JVC HR-XV2EX Service Manual page 82

# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
C512 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C513 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C514 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C515 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C516 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C517 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C518 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C519 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C520 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C521 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C522 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C523 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C525 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C526 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C527 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C528 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C529 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C530 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C531 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C532 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C533 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C534 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C535 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C536 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C538 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C540 NDC31HJ 220X CAPA,CHIP CERAMIC M/L T.C F/S
C541 NDC31HJ 270X CAPACITOR,CHIP[CERAMIC M/L TC 27PF 50V J NP0 1608 R/TP
C542 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C543 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C544 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C546 NDC31HJ 221X CAPACITOR,CHIP[CERAMIC M/L TC 220P 50V J COG 1.6X0.8 R/TP
C549 NDC31HJ 221X CAPACITOR,CHIP[CERAMIC M/L TC 220P 50V J COG 1.6X0.8 R/TP
C550 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C553 NDC31HJ 221X CAPACITOR,CHIP[CERAMIC M/L TC 220P 50V J COG 1.6X0.8 R/TP
C554 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C555 NDC31HJ 101X CHIP CAPA CERAMIC M/L T.C F/S
C556 NDC31HJ 101X CHIP CAPA CERAMIC M/L T.C F/S
C557 NDC31HJ 270X CAPACITOR,CHIP[CERAMIC M/L TC 27PF 50V J NP0 1608 R/TP
C558 NCF31CZ 104X CAPACITOR,FIXED CERAMIC(Temp.c 0.1UF 16V 80%, 20% Y5V(F) 1608
C559 QET61CM 476 CAPACITOR,ELECTROLYTIC
C560 LG 0CH1225F944 CAPACITOR,FIXED CERAMIC(Temp.c 2.2UF 16V 80%, 20% Y5V(F) 3216
C561 QET61CM 476 CAPACITOR,ELECTROLYTIC
D2A1 DAN202K X DIODE,SWITCHING
D2A2 DAN202K X DIODE,SWITCHING
D2A3 DAN202K X DIODE,SWITCHING
D401 DAP202K X DIODE,SWITCHING
IC201 LG 0ILNRHY002B IC,LINEAR
IC206 TCW04FU X IC,TOSHIBA
IC2A1 LG 0ILNRHI003A IC,LINEAR
IC2A2 NJM3414AM X IC,JRC
IC2A4 LG 0IKE393000G IC,KEC
IC2M1 LG 0IFA303200A IC,FAIRCHILD
IC2M1 LG 0ILNRFA013A IC,LINEAR
IC301 LG 0IXL957210C IC,XILINX
IC301 LG 0ICTMHY011A IC,CUSTOMIZED
IC305 LG 0IHY576532A IC,HYUNDAI
IC305 LG 0IMMRHY025A IC,MEMORIES
IC3F1 LG 0IMMRFU001B IC,MEMORIES
IC3F1A LG 6957R 412AA PROGRAM
IC401 LG 0IPRPCI003B IC,PERIPHERALS
IC402 NJM4580M X IC,JRC
IC501 LG 0INS860200A IC,NATIONAL SEMICONDUCTOR
IC502 LG 0IMMRCB001A IC,MEMORIES
IC502 LG 0IMMRAL012A IC,MEMORIES
IC503 LG 0IFA742440F IC,FAIRCHILD
IC506 LG 0IPMGA7001A IC,POWER MANAGEMENT
L201 LG 6200HJC102A FILTER(CIRC),EMC
L206 LG 6200HJC102A FILTER(CIRC),EMC
L207 LG 6200HJC102A FILTER(CIRC),EMC
L208 LG 6200HJC102A FILTER(CIRC),EMC
L2A1 LG 6200HJC102A FILTER(CIRC),EMC
L2A2 LG 6200HJC102A FILTER(CIRC),EMC
L301 LG 6200HJC102A FILTER(CIRC),EMC
L302 LG 6200HJC102A FILTER(CIRC),EMC
L3F1 LG 6200HJC102A FILTER(CIRC),EMC
L501 LG 6200HJC102A FILTER(CIRC),EMC
L502 LG 6200HJC102A FILTER(CIRC),EMC
L503 LG 6200HJC102A FILTER(CIRC),EMC
L504 LG 6200HJC102A FILTER(CIRC),EMC
L505 LG 6200HJC102A FILTER(CIRC),EMC
L506 LG 6200HJC102A FILTER(CIRC),EMC
L507 LG 6200HJC102A FILTER(CIRC),EMC
L510 LG 6200HJC102A FILTER(CIRC),EMC
L511 LG 6200HJC102A FILTER(CIRC),EMC
NSP:Not Service Parts
SPECIFICATION NSP
22P 50V J COG 1.6X0.8 R/TP
100P 50V J COG 1.6X0.8 R/TP
100P 50V J COG 1.6X0.8 R/TP
47M SRA/SS 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
DAN202K TP ROHM KOREA SOT23 80
DAN202K TP ROHM KOREA SOT23 80
DAN202K TP ROHM KOREA SOT23 80
DAP202K T146 ROHM R/TP SMD 80V
HDC25D811B HYUNDAI 208 QFP TRA
TC7W04FU
HD153702TF HITACHI 64 TQFP TRA
NJM3414AM TE1,3K/REEL. JRC
KIA393F EL FLP 8 TP DUAL COMPA
KA3032 48QFP BK 5CH MOTOR DRIV
FAN8004 FAIRCHILD 48 QFP TRAY
XC9572XL 10TQ100C 100 QFP TRAY
HS353106 HYNIX 100 TQFP TRAY C
HY57V653220CTC 7 86P TSOP BK S
HY57V643220CT 7 HYUNDAI 86P TS
MBM29LV800BA 90PFTN FUJITSU 48
VJW602CS (JVC) DVD PROGRAM
CS4391 KZR CIRRUS LOGIC 20 TSS
NJM4580M 8,DMP8 TP OP AMP 2K/R
NDV8602 240 VQFP BK MICOM+MPEG
CAT93C56S TE13 CRYSTAL SEMICON
AT93C56 10SC(SI) 2.7 8S1 ATMEL
MM74HCT244SJ 20P SOIC TP 3 STA
AMC1117 1.8SJ ADD MICROTECH 3P
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
HB 1M2012 102JT CERATECH TP
# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
Q2A1 2SA1037K/QR/ X TRANSISTOR,BIPOLARS
Q2A2 2SA1037K/QR/ X TRANSISTOR,BIPOLARS
Q2A5 LG 0TR388209AA TRANSISTOR,BIPOLARS
Q2A6 LG 0TR388209AA TRANSISTOR,BIPOLARS
Q2M1 DTC124EKA X TRANSISTOR,BIPOLARS
Q401 2SA1037K/QR/ X TRANSISTOR,BIPOLARS
