Specifications
Table 46: Digital demodulation accuracy (Option 21); applies to instruments manufactured after June 2009 (cont.)
Characteristic
S-OQPSK CF
(ARTM)
Symbol Rate
Residual EVM,
Reference Filter: ARTM STD, Measurement Filter: None
typical
S-OQPSK CF
(ARTM)
Symbol Rate
Residual EVM,
typical
Reference Filter: ARTM STD, Measurement Filter: None
S-BPSK (MIL) CF
Residual EVM,
Symbol Rate
typical
Reference Filter: MIL STD, Measurement Filter: None
S-BPSK (MIL) CF
Residual EVM,
Symbol Rate
typical
Reference Filter: MIL STD, Measurement Filter: None
CPM (MIL) CF
Residual EVM,
Symbol Rate
typical
Reference Filter: MIL STD, Measurement Filter: None
CPM (MIL) CF
Residual EVM,
Symbol Rate
typical
Reference Filter: MIL STD, Measurement Filter: None
2/4/8/16 FSK CF
Residual RMS
Symbol Rate
FSK Error,
typical

Table 47: OFDM measurement (Option 22)

Characteristic
OFDM Maximum Residual
EVM(RMS)
(802.11a/g/j OFDM and
802.16-2004)
36
4 kHz
20 kHz
100 kHz
1 MHz
4 kHz
20 kHz
100 kHz
1 MHz
4 kHz
20 kHz
100 kHz
1 MHz
10 kHz
Description
-44 dB (typical)
Description
250 MHz
0.3%
2 GHz
0.5%
0.5%
0.5%
250 MHz
0.2%
2 GHz
0.5%
0.5%
0.5%
250 MHz
0.3%
2 GHz
0.5%
0.5%
0.5%
2 GHz
0.6%
RSA6100A Series Technical Reference
