Appendix A: Interfaces
A–6
Table A–4: Parity settings COM1
Value for PARITY
none
even
odd
one
zero
Table A–5: Data bit setting COM1 (fixed)
Number of data bits
8
Table A–6: Stop bit setting COM1 (fixed)
Number of stop bits
1
Table A–7: Pace settings COM1
Value for PACE
none
XON/XOFF
RTS/CTS
Meaning
no parity check
even parity
odd parity
Parity bit logic 1
Parity bit logic 0
Meaning
No special interface protocol
XON/XOFF protocol
Hardware handshake