Q404 LG 0TR103009AC TRANSISTOR
Q405 LG 0TR103009AC TRANSISTOR
R201 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R202 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R203 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R204 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R207 NRSA63J 105X RESISTOR,METAL GLAZED(CHIP)
R217 NRSA63J 100X RESISTOR,METAL GLAZED(CHIP)
R218 NRSA63J 471X RESISTOR,METAL GLAZED(CHIP)
R219 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R220 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R230 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R231 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R232 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R233 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R234 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R235 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R236 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R237 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R239 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R240 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R241 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R242 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R243 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R252 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R269 LG 0LC0233002B INDUCTOR,CHIP
R271 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R272 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R273 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R274 NRSA63J 621X RESISTOR,METAL GLAZED(CHIP)
R275 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R276 NRSA63J 911X RESISTOR,METAL GLAZED(CHIP)
R277 NRSA63J 151X RESISTOR,METAL GLAZED(CHIP)
R278 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R279 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R281 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R290 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R291 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R292 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R293 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R294 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R295 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2A1 NRSA63J 910X RESISTOR,METAL GLAZED(CHIP)
R2A2 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2A6 NRSA63J 123X RESISTOR,METAL GLAZED(CHIP)
R2A9 NRSA63J 563X RESISTOR,METAL GLAZED(CHIP)
R2B0 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2B1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2B2 NRSA63J 180X RESISTOR,METAL GLAZED(CHIP)
R2B3 NRSA63J 180X RESISTOR,METAL GLAZED(CHIP)
R2B4 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2B5 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2B6 NRSA63J 180X RESISTOR,METAL GLAZED(CHIP)
R2B7 NRSA63J 180X RESISTOR,METAL GLAZED(CHIP)
R2B8 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2C0 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2C4 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2C5 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2C6 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2C7 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2C8 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2C9 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2D0 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2D1 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2D2 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2D3 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2D4 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R2D5 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R2D6 NRSA63J 910X RESISTOR,METAL GLAZED(CHIP)
R2E6 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R2E7 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R2E8 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R2E9 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R2F1 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R2F2 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R2F3 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R2F4 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R2F5 NRSA6AD 223W RESISTOR,METAL GLAZED(CHIP)
SPECIFICATION NSP
2SA1037K Q CHIP TP ROHM
2SA1037K Q CHIP TP ROHM
CHIP KTC3882 SOT 23 TP KEC
CHIP KTC3882 SOT 23 TP KEC
DTC124EK TP ROHM KOREA SOT23 3
2SA1037K Q CHIP TP ROHM
KRA103S T1(PC)22 22 CHIP KEC
KRA103S T1(PC)22 22 CHIP KEC
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1M OHM 1 / 16 W 1608 5.00% D
10 OHM 1 / 16 W 1608 5.00% D
470 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
HB 1S1608 800JT CERATECH R/TP
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
620 OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
910 OHM 1 / 16 W 1608 5.00% D
150 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
91 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
12K OHM 1 / 16 W 1608 5.00% D
56K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
18 OHM 1 / 16 W 1608 5.00% D
18 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
18 OHM 1 / 16 W 1608 5.00% D
18 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
91 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
22K OHM 1 / 16 W 1608 1.00% D
6-11
