JVC HR-XV2EX Service Manual page 81

# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
ZD501 UZ7.5BSB DIODE,ZENER
ZD501 UZ7.5BSB DIODE,ZENER
ZD701 MTZJ5.6C DIODE,ZENER
******************************
DVD BOARD ASSEMBLY
A46A LG 6885R 7422B SUB PWB(PCB) ASSEMBLY
C201 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C202 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C203 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C204 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C205 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C206 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C207 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C208 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C209 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C210 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C211 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C212 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C213 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C214 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C215 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C216 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C224 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C225 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C226 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C229 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C230 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C231 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C232 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C238 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C239 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C240 LG 0CH1222K562 CAPACITOR,CHIP[CERAMIC M/L HD 2200PF 50V K X7R(X) 1608 R/TP
C242 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C245 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C251 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C252 LG 0CH4100K112 CHIP CAPA CERAMIC M/L T.C F/S
C253 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C254 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C255 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C258 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C261 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C262 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C263 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C264 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C265 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C272 QET61CM 476 CAPACITOR,ELECTROLYTIC
C273 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C274 QET61CM 476 CAPACITOR,ELECTROLYTIC
C277 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C278 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C279 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C280 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C281 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C282 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C284 QET61CM 476 CAPACITOR,ELECTROLYTIC
C285 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C286 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C287 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C288 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C289 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C290 NDC31HJ 180X CAPACITOR,CHIP[CERAMIC M/L TC 18P 50V J COG 1.6X0.8 R/TP
C291 NDC31HJ 180X CAPACITOR,CHIP[CERAMIC M/L TC 18P 50V J COG 1.6X0.8 R/TP
C292 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C293 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C294 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C295 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C296 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C297 QET61CM 476 CAPACITOR,ELECTROLYTIC
C298 LG 0CE4775C638 CAPACITOR,FIXED ELECTROLYTIC 470UF SR,SV 6.3V 20% FM5 TP 5
C2A0 QET61CM 476 CAPACITOR,ELECTROLYTIC
C2A3 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2A4 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C2A5 LG 0CH1683F942 CAPACITOR,FIXED CERAMIC(Temp.c 0.068UF 16V 80%, 20% Y5V(F) 16
C2A6 LG 0CH1102K562 CAPACITOR,FIXED CERAMIC(Temp.c 1000PF 50V 10% X7R(X) 1608 R/T
C2A7 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2A8 LG 0CH1152K562 CAPACITOR,FIXED CERAMIC(Temp.c 1500PF 50V 10% X7R(X) 1608 R/T
C2A9 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2B3 LG 0CH1392K562 CAPACITOR,FIXED CERAMIC(Temp.c 3900PF 50V K Z5U(E) 1608 R/TP
C2B4 LG 0CH1683F942 CAPACITOR,FIXED CERAMIC(Temp.c 0.068UF 16V 80%, 20% Y5V(F) 16
C2B5 LG 0CH1333K562 CAPACITOR,CHIP[CERAMIC M/L HD 0.033UF 50V K X7R(X) 1508 R/TP
6-10
NSP:Not Service Parts
SPECIFICATION NSP
UZ 7.5BSB 26MM TP PYUNG CHANG
UZ 7.5BSB 26MM TP PYUNG CHANG
MTZ5.6C TP(26MM) ROHM 5.6V
< >
50
VJW602CP SERIES DI (444500D212
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10P 50V D COG 1.6X0.8 R/TP
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
C2B9 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2C1 LG 0CH1103K562 CAPACITOR,FIXED CERAMIC(Temp.c 0.01UF 50V 10% X7R(X) 1608 R/T
