GHz to 4 GHz –149 dBm /Hz
4 GHz to 6.2 GHz –145 dBm /Hz
6.2 GHz to 7 GHz –145 dBm /Hz
(RSA6114A only)
7 GHz to 14 GHz –137 dBm /Hz
(RSA6114A only)
Specification
10 MHz to 50 MHz –162 dBm/Hz
50 MHz to 1 GHz –167 dBm/Hz
1 GHz to 2 GHz –168 dBm/Hz
2 GHz to 3 GHz –166 dBm/Hz
Specifications
Typical
–102 dBm/Hz
–151 dBm/Hz
–153 dBm/Hz
–151 dBm /Hz
–147 dBm /Hz
–147 dBm /Hz
–139 dBm /Hz
Typical
–170 dBm/Hz
–170 dBm/Hz
–170 dBm/Hz
–170 dBm/Hz
7
