JVC HR-XV2EX Service Manual page 83

# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R2F6 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2F7 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2F8 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R2F9 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R2G1 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R2G2 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R2G3 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2G4 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2G7 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2G9 NRSA63J 151X RESISTOR,METAL GLAZED(CHIP)
R2M1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2M2 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2M3 NRSA63J 752X RESISTOR,METAL GLAZED(CHIP)
R2M5 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2M6 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2M7 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2M8 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2M9 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2N0 NRSA63J 123X RESISTOR,METAL GLAZED(CHIP)
R2N1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2N2 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2N3 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2N4 NRSA63J 153X RESISTOR,METAL GLAZED(CHIP)
R2N5 NRSA63J 123X RESISTOR,METAL GLAZED(CHIP)
R2N6 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2N7 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2N8 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2N9 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2P0 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R2P1 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2P2 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2P3 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2P7 NRSA63J 223X RESISTOR,METAL GLAZED(CHIP)
R2P8 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R2P9 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R2Q1 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R2R1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2R2 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R303 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R306 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R307 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R308 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R309 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R310 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R315 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R317 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R318 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R319 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R320 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R321 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R322 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R323 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R364 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R365 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R366 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R367 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R368 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R369 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R370 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R371 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R3F1 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R3F2 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R3F3 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R3F4 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R3F5 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R401 NRSA63J 180X RESISTOR,METAL GLAZED(CHIP)
R403 NRSA63J 100X RESISTOR,METAL GLAZED(CHIP)
R404 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R405 NRSA63J 182X RESISTOR,METAL GLAZED(CHIP)
R406 NRSA63J 182X RESISTOR,METAL GLAZED(CHIP)
R407 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R409 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R410 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R411 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R412 NRSA63J 182X RESISTOR,METAL GLAZED(CHIP)
R413 NRSA63J 822X RESISTOR,METAL GLAZED(CHIP)
R414 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R415 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R416 NRSA63J 822X RESISTOR,METAL GLAZED(CHIP)
R417 NRSA63J 182X RESISTOR,METAL GLAZED(CHIP)
R418 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R419 NRSA63J 331X RESISTOR,METAL GLAZED(CHIP)
R420 NRSA63J 331X RESISTOR,METAL GLAZED(CHIP)
R428 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
6-12
(VP)-D2VP11
NSP:Not Service Parts
SPECIFICATION NSP
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
150 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
7.5K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
12K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
15K OHM 1 / 16 W 1608 5.00% D
12K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
22K OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
18 OHM 1 / 16 W 1608 5.00% D
10 OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
1.8K OHM 1 / 16 W 1608 5.00% D
1.8K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
1.8K OHM 1 / 16 W 1608 5.00% D
8.2K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
8.2K OHM 1 / 16 W 1608 5.00% D
1.8K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
330 OHM 1 / 16 W 1608 5.00% D
330 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
E. & O. E. No.82984 HR-XV2EX,HR-XV2EY,HR-XV2EL,HR-XV11EX
# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R429 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R430 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R431 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R432 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R433 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R434 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R435 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R436 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R437 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R438 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R439 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R440 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R441 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R501 NRSA63J 332X RESISTOR,METAL GLAZED(CHIP)
R502 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R503 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R504 NRSA6AD 151W RESISTOR,METAL GLAZED(CHIP)
R505 NRSA63J 100X RESISTOR,METAL GLAZED(CHIP)
R506 NRSA6AD 102W RESISTOR,METAL GLAZED(CHIP)
R507 NRSA63J 111X RESISTOR,METAL GLAZED(CHIP)
R508 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R509 NRSA63J 111X RESISTOR,METAL GLAZED(CHIP)
R510 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R514 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R515 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R516 LG 6200JB8010V FILTER(CIRC),EMC
R520 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R521 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R522 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R523 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R524 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R525 LG 0LC0233002B INDUCTOR,CHIP
R530 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R531 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R532 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R533 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R534 NRSA63J 681X RESISTOR,METAL GLAZED(CHIP)
R535 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R541 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R588 NRSA6AD 151W RESISTOR,METAL GLAZED(CHIP)
R589 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R590 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R591 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R592 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R602 NRSA63J 681X RESISTOR,METAL GLAZED(CHIP)
R603 NRSA6AD 821W RESISTOR,METAL GLAZED(CHIP)
R604 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R605 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R606 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R607 NRSA63J 332X RESISTOR,METAL GLAZED(CHIP)
R609 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
X201 LG 6202R BM04C RESONATOR,CRYSTAL
X501 LG 6212AA2271F RESONATOR,CRYSTAL
X501 LG 6202R BL06C RESONATOR,CRYSTAL
SPECIFICATION NSP
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
3.3K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
150 OHM 1 / 16 W 1608 1.00% D
10 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 1.00% D
110 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
110 OHM 1 / 16 W 1608 5.00% D
22 OHM 1 / 16 W 1608 5.00% D
22 OHM 1 / 16 W 1608 5.00% D
22 OHM 1 / 16 W 1608 5.00% D
LFA20 2A1E473MT MITSUBISHI MAT
22 OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
HB 1S1608 800JT CERATECH R/TP
1.2K OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
150 OHM 1 / 16 W 1608 1.00% D
75 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 16 W 1608 5.00% D
820 OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
3.3K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
HC 49/S BUBANG 33 8688MHZ 5
HC 49S KITELCO 27MHZ +/ 20 PP
HC 49/S BUBANG 27MHZ 20PPM 1
