Specifications
Table 6: Amplitude and RF flatness (excluding mismatch error)
Characteristic
Absolute amplitude accuracy at calibration point (RF)
Absolute amplitude accuracy at all center frequencies (18 °C to 28 °C)
10 MHz to 3 GHz
3 GHz to 6.2 GHz
6.2 GHz to 14 GHz (RSA6114A only)
6.2 GHz to 20 GHz (RSA6120A only)
Level Linearity
1
All amplitude and frequency response measurements made with Preamp OFF, except where noted, and Flattop window filter used to maximize CW amplitude
measurement accuracy.
2 Reference Level ≤ –15 dBm, –15 dBm to –50 dBm. 10 Hz ≤ RBW ≤ 1 MHz, after alignment performed.

Table 7: Noise and distortion

Characteristic
1 dB 100 MHz to 3 GHz
Compression
3 GHz to 6.2 GHz
Input
6.2 GHz to 14 GHz (RSA6114A only)
6.2 GHz to 20 GHz (RSA6120A only)
3rd Order IM Intercept – RSA6106A and RSA6114A
Typical
3rd Order IM Intercept – RSA6120A
Typical
6
2 , 95% confidence
Description
>+9 dBm
>+12 dBm
>+12 dBm
>+12 dBm
9 kHz to 100 MHz +13.5 dBm
100 MHz to 3 GHz +15 dBm
3 GHz to 6.2 GHz +17 dBm
+17 dBm
6.2 GHz
to 14 GHz
(RSA6114A only)
9 kHz to 100 MHz +14.5 dBm
100 MHz to 3 GHz +20 dBm
+19 dBm
3 GHz to 6.2 GHz
6.2 GHz to +19 dBm
20 GHz
1 (cont.)
Description
±0.31 dB
±0.5 dB
±0.8 dB
±1.5 dB
±1.5 dB
±0.1 dB (0 dB to –70 dB Below Reference Level)
Set Setup > Amplitude > Internal
Settings > RF & IF Optimization to
Maximize Dynamic Range.
Set Setup > Amplitude > Internal
Settings > RF & IF Optimization to
Maximize Dynamic Range.
RSA6100A Series Technical Reference