C2C2 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C2C4 LG 0CH1102K562 CAPACITOR,FIXED CERAMIC(Temp.c 1000PF 50V 10% X7R(X) 1608 R/T
C2C5 LG 0CH1332K562 CAPACITOR,CHIP[CERAMIC M/L HD 3300P 50V K X7R 1.6X0.8 R/TP
C2C6 LG 0CH1102K562 CAPACITOR,FIXED CERAMIC(Temp.c 1000PF 50V 10% X7R(X) 1608 R/T
C2C8 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2C9 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C2D0 QET61CM 476 CAPACITOR,ELECTROLYTIC
C2D1 QET61CM 476 CAPACITOR,ELECTROLYTIC
C2D2 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2D3 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2D4 QET61CM 476 CAPACITOR,ELECTROLYTIC
C2D5 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C2D6 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2D7 LG 0CH1152K562 CAPACITOR,FIXED CERAMIC(Temp.c 1500PF 50V 10% X7R(X) 1608 R/T
C2D9 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M1 QET61CM 107Z CAPACITOR,ELECTROLYTIC
C2M2 LG 0CH1682K562 CAPACITOR,CHIP[CERAMIC M/L HD 6800P 50V K X7R 1.6X0.8 R/TP
C2M3 LG 0CH1472K562 CAPACITOR,CHIP[CERAMIC M/L HD 4700PF 50V K X7R(X) 1608 R/TP
C2M4 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M5 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M6 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M7 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M8 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2M9 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2N1 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C2N3 LG 0CH1223K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.022UF 50V Z Y5V(F) 1508 R/TP
C2N4 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C301 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C302 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C303 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C304 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C305 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C306 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C307 LG 0CH1105D942 CAPACITOR,CHIP[CERAMIC M/L HD 1UF 10V Z Y5V(F) 1508 R/TP
C308 QET61CM 476 CAPACITOR,ELECTROLYTIC
C309 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C314 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C316 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C317 QET61CM 476 CAPACITOR,ELECTROLYTIC
C318 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C319 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C320 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C321 QET61CM 476 CAPACITOR,ELECTROLYTIC
C323 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C324 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C3F1 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C3F2 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C3F3 QET61CM 476 CAPACITOR,ELECTROLYTIC
C401 QET61CM 226 CAPACITOR,ELECTROLYTIC
C402 QET61CM 226 CAPACITOR,ELECTROLYTIC
C403 QET61CM 226 CAPACITOR,ELECTROLYTIC
C404 QET61CM 226 CAPACITOR,ELECTROLYTIC
C405 QET61CM 476 CAPACITOR,ELECTROLYTIC
C406 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C408 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C409 LG 0CE2274C638 CAPACITOR,ELECTROLYTIC
C410 LG 0CH4271K412 CAPACITOR,FIXED CERAMIC(HIGH D 270PF 50V 5% NP0 1608 R/TP
C411 LG 0CH1102K512 CAPACITOR,FIXED CERAMIC(Temp.c 1000PF 50V 10% B(5YP) 1608 R/T
C412 LG 0CH4271K412 CAPACITOR,FIXED CERAMIC(HIGH D 270PF 50V 5% NP0 1608 R/TP
C413 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C414 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C415 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C416 LG 0CH1102K512 CAPACITOR,FIXED CERAMIC(Temp.c 1000PF 50V 10% B(5YP) 1608 R/T
C417 LG 0CH4271K412 CAPACITOR,FIXED CERAMIC(HIGH D 270PF 50V 5% NP0 1608 R/TP
C418 LG 0CH1392K562 CAPACITOR,FIXED CERAMIC(Temp.c 3900PF 50V K Z5U(E) 1608 R/TP
C419 QET61CM 226 CAPACITOR,ELECTROLYTIC
C420 LG 0CH1392K562 CAPACITOR,FIXED CERAMIC(Temp.c 3900PF 50V K Z5U(E) 1608 R/TP
C421 QET61CM 226 CAPACITOR,ELECTROLYTIC
C422 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C423 LG 0CH4271K412 CAPACITOR,FIXED CERAMIC(HIGH D 270PF 50V 5% NP0 1608 R/TP
C424 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C425 LG 0CH1104K942 CAPACITOR,CHIP[CERAMIC M/L HD 0.1UF 50V Z Y5V(F) 1508 R/TP
C501 QET61CM 476 CAPACITOR,ELECTROLYTIC
C502 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C503 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C504 QET61CM 106Z CAPACITOR,ELECTROLYTIC
C506 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C507 QET61CM 476 CAPACITOR,ELECTROLYTIC
C508 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C509 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C510 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C511 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
SPECIFICATION NSP
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
100U SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
220M SRA 6.3V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
22M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
