Performance Verification
DANL - Preamp ON (Option
01 Only)
82
Table 67: Frequencies of interest for DANL check (cont.)
Center frequency
15.0 GHz
16.0 GHz
17.0 GHz
18.0 GHz
19.0 GHz
20.0 GHz
6. Enter the highest noise level for each of the frequency ranges shown into the
test record. (Limits are shown in the test record.)
1. Continuing from the previous step, change the RSA6100A settings:
Reference Level
Preamp
2. Use Marker 1 to measure the noise level, in dBm/Hz (Absolute readout), at
each of the Center Frequencies shown in the following table:

Table 68: Frequencies of interest for DANL check (Option 01)

Center frequency
10 MHz
49 MHz
51 MHz
990 MHz
1.01 GHz
1.99 GHz
2.01 GHz
3 GHz
3. Enter the highest noise level for each of the frequency ranges shown into the
test record. (Limits are shown in the test record.)
Noise level
–70 dBm
ON
Noise level
RSA6100A Series Technical Reference
Frequency range
15.0 GHz - 20.0 GHz
(RSA6120A only)
Frequency range
10 MHz - 50 MHz
50 MHz - 1 GHz
1 GHz - 2 GHz
2 GHz - 3 GHz
