MECHANISM TROUBLESHOOTING GUIDE
C.
Cassette does not load.
Does the cassette insert?
YES
Does the Opener Lid work?
YES
Does the Gear Assembly Rack F/L
work?
YES
Does the Opener Door work?
YES
Does the Arm Assembly F/L work?
YES
Does the L/D Motor work?
YES
Does the Holder Assembly Cassette
move the Arm Assembly F/L?
YES
Replace the Front Loading
Mechanism Assembly.
NO
NO
NO
NO
NO
NO
Replace the Opener Lid.
Replace the Gear Rack F/L.
Check the opener Door assembled
correctly.
Replace the Arm Assembly F/L.
Check the power of L/D Motor.
Check the Holder Assembly Cassette
assembled correctly.
