MTD200 MPEG Test Decoder User Manual
Table 5–8: Definition of bits used in the Event Status Register (cont.)
Bit No. Definition
4 Execution Error
This bit is set if the syntax of the command received is not correct but the command
cannot be executed due to various marginal conditions. An error message with a
number between –200 and –300 describing the error in greater detail (refer to Error
Messages of Remote-Control Interface on page 5–63) will be entered into the Error
Queue.
5 Command Error
This bit is set if an undefined command or a command with incorrect syntax is
received. An error message with a number between –100 and –200 describing the
error in greater detail (refer to Error Messages of Remote-Control Interface on
page 5–63) will be entered into the Error Queue.
6 User Request
This bit is set upon switchover from [REMOTE] to [LOCAL] (that is, when the
instrument is switched to manual operation by means of the LOCAL key).
7 Power On (AC supply on)
This bit is set upon power on of the instrument.
STATus:OPERation Register. The OPERation Status Register contains information
on the operations currently performed by the instrument.
It can be read by the queries STATus:OPERation:CONDition? or STATus:OP-
ERation[:EVENt]?.
Table 5–9: Definition of bits used in the STATus:OPERation Register
Bit No. Definition
1 SETTling
This bit is set as long as settling takes place following a new setting command. The
bit is only set if the settling time is longer than the command processing time.
4 MEASuring
This bit is set while the instrument is performing a measurements and the results
are not yet stable.
5 Waiting for TRIG
This bit is set if the instrument is active in the Trigger on Error and DUMP mode.
8 HCOPy
This bit is set when the print function is active.
Remote Control
5–55
