SERVICE MANUAL
LECTEUR DVD Hi-Fi VIDÉO MAGNÉTOSCOPE
Regarding service information other than these sections, refer to the service manual No. 82927 (HR-XV1EU-C).
Also, be sure to note important safety precautions provided in the service manual.
Caractéristiques techniques
GENERAL
Fonctionne sur courant:
Consommation électrique:
Poids:
Dimensions:
Niveau d'entrée:
Niveau de sortie:
Hi-Fi Distorsion de fréquence: 20Hz to 20,000Hz
Hi-Fi Gamme d'amplification: More than 75dB
Magnétoscope
Signal couleur:
Tête vidéo:
Piste audio:
Couverture des canaux:
Durée rembobinage rapide:
HR-XV1MS
AC 230V 50Hz
marche: 22W
veille: 5W
4.5 kg
largeur: 430 mm
Hauteur: 99 mm
profondeur: 310.5 mm
Prise SCART: VIDEO: 1 Vp-p, 75 Ω
AUDIO: 500 mV, 50 kΩ
Audio IN jack: 500 mV, 50 k Ω
Prise SCART: VIDEO: 1 Vp-p, 75 Ω
AUDIO: 500 mV, 1 kΩ
Audio OUT jack: 500 mV, 1 kΩ
PAL et SECAM Lecture NTSC
4 têtes rotatives
Son Hi-Fi - 2 pistes/son mono - 1 piste
2-12, X, Y, Z, S1-S41, 21-69
Environ 1 minute 48 secondes
(avec une cassette E-180) (à + 25˚C)
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD
Lecteur DVD
Système de signal:
PAL
Disque compatibles:
DVD (12cm, 8cm), CD (12cm, 8cm)
Caract éristiques audio:
DVD: 4Hz - 22KHz
Distorsion de fréquence:
CD: 4Hz - 20KHz
T aurapport signal/bruit
90dB
Distorsion harmonique:
0.1%
scintillement et pleurage:
En dessous des seuils de mesure
Gamme d'amplification:
90dB
sortie:
Audio: (RCA) 500 mV, 1Kohm
Digital Audio: 0.5Vp-p/75 ohm
Micro:
CD: longueur d'onde: 775 - 805 nm
DVD: longueur d'ondes: 640 - 660 nm
A CCESSOIRES:
Télécommande x 1
Câble coaxial 75 ohm x 1
Câble Scart x 1
Pile (UM-3) x 2
PAL SECAM
DIGITAL VIDEO
Sortie maximum: 0.5 mW
Sortie maximum: 1.0 mW
HR-XV1MS V14PV1
No.82943
August 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HR-XV1EU-C and is the answer not in the manual?

Questions and answers

Related Manuals for JVC HR-XV1EU-C

Summary of Contents for JVC HR-XV1EU-C

  • Page 1 LECTEUR DVD Hi-Fi VIDÉO MAGNÉTOSCOPE HR-XV1MS PAL SECAM DIGITAL VIDEO Regarding service information other than these sections, refer to the service manual No. 82927 (HR-XV1EU-C). Also, be sure to note important safety precautions provided in the service manual. Caractéristiques techniques GENERAL...

