JVC HR-XV2EX Service Manual page 28

E. Picture abnormal
PICTURE ABNORMAL
Check the disc.
Refer to Servo part
If OK
Check MPEG_CLK Signal
(IC501 Pin22) of MPEG part
YES (If OK)
Check DSP
YES (If OK)
Check MPEG
YES (If OK)
Replace Main B/D
F. Disc Error
DISC ERROR
Check Disc
YES (If OK)
Refer to Servo part
YES (If OK)
Replace main B/D
3-54
