Table 4: Maximum Input Level; Table 5: Input Attenuator; Table 6: Amplitude And Rf Flatness (Excluding Mismatch Error) - Tektronix RSA6100A Technical Reference

Table 4: Maximum input level

Characteristic
Maximum DC voltage
Maximum safe input power
Maximum Measureable input
power

Table 5: Input attenuator

Characteristic
RF Attenuator (9 kHz to 20 GHz)
Table 6: Amplitude and RF flatness (excluding mismatch error)
Characteristic
Reference level setting range, nominal
Frequency response (18 °C to 28 °C)
10 dB RF
attenuator
setting
All RF attenuator
settings, typical
Frequency response (0 °C to 50 °C), typical
All RF attenuator
settings
Input attenuator switching uncertainty
RSA6100A Series Technical Reference
Description
±40 V (RF Input)
+30 dBm (RF Input, RF ATT ≥10 dB)
+75 Watts peak (RF Input, RF ATT ≥30 dB (<10 µs Pulse Width, 1% Duty Cycle repetitive
Pulses)
+ 30 dBm (RF Input, RF ATT Auto)
+ 75 Watts peak (RF Input, RF ATT Auto), (<10 μs Pulse Width, 1% Duty Cycle repetitive
pulses)
Description
0 dB to 75 dB (5 dB step), nominal
10 MHz to 3 GHz Preamp
OFF
10 MHz to 3 GHz Preamp ON
(Option 01 only)
3 GHz to 6.2 GHz
6.2 GHz to 14 GHz
(RSA6114A only)
6.2 GHz to 20 GHz
(RSA6120A only)
9 kHz to 10 MHz
9 kHz to 10 MHz
10 MHz to 3 GHz
3 GHz to 6.2 GHz
6.2 GHz to 14 GHz
(RSA6114A only)
6.2 GHz to 20 GHz
(RSA6120A only)
1
Description
–170 dBm to +50 dBm, 0.1 dB step, (Standard RF
input) Minimum ref level –50 dBm at CF < 70 MHz
±0.5 dB
±0.7 dB
±0.8 dB
±1.0 dB
±1.0 dB
±0.7 dB
±0.7 dB
±0.7 dB
±0.8 dB
±2.0 dB
±2.0 dB
±0.2 dB
Specifications
5