  • Page 3: Table Of Contents

    PACKING AND ACCESSORY ASSEMBLY <M1> ..........................3-1 ELECTRICAL PART LIST VCR BOARD ASSEMBLY<03> ................................3-2 4. REFERENCE (4-1 to 4-6) GENERAL SPECIFICATIONS ................................4-1 The following table indicates main different points between models HR-XV1EU-C and HR-XV1MS. MODEL HR-XV1EU-C HR-XV1MS ITEM...
  • Page 5 <Reference> GENERAL SPECIFICATIONS Outline of the product DVD VIDEO PLAYER & VHS Player / Recorder DVD System Color System Disc DVD, CD-DA, CD-R/RW, VIDEO CD Disc Diameter 120 mm , 80 mm Deck Disc Loading System Front Disc Loading Motor 3 Motors Pick up 1-Lens 2-Beams System...
  • Page 6 <Reference> GENERAL SPECIFICATIONS Signal Video Signal Output Level 1 V p-p/75 ohm (DVD,VCR) S/N Ratio (Weighted) 65 dB(DVD) 53 dB(VCR) Horizontal Resolution 500 Lines (DVD) 240 Lines(VCR at SP) RGB Signal Output Level 0.7V p-p / 75 ohm Audio Signal Input Level Microphone Input Level Line -3.8 dBm/ 50k ohm(VCR)
  • Page 7 <Reference> GENERAL SPECIFICATIONS On Screen Menu Display(VCR) Menu Type Character Timer Rec Set VCR Extension Auto Repeat On/Off Scene Repeat Audio Dubbing VCR Set-Up NICAM Auto/Off Audio Mix On/Off Color System Sharpness BBE On/Off CH Set-Up CH Tuning Auto Tuning CH Mapping Guide CH Set Pin Code Registration...
  • Page 8 <Reference> GENERAL SPECIFICATIONS G-14 Remote Unit RC-FO Control Glow in Dark Remocon Format Custom Code 43,53(DVD,VCR), 03( TV ) Power Source Voltage(D.C) UM size x pcs UM-3 x 2 pcs Total Keys 50 Key Keys Power 0/AV DVD MENU MEMORY RETURN OPEN/CLOSE CLOCK / COUNTER...
  • Page 9 <Reference> GENERAL SPECIFICATIONS Features Auto Head Cleaning (VCR) Auto Tracking Index Search HQ (VHS Standard High Quality) Auto Power On, Auto Play, Auto Rewind, Auto Eject Auto Repeat Auto Power Off VIDEO PLUS+(SHOWVIEW,G-CODE) Auto Tuning/Auto Clock/Auto Guide ch Auto Set Up (CH Auto Set-Up/Auto Clock) Reverse Slow One Touch Playback Picture Control(Sharpness)
  • Page 10 <Reference> GENERAL SPECIFICATIONS G-17 Interface Switch Front Power Play Eject (VCR) Stop Rec/OTR Open/Close (DVD) CH + CH - FF/ Search(>>) Rew/Search(<<) Still/Pause Shuttle(Search/REV/FWD) DVD/VCR Input Select Main Power SW Rear Attenuator Video/RGB Selector RF Out(Slide SW) Main Power SW Volume Phones Volume Mic Volume...
  • Page 12 VICTOR COMPANY OF JAPAN, LIMITED HOME AV NETWORK BUSINESS UNIT. 12,3-chome,Moriya-cho,Kanagawa-ku,Yokohama,Kanagawa-prefecture,221-8528,Japan Printed in Japan 0208 VP...

  • Page 13: Y/C/Audio/H.amp Schematic Diagram

    The Parts Number , value and rated voltage etc. in the Schematic Diagram are for references only. Note : When replacing the parts , refer to the Parts List. L4601 P.CON+5V BUFFER 47uH Y/C/AUDIO/H.AMP SECAM PB Q4601 0305 KTC3875S_ VV SW Q4605 Y_RTK FROM/TO MICON...
  • Page 14 The Parts Number , value and rated voltage etc. in the Schematic Diagram are for references only. Note : When replacing the parts , refer to the Parts List. MICON SCHEMATIC DIAGRAM (VCR PCB) FROM/TO REGULATOR (S/S) FROM/TO TUNER/JACK MOTOR_GND AT+5.2V PERI_CTL-L P.CON+5V...

  • Page 15: Tuner/Jack Schematic Diagram

    The Parts Number , value and rated voltage etc. in the Schematic Diagram are for references only. Note : When replacing the parts , refer to the Parts List. AUDIO OUT Y/C SEPA TUNER/JACK SCHEMATIC DIAGRAM J8002 J8003 (VCR PCB) MSP-242V2-01PBSN MDC-070V OPT TRNSFORMER...

  • Page 16: Sub Micom/Osd/Vps Schematic Diagram

    The Parts Number , value and rated voltage etc. in the Schematic Diagram are for references only. Note : When replacing the parts , refer to the Parts List. SUB MICON/OSD/VPS SCHEMATIC DIAGRAM (VCR PCB) FROM REGULATOR C4505 R4505 L4503 L4505 C4514 P.CON+5V...

  • Page 17: Printed Circuit Board Vcr

    PRINTED CIRCUIT BOARDS VCR (INSERTED PARTS) SOLDER SIDE COMPONENT PARTS LOCATION GUIDE < CP653_1 CP8002 REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION W851 CAPACITOR C722 C8008 D656 C106 C723 C8009 C107 C724 C8010 CP8001 C108 C725 C8011 W850 W067 C109 C726 C8012 W120 C111...
  • Page 18 PRINTED CIRCUIT BOARDS VCR (CHIP MOUNTED PARTS) SOLDER SIDE <VCR> VMB252A REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF IC102 Q8001 R3013 R8054 IC701 Q8002 R3014 R8055 IC801 Q8003 R3015 R8056 IC3001 Q8004 R3016 R8057 IC3004 Q8012 R3017 R8058 IC3005 Q8013 R3018...

  • Page 19: Parts List (3-1 To 3-7)

    PARTS LIST SAFETY PRECAUTION Parts identified by the symbol are critical for safety. Replace only with specified part numbers. PACKING AND ACCESSORY ASSEMBLY <M1> The instruction manual to be provided with this product will differ according to the destination. 10, 11, 12 1, 17 SPEC OF BARCODE SPEC OF BARCODE...

  • Page 20: Electrical Part List

    ELECTRICAL PARTS LIST REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 21 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 22 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 23 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 24 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 25 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
