Remote Control
Commands of TS INPUT
Menu
Command
ROUTe
:INPut[?]
SENSe
:SCONdition
:LOCK[?]
:DROP[?]
5–28
In the TS INPUT menu, the input is selected and the hysteresis for synchroniza-
tion of the MPEG test decoder is set.
Parameter
RSERial|FSERial|FPARallel
1 to 31
1 to 7
ROUTe :INPut RSERial | FSERial | FPARallel
*RST value:
The command selects the signal input for the transport stream.
RSERial
FSERial
FPARallel
Example:
SENSe :SCONdition
This node provides the commands for setting the hysteresis for synchronization
to the MPEG2 transport stream.
SENSe :SCONdition :LOCK 1 to 31
*RST value:
This command sets the number of consecutive valid data words required before
the decoder detects synchronization.
Example:
SENSe :SCONdition :DROP 1 to 7
*RST value:
Sets the number of consecutive invalid data words required before the decoder
detects a drop-out.
Example:
Unit
FSERial
serial, asynchronous input (T link) at the rear
serial, asynchronous input (T link) at the front
parallel input (LVDS) at the front
ROUT:INP FSER
5
SENS:SCON:LOCK 5
2
SENS:SCON:DROP 2
MTD200 MPEG Test Decoder User Manual
Notes
Selects signal input
Number of consecutive valid sync words
received before synchronization is
detected.
Number of consecutive invalid sync
words received before unlocking is
detected.
